PROPANE CONStRuCtION CONVECtION HEAtER
IMPORTANT: Read and understand this manual before
assembling, starting or servicing heater. Improper use
of heater can cause serious injury. Keep this manual for
future reference.
GENERAL HAZARD WARNING:
Failure to comply with the precautions and instructions
provided with this heater, can result in death, serious
bodily injury and property loss or damage from hazards
of fire, explosion, burn, asphyxiation, carbon monoxide
poisoning and/or electrical shock.
Only persons who can understand and follow the instruc-
tions should use or service this heater.
If you need assistance or heater information such as an in-
structions manual, labels, etc. contact the manufacturer.
Safety .................................................................. 2
Unpacking............................................................ 3
Product Identification ........................................... 3
Ventilation ............................................................ 3
Theory of Operation............................................. 3
Propane Supply ................................................... 4
Installation ........................................................... 4
Operation ............................................................. 5
Storage ................................................................ 7
OWNER'S MANuAL
VARIABLE 40-80,000 Btu/HR
75-200,000 Btu/HR
tABLE OF CONtENtS
Save this manual for future reference.
For more information, visit www.desatech.com
Maintenance ........................................................ 7
Troubleshooting ................................................... 8
Specifications ...................................................... 9
Replacement Parts .............................................. 9
Technical Services ............................................... 9
Accessories ......................................................... 9
Parts .................................................................. 10
Warranty ............................................................ 14
Advertisement
Table of Contents
Related Manuals for Desa TC106A
Summary of Contents for Desa TC106A
-
Page 1: Table Of Contents
PROPANE CONStRuCtION CONVECtION HEAtER OWNER’S MANuAL VARIABLE 40-80,000 Btu/HR 75-200,000 Btu/HR IMPORTANT: Read and understand this manual before assembling, starting or servicing heater. Improper use of heater can cause serious injury. Keep this manual for future reference. GENERAL HAZARD WARNING: Failure to comply with the precautions and instructions provided with this heater, can result in death, serious bodily injury and property loss or damage from hazards... -
Page 2: Safety
SAFEty Propane Gas: Propane gas is odorless. An WARNING: This product odor-making agent is added to propane gas. contains and/or generates The odor helps you detect a propane gas leak. However, the odor added to propane chemicals known to the State gas may fade. -
Page 3: Unpacking
The Automatic Control System: This system 3. Check heater for any shipping damage. causes the heater to shut down if the flame If heater is damaged call DESA Heating, goes out. LLC at 1-866-672-6040 for replacement parts before returning to dealer. -
Page 4: Propane Supply
PROPANE SuPPLy You must provide propane gas and propane 1. The amount of propane gas in tank(s) tank(s). 2. The temperature of tank(s) Use this heater only with a propane vapor The chart below shows the minimum num- withdrawal supply system. See Chapter 5 ber of 100 b (45 kg) tanks needed to run of the Standard for Storage and Handling of the heater. -
Page 5: Operation
INStALLAtION Continued CONNECTING TO GAS SuPPLy 5. Check all connections for leaks. Apply mixture of liquid soap and water to gas WARNING: Test all gas piping joints. Bubbles forming show a leak that must be corrected. and connections for leaks after installation or servicing. - Page 6 OPERAtION Continued 4. Open propane supply valve on propane 200,000 BTu/HR HEATER tank(s) slowly. Note: If not opened slowly, TO START HEATER excess-flow check valve on propane tank 1. Before lighting pilot fully close the ball may stop gas flow. If this happens, you valve (turn knob fully clockwise).
-
Page 7: Storage
StORAgE 2. Before each use, check the soft "O" ring CAuTION: Disconnect heater seat at the bullnose of the POL fitting. If the "O" ring is cut, scuffed or otherwise from propane supply tank(s). damaged, replace the POL fitting with part number LPA4020. -
Page 8: Troubleshooting
tROuBLESHOOtINg WARNING: Never service heater while it is plugged in, connected to propane supply, operating or hot. Severe burns and electrical shock can occur. OBSERvED FAuLT REMEDy POSSIBLE CAuSE Burner fails to light 1. Open propane supply valve 1. Propane supply valve slowly closed on propane tank(s) 2. -
Page 9: Specifications
When calling please have your model and PARTS uNDER WARRANTy serial numbers of your heater ready. Contact authorized dealers of this product. If You can also visit DESA Heating, LLC’s web they can’t supply original replacement part(s), site at www.desatech.com. call DESA Heating, LLC at 1-866-672-6040. -
Page 10: Parts
PARtS MODELS TC106A, TC112A, TC113A, TC114A AND TC115A www.desatech.com 121512-01C... - Page 11 PARtS MODELS TC106A, TC112A, TC113A, TC114A AND TC115A This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 9 of this manual. NO. PART NO. DESCRIPTION qTy. 113785-01 Cap...
- Page 12 PARtS MODELS 200C, RCP200v(A), SPC-200C, TC107 AND TC200v(A) www.desatech.com 121512-01C...
- Page 13 PARtS MODELS 200C, RCP200v(A), SPC-200C, TC107 AND TC200v(A) This list contains replaceable parts used in your heater. When ordering parts, follow the instructions listed under Replacement Parts on page 9 of this manual. NO. PART NO. DESCRIPTION qTy. 113814-01 Pilot Assembly 113835-01 Hose/Regulator Assembly 113777-01 Burner Ring Assembly 113778-01 Ring Shield...
-
Page 14: Warranty
This is DESA Heating, LLC’s exclusive warranty, and to the full extent allowed by law; this express warranty excludes any and all other warranties, express or implied, written or verbal and limits he duration of any and all implied warranties, including warranties of merchantability and fitness for a particular purpose to one (1) year on new products and 30 days on factory recondi ioned products from the date of first purchase.
