amberley spindle chair
457/3760
- Please keep for future reference
Dimensions
Width - 53.5cm
Depth - 51cm
Height - 86.5cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 640 0800
Issue 1 - 20/06/16
Advertisement
Table of Contents
Related Manuals for Heart of House Amberley spindle chair 457/3760
Summary of Contents for Heart of House Amberley spindle chair 457/3760
- Page 1 amberley spindle chair Assembly Instructions 457/3760 - Please keep for future reference Dimensions Width - 53.5cm Depth - 51cm Height - 86.5cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 640 0800 Issue 1 - 20/06/16...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, this recommend the the following pages.
- Page 3 Components - Parts If you have damaged or missing components, call the Customer Helpline: Argos = 0345 640 0800 Please check you have all the parts listed below Note: The quantities below are the correct amount to complete the assembly of 1 chair. Seat Frame Left Leg Frame (FL) Right Leg Frame (FR)
- Page 4 Assembly Instructions Step 1 Attaching stretcher Attach the stretcher into the holes on left leg frame and right leg frame as shown. Place the barrel nuts into the holes on the stretcher. Then align the holes on the barrel nut by turning it using a crosshead screwdriver to be able to fix the bolts...
- Page 5 Assembly Instructions Step 3 Attaching foot pads Remove backing from foot pads and carefully position on the bottom of the leg frames as shown. Step 4 Attaching wood caps Carefully turn the chair upright and place the wood caps into the holes on the leg frames as shown.
