Page 2: Safety Information
• Storage and Use The Confidence Olympic Power Tower is intended for use in clean and dry conditions. You should avoid storage in excessively cold or damp places as this may lead to corrosion and other related problems. Weight Limit 100kgs •... -
Page 3: Exploded View
Exploded View... - Page 5 (4)SUPPORT (2)BOTTOM (3)UPPER (1)MAIN BASE UPRIGHT FRAME UPRIGHT FRAME (6)BACKREST (5)CENTER (8)LAT BAR (7)DIP HANDLE ARM SUPPORT TUBE CROSS SUPPORT (9)STEEL PLATE (10)STEEL PLATE (50MM) (LONG) (13)HAND GRIP (11)BACKREST (12)ARM REST (14)LAT BAR FOAM (15)STEEL PLATE (16)FOAM PAD (18)25MM ROUND PAD (LONG) (38MM) (SHORT)
- Page 6 (25)M10 LOCK NUT (26)M10 WASHER (20)M10X75 BOLT (21)M10X65 BOLT (27)M8 WASHER (28)M10 ARC WASHER (22)M10X55 BOLT (32)M10X60 BOLT (23)M8X55 BOLT (33)M10X25 BOLT (24)M8X16 BOLT...
- Page 7 Assembly Instructions Step 1 PLACE RUBBER END CAP (30) ONTO BOTH ENDS OF MAIN BASE (01). CONNECT CENTER CROSS SUPPORT (05) TO CATCH MAIN BASE (01) BY USING BOLTS (20) STEEL PLATE (09) AND NUTS (25) WASHERS (26). SLIDE FOAM PAD (16) AND 25MM ROUND CAP (18) ONTO MAIN BASE (01) AS SHOWN.
- Page 8 Step 3 CONNECT UPPER UPRIGHT FRAME (03) INTO BOTTOM UPRIGHT FRAME (02) SLIDE FOAM PAD (14,16) ONTO LAT BAR (08) AS SHOWN. CONNECT LAT BAR (08) INTO THE UPPER UPR IGHT FRAME (03) BY US ING BOLTS (22) AND ARC WASHERS (28) AS SHOWN.
- Page 9 Step 4 CONNECT DIP HANDLE ARM (07) TO THE UPPER UPR IGHT FRAME (03) BY USING BOLTS (20) STEEL PLATE (10) AND WASHERS (26) NUTS (25). CONNECT BACKREST SUPPORT TUBE (06) ONTO DIP HANDLE ARM (07) BY USING BOLTS (32) STEEL PLATE (15) AND WASHERS (26) NUTS (25). INSERT HANDLE PIPE (31) INTO DIP HANDLE ARM (07) US ING BOLTS (33) AND WASHERS (26) AS SHOWN.
- Page 10 Step 5 ATTACH BACKREST (11) ONTO BACKREST SUPPORT TUBE (06) BY USING BOLTS (24) WASHERS (27). ATTACH ARM REST (12) ONTO DIP HANDLE ARM (07) BY US ING BOLTS (23) WASHERS (27) AS SHOWN.
- Page 11 UK & Europe www.shop247.co.uk Units 3 & 4 Lower Park Farm Storrage Lane Alvechurch, Worcestershire B48 7ER United Kingdom Telephone: 01527 598388 www.shop247.com East Coast 6965-K Northpark Blvd Charlotte NC 28216 Telephone 800 603 0004 West Coast 16 Sunset Way Henderson NV 89014 Telephone 800 603 0004...
