Ryobi RLM36B51SP Original Instructions Manual

Cordless lawn mower
Hide thumbs
Table of Contents

Advertisement

Quick Links

ORIGINAL INSTRUCTIONS
Cordless Lawn
Mower
RLM36B51SP

Advertisement

Table of Contents
loading

Related Manuals for Ryobi RLM36B51SP

Summary of Contents for Ryobi RLM36B51SP

  • Page 1 ORIGINAL INSTRUCTIONS Cordless Lawn Mower RLM36B51SP...
  • Page 2 Important! It is essential that you read the instructions in this manual before assembling, operating, and maintaining the product. Subject to technical modification.

  • Page 3: Intended Use

    Safety, performance, and dependability have the product. Local regulations may restrict been given top priority in the design of your the age of the operator. Children should be cordless lawn mower. adequately supervised to ensure that they do not play with the product. INTENDED USE ■...
  • Page 4 ■ Keep in mind that the operator or user ■ Do not place battery products or their is responsible for accidents or hazards batteries near fire or heat. This increases occurring to other people or their property. the risk of explosion and possibly injury. ■...

  • Page 5: Product Features

    ■ The product must be started with the user ■ Turn off the product, and remove the behind the handlebars in the operator isolator key and the battery pack. Make safety zone. Never start the product if: sure that all moving parts have come to a complete stop: ●...

  • Page 6: General Mowing Tips

    be released. Press the on/off switch to restart ■ If you are making a light cut and wish the product. for the grass cuttings to remain on the lawn, fit the mulching plug, and close the The battery pack has overheat protection. grass discharge chute cover to cover the Excessive temperatures will cause the battery discharge opening.

  • Page 7: Maintenance

    recommendations for blade bolt torque MAINTENANCE which can be found in the product specification table in this manual. WARNING CLEARING BLOCKAGES only original manufacturer’s replacement parts, accessories ■ Turn off the product, and remove the attachments. Failure to do so can cause isolator key and the battery pack.

  • Page 8: What's In The Box

    ■ Charger x 1 requirements. ■ Operator’s manual x 1 Do not expose the battery, NOTE: RLM36B51SP, battery battery compartment, or electric charger are sold seprately. component to rain, water, or liquids. Close the battery door SYMBOLS ON THE PRODUCT during use.

  • Page 9: Symbols In This Manual

    Insert the battery pack into the product. Make sure that the latch snaps in place, and that the battery pack is secured in the product before operating. Insert the isolator key. Pull and hold the bale against the handle, and push the start button to start the blades.
  • Page 10 WHAT’S IN THE BOX RLM36X51SP *Kit includes battery and charger. 15 mm...
  • Page 11 WHAT’S IN THE BOX RLM36B51SP 15 mm...

  • Page 12: Know Your Product

    KNOW YOUR PRODUCT Bale Quick-release fasteners 13. Isolator key Self-propel paddle Height adjustment lever 14. Front wheel Start button Rear wheel 15. Battery door Telescopic handle 10. Charger 16. Motor control cable Handle lock lever 11. Battery pack 17. Speed adjustment slider Grass catcher 12.
  • Page 13 GETTING STARTED GETTING STARTED GETTING STARTED GETTING STARTED GETTING STARTED Wear full eye protection, ear protection, non-slip heavy- Set the handle to the operating position. Make sure that Rotate the handle lock levers counterclockwise to unlock Fully extend the upper handle. Make sure that the upper handle is fully extended.
  • Page 15 OVERVIEW Using the product Installing the mulch plug p.15 p.16 Installing the grass catcher Adjusting the cutting height p.17 p.18...
  • Page 16 OVERVIEW Replacing the blade Cleaning the product p.19 p.21 Emptying the grass catcher Storing the product p.21 p.22...

  • Page 17: Operation

    OPERATION USING THE PRODUCT WARNING: Avoid holes, ruts, bumps, rocks, property stakes, or other hidden objects. WARNING: Do not operate the product on inclines greater than 15°. Mow across the face of slopes, never up and down. 1. Open the battery door. Insert the battery pack into the product.
  • Page 18 OPERATION INSTALLING THE MULCH PLUG 1. Remove the metal frame lock of the grass catcher from the slots on the product. Remove the grass catcher from the product. 2. Insert the metal frame lock of the mulching plug into the slots on the mower.

  • Page 19: Installing The Grass Catcher

    OPERATION INSTALLING THE GRASS CATCHER 1. Lift the handle of the mulch plug, and pull out the plug from the rear discharge chute. 2. Insert the metal frame lock of the grass catcher into the slots on the product. Align the grass catcher with the rear discharge chute, and make sure that the catcher fully covers the chute.

  • Page 20: Maintenance

    MAINTENANCE ADJUSTING THE CUTTING HEIGHT To adjust the deck height, pull the height adjustment lever towards the wheel, then raise or lower the deck to the preferred height. Make sure that the handle is always secured into one of the seven height slots. NOTE: The cutting height can be adjusted to 7 positions.

  • Page 21: Replacing The Blade

    MAINTENANCE REPLACING THE BLADE WARNING: Keep bare hands away from blades. Blades continue to rotate after the motor is switched off. Remove the isolator key before maintenance. Use heavy-duty gloves when replacing the blades. NOTE: For a quality finish to your lawn, replace the mowing blade every season.
  • Page 22 MAINTENANCE 5. Remove and properly dispose of the blade. 6. Install the new blade. 7. Hand-tighten the blade nut, then use a 15 mm spanner to turn the nut 7 turns or with 35~40 Nm of torque. Blade bolt tightening torque (35~40 Nm)

  • Page 23: Cleaning The Product

    MAINTENANCE CLEANING THE PRODUCT After each use, clean the product with a soft, dry cloth, or cleaning brush. WARNING: Do not use water to clean the product. EMPTYING THE GRASS CATCHER 1. Remove the grass catcher. 2. Empty the grass clippings into a bin.

  • Page 24: Storing The Product

    STORAGE STORING THE PRODUCT 1. Open the battery door. Remove the isolator key and the battery pack. Close the battery door. 2. Remove the metal frame lock of the grass catcher from the slots on the product. Remove the grass catcher from the product.
  • Page 25 STORAGE 5. Rotate the handle lock levers clockwise to lock the upper handle. 6. Pull out the quick-release fastener and turn it 90°. Fold down the handle. 7. Fold the grass catcher, and place it on top of the product. 8.

  • Page 26: Product Specifications

    PRODUCT SPECIFICATIONS BATTERY AND CHARGER Model RLM36X51SP RLM36B51SP Product name Cordless Lawn Mower Battery pack BPL3660D not included Model RLM36X51SP / Weight 2 kg RLM36B51SP Charger BCL3660F not included Rated voltage 36 V d.c BPL3620D, BPL3626, Width of cut 51 cm...
  • Page 28 Techtronic Industries Australia Pty Ltd 31 Gilby Road, Mount Waverley, VIC 3149, Melbourne, Australia Techtronic Industries N.Z. Limited RYOBI is a trademark of Ryobi Limited, Unit C, 70 Business Parade South, and is used under license. Highbrook, Auckland 2013, New Zealand ©...
