Zte Z233 User Manual

Have questions about your phone? Contact us by dialing 611 from your Affinity Cellular phone or 866-488-8717 from a landline.
ZTE 2233
USERS MANUAL
Camera
External
Display
Cha,g;ng/
micro-USB
Port
Internal
Display
Key
4-Way Navigation
l<ft
Key
Soft
Send Key
Apps Key
Recent
Camera Key
* Key
Key Functions
Power/Lock Key: Press and hold to turn Airplane mode on or off, restart, or to
or
power off. Press to end cancel a call. Press to return to the home screen.
Left Soft Key/Right Soft Key: Press to select the options at the left/right corner
of the bottom of the display. The options change depending on the application/
function in use.
Send Key: Press to place or answer a call. Press to launch the Recent Calls
app from the home screen to view recent calls.
Clear Key: Press to delete text or numbers before the cursor.
4-Way Navigation Key: Press up/down/left/right to access designated functions
from the home screen, navigate options on the display, or move the cursor.
Auxiliary
Microphone
Batte,y
Cover
Earpiece
3, Press the cover gently back into place until you hear a click.
Key
Center
Rig Soft
ht Key
Key
Power/End
Key
Clear
Key
Vibration Mode
Main Microphone
Getting Started
The Battery
Installing the battery
1. Place your finger in the slot at the bottom of the back cover to lift and remove
the cover.
2. Insert the battery by aligning the metal contacts on the battery with the gold
contacts in the battery compartment. Gently push down on the battery until it
clicks Into place.
Removing the battery
1. Remove the back cover.
2. Lift the battery up and out.
Charging the Battery
1. Connect the adapter to the charging port. Ensure that the adapter is inserted
with the correct orientation. Do not force the connector into the charging port.
2. Connect the charger to a standard AC wall outlet. If the phone is on, you'll see
a charging icon, such as ffi or lJ, appear in the Status Bar.
3. Disconnect the charger when the battery is fully charged.
Turning The Phone On /
Turn Phone On
- Press and hold the Power/End Key to turn on your phone.
Turn Phone Off
- Press and hold the Power/End Key to open the options menu.
Select Power off> OK.
Off
