  • Page 1 P R E M I U M G R ILL S atio BL26P-2 SS26P-2 Round BL48G-2 SS48G-2 ’ etain wneR anual foR utuRe efeRence Page 1...
  • Page 2 IMPORTANT INFORMATION IMPORTANT his manual should be read thoroughly by the installer and by anyone who will use or maintain the grill. Installer - Write the model number, serial number, and date of installation in the manual. If available, attach a copy of the receipt. Leave this manual with the grill owner. Grill Owner - Read and retain this manual.
  • Page 3 Thank you for purchasing a Broilmaster Grill Post Accessory. Broilmaster takes pride in its reputation as the The Most Durable Grill Known to Man. From its thick aluminum casting to its massive cooking grids, your Broilmaster is built to last. In fact we still make replacement parts for Broilmaster grills built more than 30 years ago.
  • Page 4: Table Of Contents

    TABLE OF CONTENTS You have chosen the finest grill for your outdoor cooking pleasure. Please take time to read this entire manual before assembling your Broilmaster Grill Accessory. ASSEMBLY INSTRUCTIONS ....................5 IMPORTANT INFORMATION ....................6 BL48G-2, SS48G-2 IN-GROUND POST SECTION ............7 - 16 IN-GROUND POST PARTS DIAGRAM ..................
  • Page 5: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Before You Begin Compare the parts in the box to the parts list provided in this manual. If any are missing, contact your Broilmaster dealer before beginning assembly. All Broilmaster grills require some assembly. For the best results, follow the step-by-step instructions. For natural gas grills, have your gas supplier run service to the desired location first.
  • Page 6: Important Information

    IMPORTANT INFORMATION Grill Location your Broilmaster dealer.) Installing old grill head P3 or P4 to new in-ground post. A This grill is designed for outdoor use only. B101668 kit will need to be used to cover the opening in the post. See instructions with the kit for further installation information.
  • Page 7: Bl48G-2, Ss48G-2 In-Ground Post Section

    BL48G-2, SS48G-2 IN-GROUND POST SECTION P R E M I U M G R I LL S BL48G-2, SS48G-2 ONE PIECE IN-GROUND POST Page 7...
  • Page 8: In-Ground Post Parts Diagram

    IN-GROUND POST PARTS DIAGRAM B101760 (1) UPPER BRACKET ASSEMBLY B101473 (1) GREASE CUP B101628 (1) GREASE CUP HOLDER B101630 (1) POST ACCESS DOOR B101674 (1) POST ASSEMBLY, SS B101672 (1) POST ASSEMBLY, BLACK B076519 (1) FLEX LINE Page 8 B102250-1-0714...
  • Page 9: Post Hardware Pack - B101999

    POST HARDWARE PACK - B101999 Standard hardware items such as bolts, screws, washers, and nuts can be purchased at your local hard- ware store. Do not order individual pieces of standard hardware. A replacement hardware pack may be ordered using the hardware pack part number at the top of the page. B102250-1-0714 Page 9...
  • Page 10: Insert Flex Line Through

    INSERT FLEX LINE THROUGH Patio Post, BL26P or Ss26 posts, skip to page 13. Arrange with your local gas company or licensed contractor to have a gas supply At the access door connect a 3/8" flare line connected to inlet of stainless steel coupling (not supplied by Empire) to the flex tube assembly.
  • Page 11: Place Post In Ground

    PLACE POST IN GROUND 24 3/4 ” ABOVE GRADE Check Local Codes for requirements concerning buried gas lines. SOIL GRADE GAS SUPPLY LINE CONCRETE OR STANDARD PRE-MIX 1. Dig a posthole approximately 12" in diameter and 28 3/4" in depth at the desired grill location. Note: "Normal Installation"...
  • Page 12: Attach Upper Bracket

    ATTACH UPPER BRACKET HEX HEAD SCREW, SS,10 X 1/2 B101569 (4) 5/16” Page 12 B102250-1-0714...
  • Page 13: Grease Cup Holder Placement

    GREASE CUP HOLDER PLACEMENT Remove Protective film applied to Grease Cup Holder prior to install. Snap Grease Cup Holder to top of Post. Use only the supplied Grease Cup or noncombustible containers for the Grease Cup (aluminum or tin cans). B102250-1-0714 Page 13...
  • Page 14: Attach Bottom Casting To Post

    ATTACH BOTTOM CASTING TO POST HEX HEAD BOLT SS, 1/4-20 X 3/4 B063096 (4) FLAT WASHER, SS, 1/4 ID X 5/8 OD B076332 (4) 7/16” Page 14 B102250-1-0714...
  • Page 15: Attach Post Cover Plate Upper Bracket (R3 Only)

    ATTACH POST COVER PLATE UPPER BRACKET (R3 ONLY) HEX HEAD SCREW, SS,10-24 X 1/2 B101569 (2) 5/16” PROTECTIVE Remove Protective FILM SIDE Film from Cover Plate and bend tabs. COVER PLATE Remove Front Left and Right Screws and install Cover Plate after head and gas line is connected.
  • Page 16: Grease Cup And Access Door Placement

    GREASE CUP AND ACCESS DOOR PLACEMENT HEX HEAD SCREW, SS,10-24 X 1/2 B101569 (1) 5/16” Slide Grease Cup into the cutout provided in the Grease Cup Holder. Secure Access Door with hex-head screw Page 16 B102250-1-0714...
  • Page 17: Bl26P-2, Ss26P-2 Patio Base Section

    BL26P-2, SS26P-2 PATIO BASE SECTION P R E M I U M G R I LL S BL26P-2, SS26P-2 PATIO BASE Page 17...
  • Page 18: Patio Base Parts Diagram

    PATIO BASE PARTS DIAGRAM Page 18 B102250-1-0714...
  • Page 19: Patio Base Hardware Pack - B102255

    PATIO BASE HARDWARE PACK - B102255 Standard hardware items such as bolts, screws, washers, and nuts can be purchased at your local hard- ware store. Do not order individual pieces of standard hardware. A replacement hardware pack may be ordered using the hardware pack part number at the top of the page. B102250-1-0714 Page 19...
  • Page 20: Attach Lower Bracket

    ATTACH LOWER BRACKET HEX HEAD SCREW, SS,10 X 1/2 B101569 (8) (STAINLESS SERIES ONLY) 5/16” Page 20 B102250-1-0714...
  • Page 21: Attach Base To Post

    ATTACH BASE TO POST HEX HEAD SCREW, SS,1/4-20 X 1-1/2 B100112 (4) LOCK WASHER, SS, 1/4 ID X 1/2 OD B076333 (4) 7/16” CAST BASE B102250-1-0714 Page 21...
  • Page 22: Insert Flex Line Through Post

    INSERT FLEX LINE THROUGH POST GAS OUTLET TO GRILL CONTROL Insert the stainless steel Flex Tube PANEL Assembly into the Post. The inlet side of the tube may protrude from the bottom of the Patio Base or through the large square hole in the back of the square Post.
  • Page 23: Attach Upper Bracket

    ATTACH UPPER BRACKET HEX HEAD SCREW, SS,10 X 1/2 B101569 (4) (STAINLESS SERIES ONLY) 5/16” Slide the Upper Bracket into the Post and secure with four Self Drill Screws. B102250-1-0714 Page 23...
  • Page 24: Grease Cup Holder Placement

    GREASE CUP HOLDER PLACEMENT Remove Protective film applied to Grease Cup Holder prior to install. Snap Grease Cup Holder to top of Post. Use only the supplied Grease Cup or noncombustible containers for the Grease Cup (aluminum or tin cans). Page 24 B102250-1-0714...
  • Page 25: Attach Bottom Casting To Post

    ATTACH BOTTOM CASTING TO POST HEX HEAD BOLT SS, 1/4-20 X 3/4 B063096 (4) FLAT WASHER, SS, 1/4 ID X 5/8 OD B076332 (4) 7/16” B102250-1-0714 Page 25...
  • Page 26: Attach Post Cover Plate Upper Bracket (R3 & R3B Only)

    ATTACH POST COVER PLATE UPPER BRACKET (R3 & R3B ONLY) HEX HEAD SCREW, SS,10 X 1/2 B101569 (2) (STAINLESS SERIES ONLY) HEX HEAD SCREW, BLACK,10 X 1/2 R2737 (2) (BLACK SERIES ONLY) 5/16” PROTECTIVE Remove Protective FILM SIDE Film from Cover Plate and bend tabs.
  • Page 27: Grease Cup And Access Door Placement

    GREASE CUP AND ACCESS DOOR PLACEMENT HEX HEAD SCREW, SS,10 X 1/2 B101569 (1) 5/16” Install Grease Cup by sliding it in the cutout provided in the Grease Cup Holder. Secure Access Door with hex-head screw B102250-1-0714 Page 27...
  • Page 28: Grill Maintenance History

    GRILL MAINTENANCE HISTORY Date Maintenance Performed Page 28 B102250-1-0714...
  • Page 29 GRILL MAINTENANCE HISTORY Date Maintenance Performed B102250-1-0714 Page 29...
  • Page 30 GRILL MAINTENANCE HISTORY Date Maintenance Performed Page 30 B102250-1-0714...
  • Page 31: Master Parts Distributor List

    MASTER PARTS DISTRIBUTOR LIST To order parts under warranty, please contact your local Broilmaster dealer. See the dealer locator at www.broilmaster.com. To provide warranty service, your dealer will need your name and address, purchase date and serial number, and the nature of the problem.
