Accora CV1 Instruction Manual

COVID-19 Treatment Bed
INSTRUCTION MANUAL (CV1)
Welcome
The Covid-19 treatment bed (CV1) is a nursing bed classified as a Class 1 Medical
Device in accordance with the Medical Device Regulation 2017/745.
COVID-19 Treatment Bed (CV1)
Part No: NSB-0-CV1-000
Side Rails set (3 positions):
Head End, Middle, Foot End
(Option: SDR-0-CV1-000)
Footboard
Bed frame
Intended Use
The Covid-19 bed is intended for an adult population and can be used in all fixed and
temporary hospital and nursing environments.
WARNINGS
Always keep this manual available for future reference.
•
Only use compatible mattresses with this bed. Refer to specification for
•
dimensions.
A patient risk assessment must be carried out before both the bed
•
frame and / or the side rails are used.
Always fully decontaminate the bed in between users.
•
Always lock the folding arm of the legs in place by using the locking
•
ring to slide over the hinge at each end of the bed.
Care should be used when using the CPR Handle, there is a risk of
•
entrapment when the backrest falls to flat position.
Notice to user
If a serious incident occurs in relation to this medical device, affecting the user or the patient,
then the user or patient should report the serious incident to the medical device manufacturer
(or distributor) and, in the European Union, the user should also report the serious incident to
the Competent Authority in the member state where they are located.
IV Pole (Option: IVP-0-CV1-000)
Headboard
CPR Handle
Manual Backrest
Folding legs
(locked)
1
