Ferno IndustriPOD FWE-INPOD User Instructions

Australia
The IndustriPOD® is a heavy duty, versatile and durable tripod that exceeds the criteria of most international
standards. It has built in safety factors equivalent to internationally recognised rescue systems. Its unique
design and simplicity makes it ideal for any heavy duty confined space requirement where guaranteed
performance is mandatory.
1
Fig 1
5

FEATURES

• Rectangular fully adjustable legs with quick action ball
lock leg pins
• One piece fabricated steel head
• Adjustable feet with aggressive non-slip tread pattern
• One swivel eyebolt
• Three karabiner attachment points
• Three tie-off points for rigging or stabilisation

WARNING

Activities conducted at height can be dangerous resulting in
injury or death. Do not use this device unless you have:
1. Read and understood the User's Instructions
2. Received appropriate training
3. Ensured a competent person has conducted a risk
assessment for the specific task
4. Carried out a preoperational check of the tripod, associated
hardware and rigging before each use
5. Accepted total responsibility for your safety, and all risk
assessments are completed.
HEAD OFFICE: 11 Johnstone Road, Brendale, QLD 4500
Toll Free: 1800 804 647 | Tel: +61 7 3881 4999 | Email: sales@ferno.com.au | www.ferno.com.au
2
3
4
6
7
IndustriPOD® Instructions: ID# 00195-V1- 03/2013
(FWE-INPOD)

TRIPOD PARTS IDENTIFIER

Tripod Head
1
Stabilisation Point (3)
2
Side Plate Attachment Point (3)
3
Eyebolt (1)
4
Leg Pin (3)
5
Adjustable Foot Tether (1)
6
Tripod Feet (3)
7

TECHNICAL SPECIFICATIONS

WEIGHT 23 kgs
OVERALL HEIGHT 2465 mm extended, 1650 mm collapsed
FOOT PRINT 2185 mm inside diameter of feet
CONSTRUCTION Steel, aluminium and stainless steel
SWL 550 kg off centre eyebolt
360 kg off side plate attachment points
RATING 2 Person rescue - 1 Person working
TRIPOD SUPPLIED WITH 1 x Adustable Foot Tether sling
3 x Leg Pins

OPTIONAL ACCESSORIES

36-1019 IndustriPOD® Bag
16-1046-0 Hold-down Stake
07-1026-0 Step
90-0119 Equipment Bracket
APOD-W10/W20/W25 10m/20m/25m Winch & Mount - 6mm cable
APOD-FA 15m Type 3 Fall Arrestor & Mount
These instructions are not intended as a substitute for
appropriate training. Training, practice and experience in
technical rigging are essential for safe use.
Operator Responsibility
The product liability of the manufacturer does not cover damage
to property or body injuries which may occur as a result of
improper use or function. It is the responsibility of the operator/s
to ensure the correct personal protective equipment (PPE) is
used when operating the unit. The manufacturer is not liable
for the correct or incorrect use of PPE. Any modifications to the
product or disregarding the Operator Instructions or safety rules
voids any liability extended towards the manufacturer.
IndustriPOD
USER INSTRUCTIONS
1
