- Page 1 X100PAD3 Auto Key Programmer User Manual https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
- Page 2 Declaration 1. This manual is designed for the usage of X100PAD3, applying to X100PAD3 smart automotive diagnosis platform. No part of this manual can be reproduced, stored in a retrieval system or transmitted, in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), without the prior written permission of Xtool.
- Page 3 Xtool X100PAD3 Diagnosis System Main Unit Maintenance Avoid shaking or dismantling the unit as it may damage the internal components. Do not use hard or sharp objects to touch the LCD screen; do not use excessive force; do not expose the screen to strong sunlight for a long period.
-
Page 4: Table Of Contents
3. X100PAD3 Technical Parameters ................2 CHAPTERⅡ How to Use X100PAD3 ................3 1. X100PAD3 Activation ....................3 2. X100PAD3 Main Interface and Functional Buttons Descriptions ....... 3 2.1. Main Interface ......................3 2.2. Sub-menu and Functional Buttons ............... 5 2.3. -
Page 5: Chapterⅰ About X100Pad3
CHAPTER Ⅰ About X100PAD3 1. Appearance 1.1. Front View 1.2. Back View https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 6: Layout Of X100Pad3 Tablet
2. Layout of X100PAD3 Tablet 2.1. Top View of X100PAD3 Tablet ① ② ③ ④ ⑤ ①USB3.0 interface: Wired data transmission ②Mini HDMI interface: Transmission of audio and video ③DB15 interface: Subsequent extended reservation port ④DC charging port: Charge for equipment, use 12V power supply ⑤Power Button: Power on or power off... - Page 7 Interface: USB3.0, DC charging port, MINI HDMI, DB15 interface. Battery: 10000mAh 3.7V lithium polymer battery Input voltage: +9~+36VDC, compatible with 12V and 24V voltage system. Working temperature: -20 to 50 C (-4 to 126 C) Relative humidity: <90% Appearance size: 275·183·33.9 (mm) https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 8: Chapterⅱ How To Use X100Pad3
CHAPTER Ⅱ How to Use the X100PAD3 . X100PAD3 Activation 1.1. Please activate X100PAD3 before you use it to test vehicles. And please connect WiFi first. 1.2. Input Company name and mailbox, the diagnostic application will start after activation. 2. X100PAD3 Main Interface and Functional Buttons Descriptions 2.1. - Page 9 https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 10: Sub-Menu And Functional Buttons
2.2. Sub-menus and Function Buttons Functional Buttons Functional Descriptions 【Diagnosis】Read vehicle diagnosis information 【Diagnose report】Read vehicle report 【Setting】Language, unit, Bluetooth 【Xtool cloud】Online chatting 【One-click upgrade】Upgrade software 【Remote control】Xtooltech support center and function keys https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 11: Vehicle Connection Diagnosis
XTOOL service center.】 3. Vehicle Connection Diagnosis 3.1. Vehicle Connection Test a. Turn on X100PAD3 tablet b. Connect cables and X100PAD3 in following order: ①→②→③→④ c. Switch on the ignition and tap on X100PAD3 application to test vehicles. (Shown as follows) https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 12: Precautions Before Use
3.2.4. If users can not find the tested vehicle model or electronic control system in the X100PAD3 test menu, they may need to update the software or consult Xtool technical service department. -
Page 13: Special Function And Diagnosis
4.Special function and Diagnosis 4.1. Menu Options 4.1.1. After the X100PAD3 mainframe is connected to the vehicle via main test cable, Immobilization can be performed. The Immobilization interface is shown as below: 4.1.2. X100PAD3 lists mileage adjustment separately. The Dashboard Recovery interface is shown as below: https://www.uobdii.com/wholesale/xtool-x100-pad3.html... - Page 14 4.1.3. Users can choose the relevant menu for the vehicle being tested: selection for Europe will enter the European cars menu, selection for Asia will enter the Asian cars menu, selection for America will enter the American cars menu. 4.1.4. Besides the usual system diagnostic functions, XTOOL also has developed a https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 15: Test Functions
4.2.1. Using BMW as an example, select Common Diagnosis, then select EUROPE. Choose the BMW word. If the word is not showing on the screen, please swipe up or down to display it. PLEASE NOTE: Different vehicles have different menus and systems. Common main function menu includes the following options: https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 16: Read Ecu
Users can then enter the nature of the problem and any other relevant information and send the form to the Xtool engineering department. - Page 17 This function is used to read ECU version information, which is the equivalent of “System Identification” or “System Information” in some electronic control systems. This will allow you to read ECU related software and hardware versions, models and production date of diesel engine, part number, etc. shown below: https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 18: Read Dtcs
4.5.1. Return to the previous step, select Clear Fault Codes to clear the current and historical trouble codes memory in ECU. Performing this function will clear all the current and historical trouble codes. Please ensure that the trouble codes have been recorded before clearing, shown below: https://www.uobdii.com/wholesale/xtool-x100-pad3.html... - Page 19 https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 20: Settings
By selecting Settings users can set the language, unit and other system related options. Languages: select the language. Please tick the required option from the multi-language options on the right. Units: Select unit of measurement. Users can select Metric or British Unit. https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 21: Xcloud
7. Update X100PAD3 updates directly via the Internet using WiFi or wired connection. To access the update application open the X100PAD3 application and click UPDATE , shown below. https://www.uobdii.com/wholesale/xtool-x100-pad3.html... -
Page 22: Report
Report is used for viewing and printing the saved files, such as Live Data, Trouble Codes or pictures generated in the process of diagnosis, users also can view a record of which cars have been previously tested. It includes three parts: PDF Files, Pictures and Data Playback. https://www.uobdii.com/wholesale/xtool-x100-pad3.html... - Page 23 Entering PDF will allow you to view and print these reports. 8.1.2 Click PDF icon to generate PDF when you want to save the trouble code report 8.2. Data Replay: With Data Playback you can play back recorded Data. 8.3. File Management: https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 24: Remote
If users encounter problems and are not able to solve them, they can open this application and ask for remote assistance. How to get remote assistance from Xtool Technical Assistance Center: a. Open X100PAD3 b. Click Remote and open the Team Viewer interface. Generate and display device ID. -
Page 25: Chapterⅲ How To Use Kc100
1. Please use main cable and OBDII connector (or other relative connector) to connect between X100PAD3 and your car’s OBD port. 2. Please use USB to mini USB cable to connect between X100PAD3 and KC100. 3. Please switch ignition on position, then enter software as following steps:... - Page 26 https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
- Page 27 5 immobilizer system. It will detect your meter type automatically, if it does not detect successfully, you can choose your meter type manually. 5. Then follow the instructions that software reminds you to copy new keys. https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 28: Diagnostic Link Connectors Locations Of Various Vehicle Models
*AUDI A6: the OBD plug is on the lower left side of the dashboard, use SMART OBDII-16 connector. *VW Bollywood 1.8: the OBD plug is below the console, use SMART OBDII-16 connector. *Benz S320,220 Chassis: the OBD plug is below the dashboard, use SMART OBDII-16 connector. https://www.uobdii.com/wholesale/xtool-x100-pad3.html... - Page 29 *Benz 300SEL 140 chassis: the OBD plug is on the left hand side of the engine bay, use Benz-38 connector. *GM Buick: the OBD plug is below the dashboard, use SMART OBDII-16 connector. *GM Buick GL8 : the OBD plug is below the dashboard, use SMART OBDII-16 connector. https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
- Page 30 *BMW 735I: the OBD plug is in the right hands side of the engine bay, use BMW-20 connector. *VW Passat B5: the OBD plug is behind the gearlever and beside the parking brake lever. Lift the cover to access it. Use SMART OBDII-16 connector. https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
-
Page 31: Location Diagram Of Vehicle Diagnostic Link Connectors
3. Diagnostic Link Connectors Terminal Definition and Communication Protocols 3.1. Standard OBDII Diagnostic Link Connector: Pin Definition (Reference material) Various pin definitions as follows: 1. Manufacturer definition 2. SAE J1850 bus positive 3. Manufacturer definition 4. Bodywork site 5. Signal site https://www.uobdii.com/wholesale/xtool-x100-pad3.html... - Page 32 14. ISO9141 and ISO14230 defined L line 15. Permanent positive voltage [1] 1, 3, 8, 9, 11, 12 and 13 are defined by manufacturer. [2] 2, 6, 7, 10, 14 and 15 are used for diagnostic communication. Unused definitions can be defined by manufacturers. https://www.uobdii.com/wholesale/xtool-x100-pad3.html...
