Pen Specification - WizCom Technologies Quicktionary 3 Lite User Manual

Pen Specification

Feature
Display Type
Keypad
CPU
Memory
•
SRAM
•
ROM/RAM
Optical Scanner
Internal Power
Current Consumption
Size
Weight
Safety
Operating Temperature
Range
Description
Touch Screen Monochromatic FSTN
Resolution: 208 x 65
Size: 61mm x 20mm / 2.4" x .8"
•
Navigation Switch (Enter, Up,
Down, Left, Right)
•
Push Button - Power/ESC
ARM7 ASIC, 16 bit, 80 MHz
64 K x 16 bit
8 MB
•
128 pixels linear array image
sensor
•
400 DPI resolution
2 x 1.5V AAA Alkaline batteries
•
Idle mode - 42 mA
•
Max. (Peak) - 212 mA
L x W x H:
177.5 mm x 41.5 mm x 33 mm
(7" x 1.62" x 1/3")
•
77 grams (2.716 oz.) without
batteries
•
100 grams (3.527 oz.) with
batteries
•
CE
•
UL
•
FCC class B
0°C - 40°C
Pen Specification
21
