Danfoss MCV111B Series Manual page 3

DIMENSIONS, 75, 100, 130, 180, AND 250 cc PUMP EDC
CONTROL MS CONNECTOR
LINKAGE OPTION
PACKARD
WEATHER-PACK
CONNECTOR
OPTION
10,4
(0.41)
22,4
(0.88)
Dimensions of the MCV111B EDC for 75, 100, 130, 180, and 250 cc Pumps in Millimeters (Inches).
DIMENSIONS, 42 cc AND 55 cc PUMP EDC
CONTROL
LINKAGE
10,4
(0.41)
22,4
(0.88)
Dimensions of the MCV111B EDC for 42 cc and 55 cc Pumps in Millimeters (Inches).
27,94
(1.10)
52,83
(2.08)
SAE
SERVO PORT
FITTING X1
27,94
(1.10)
52,83
(2.08)
MS CONNECTOR
OPTION
PACKARD
WEATHER-PACK
CONNECTOR
OPTION
SAE
SERVO PORT
FITTING X1
MANUAL OPERATOR
203,2
(8.00)
49,78
(1.96)
108,46
(4.27)
141,22
(5.56)
169,67
(6.68)
186,06
(7.33)
203,2
(8.00)
49,78
(1.96)
108,46
(4.27)
141,22
(5.56)
169,67
(6.68)
186,06
(7.33)
3
8,6 REF.
(0.34)
7,11
(0.28)
NEUTRAL ADJUST
LOCK NUT
122,99
7,14 DIA 6 PLACES
(0.28 DIA)
89,41
(3.52)
55,37
(2.18)
36,07
31,62
(1.42)
(1.25)
12,2
SAE
(0.48)
SERVO PORT
FITTING X2
9,4
(0.37)
8,6 REF.
(0.34)
7,11
(0.28)
NEUTRAL ADJUST
LOCK NUT
MANUAL OPERATOR
122,99
(4.84)
7,14 DIA 6 PLACES
(0.281 DIA)
89,41
(3.52)
55,37
(2.18)
36,07
31,62
(1.42)
(1.25)
12,2
(0.48)
SAE
SERVO PORT
FITTING X2
9,4
(0.37)
BLN-95-8995-4
(4.84)
1788
1789
