Mean Green ReVolt Series Manual

48”/52” dual drive walk behind mowers

Advertisement

Quick Links

GENERAL INFORMATION
This manual applies to the following Mean Green Products equipment lines:
Mean Green Mowers – ReVolt 48"/52" Dual Drive Walk Behind
To the new owner
The purpose of this manual is to assist owners and operators in maintaining and operating the
mower. Please read it carefully; information and instructions furnished can help you achieve
years of dependable performance. It is the owner's responsibility to make certain that the
operators and mechanics read and understand this manual and all decals before operating this
machine. It is also the owner's responsibility to make certain that the operators and mechanics
are qualified and physically able individuals, properly trained in the operation of this equipment.
All operator and mechanics must become familiar with the safe operation of the equipment,
operator controls and safety signs. Never let children or untrained people operate or service the
equipment. Local regulations may restrict the age of the operator. The owner/user can prevent and
is responsible for accidents or injuries occurring to themselves, other people or property.
Using this manual
General operation, adjustment and maintenance guidance is outlined for both the experienced and
novice Mean Green Mower user. Operating conditions vary considerably and cannot all be
addressed individually. Through experience, however, operators should find no difficulty in
developing good operating skills suitable to most conditions. Directions used in this manual, for
example RIGHT or LEFT, refer to directions when seated on the mower/standing facing forward,
unless otherwise stated. Photographs and illustrations used were current at the time of printing,
but subsequent production changes may cause your machine to vary slightly in detail. Mean
Green Products reserves the right to redesign and change the machine as deemed necessary,
without notification. If a change has been made to your machine which is not reflected in this
owner's manual, or the parts manual, see your Mean Green Products dealer for current
information and parts.
Warranty registration
The Owner must register the unit by filling out the Warranty Registration Form, provided in the
owner's packet, to validate your warranty protection. As the new equipment owner, you are
expected to see that this is done at the time of delivery. If using the Warranty Registration Form,
it MUST be completed and signed by the authorized dealer and original purchaser.
Be sure to register the mower plus each attachment that displays a model and serial identification
number plate with Mean Green Products.
Any unauthorized modification, alteration, or use of non-approved attachments
IMPORTANT:
voids the warranty and releases Mean Green Products from any liability arising from subsequent
use of this equipment.
Model and serial number
The mower serial number is found on the serial identification plate located on the inside left rear
wall of the battery/electronics compartment of the mower. The model is the type of Mean Green
Mower purchased i.e. WBX-33HD, SK-48, CXR-52. The serial numbers and model are required
on the Warranty Registration form. They will also assure you of the correct service parts when
replacement becomes necessary.
Parts and service
All warranty repair and service must be handled through an
authorized Mean Green Products dealer. Arrangements should be made
through your local service center or Mean Green Products LLC.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ReVolt Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mean Green ReVolt Series

  • Page 1 The mower serial number is found on the serial identification plate located on the inside left rear wall of the battery/electronics compartment of the mower. The model is the type of Mean Green Mower purchased i.e. WBX-33HD, SK-48, CXR-52. The serial numbers and model are required on the Warranty Registration form.
  • Page 2 SAFETY PRECAUTIONS This safety alert symbol is used to call attention to a message intended to provide a reasonable degree of PERSONAL SAFETY for operators and other persons during the normal operation and servicing of this equipment. DANGER – denotes immediate hazards which WILL result in severe personal injury or death.
  • Page 3 DANGER: Rotating blades! (fig.1A) * Keep shields and covers in place while machine is in operation * Keep hands, feet and clothing away from rotating blades DANGER: Safety Precautions!: (fig.2A) Read Owner’s Manual Before Operation Keep Hands, Feet, And Clothing Away From Rotating Blades Maintain Safe Distance From People And Pets Roll Over Warning –...
  • Page 4 Warning: Keep hands & feet away when mower is in operation! (fig.1B) *Fall Hazard. Keep Hands & Feet Away When Mower Is In Operation! Important: Mower Control Panel (1C) (May vary slightly due to model and year of manufacture)
  • Page 5 A.Master B.Battery C.Drive D. Aux E. Hi/Low F. Deck G. Steering Power Capacity Speed ON/Off Blade Speed Blade Trim Lever Ignition Indicator Control On/Off Switch Switch Operator Presence Safety Levers Engaged Fig. 1H: Operator Presence Safety Levers – (OPS) - 2 each large green levers on right left side of handle bars closest to operator.
  • Page 6: Steering Trim Lever

    OFF position and then to the ON position. If FAULT continues: Call your Mean Green Mowers Dealer Immediately! ***SEE Appendix Smartec pages 8-12 for detailed Battery Capacity Indications, Troubleshooting and Information Guide**** IMPORTANT: When battery voltage becomes low, the mower drives will go into “creep”...
  • Page 7 Fig. 1F: Deck Blades ON and OFF Switch: This switch engages the deck blade motors. Pull the switch up to engage blades and push switch down to disengage blade motors. IMPORTANT: ONLY engage Deck Blades when throttle lever is in the neutral position. NEVER engage blades when moving!!!! Fig.
  • Page 8 ↑ Manual Drive Lever Engaged for driving. (handles facing down) Manual Drive Lever Dis-engaged for towing/pushing. (handles crossed) OPERATION Safe Operating Practices This product is capable of amputating hands and feet and throwing objects. Always follow all safety instructions to avoid serious injury or death. Operation Evaluate the terrain to determine what accessories and attachments are needed to properly and safely perform the job.
  • Page 9 right rear battery box compartment). Always wear adequate ear protection, such as earplugs, when operating this equipment as prolonged exposure to uncomfortable or loud noises can cause impairment or loss of hearing. Do not wear radios or music headphones while operating the machinery. Safe operation requires your full attention.
  • Page 10 Never stop suddenly while backing down slopes. This action may result in a reaction of the machine that can cause serious physical injury. The Mean Green Mower is capable of operating horizontally (traverse) on moderate slopes. When operating on slopes up to 20 degrees, be aware of any conditions that may cause the mower drive tires to lose traction resulting in a possible loss of control of the machine.
  • Page 11: Operator Controls

    injured or interfere with safe machine operation. Children who have been given rides in the past may suddenly appear in the mowing area for another ride and be run over or backed over by the machine. Never allow children to operate the machine. Use care when approaching blind corners, shrubs, trees, the end of a fence or other objects that may obscure vision.
  • Page 12 To place the drive levers in the “forward” position, slightly squeeze the drive levers while placing thumbs on the outer thumb lobe of the neutral lock latches (or the index finger on the front lobe) and rotate them from under the drive levers. Slowly and carefully release the drive levers. To place the drive levers in the “reverse”...
  • Page 13 Fig. 6 1. Deck support pin 2. Cutting Height The cutting height of the mower deck is adjusted from 1 1/2 to 5.0 inches in ½ inch increments. 1. Stop the machine and move the drive levers to the neutral locked position. 2.
  • Page 14: Blade Warning Light System

    Discharge Chute – (Fig. 3C) Found on right side of chassis. WARNING: Always keep Discharge Chute in the down position when mowing and blades are moving. Warning: Keep all shields in place at all times to prevent injury! DO NOT operate mower without discharge chute or other safety devices in place &...
  • Page 15 If the operator continues to run the mower in YELLOW with longer, taller, wet grass, the lights will turn RED. RED lights indicate the blade tip speed and power is at the lowest point and is on the verge of shutting down. Continuing to run in RED will result in your blade or blades shutting down completely, requiring the operator to turn Deck Blades Off and then On to reset the PTO.
  • Page 16: Maintenance & Adjustments

    when handling blades. Always check for blade damage if mower strikes a rock, a branch or another foreign object during mowing! Direct grass discharge to right (with side discharge models), away from un-mown area. Select a mowing pattern that directs grass discharge towards the outside, not towards center, of mowing area.
  • Page 17 Exercise caution when working under the deck as the mower blades are extremely sharp. Wear gloves and use extra caution when servicing them. Use only genuine Mean Green Mower parts to ensure that original standards are maintained. Always remove key and disconnect battery cables by pulling disconnect battery cables by pulling LARGE exterior battery quick disconnect handle upward to remove &...
  • Page 18: Lubrication

    Lug nuts only - It is recommended that these be checked after the first 2 hours of operation, initially, every 100 hours and following removal for repair or replacement. Tires (Every 40 hours) It is important for level mowing that the rear tires have the same amount of air pressure.
  • Page 19: Electrical System Safety

    If they become damaged, repair or replace immediately. Never modify or remove safety devices. Electrical System Information The Mean Green Mower is powered by a 48 volt electrical system. It consists of the following components: DWBX-33HD Walk Behind Mower 1.
  • Page 20 WARNING: Charge only with a Mean Green Mower approved charger. Do not use battery chargers other than those recommended by Mean Green Products. Incorrect battery charging will void warranty and can lead to equipment damage, fire, serious injury or death.
  • Page 21 WARNING: Batteries should not be removed from unit unless repair is needed. Use EXTREME Caution When Lifting Batteries Out Of Mower Unit. Serious Injury to operator and/or Battery Could Occur If Battery Is Mishandled or Dropped!! Never Use An Extension Cord To Recharge Mower WARNING: Chargers include: LEMC3548 (Standard Charger) The charger will charge from a Standard 110-120V outlet and charging at 25 amps-...
  • Page 22 ***Always refer to the Charger Manual for more information about the proper operation of the charger or call Mean Green Customer Service at: 513-738-4736 Charging Recommendations SEE Lithium Energy Module Care Page 24...
  • Page 23 Mower will not start Check that key is in the ON position. Check all battery connections in back battery compartment. Make sure batteries are charged. Mower blades stop due to low charge & mower will not move Turn blades off, turn key to OFF position and then back to ON. (this resets computer) If manual operation is needed to return to charging station or to move mower without battery power, pull emergency manual drive brake...
  • Page 24 3. For charging, charge all modules while connected together. Each module can be charged separately every 50-100 charging cycles or when total run time is reduced.* Consult Mean Green Service Department for complete instructions.* 4. Before connecting modules together in parallel, please make sure the modules have the SAME SOC (state of charge or voltage).
  • Page 25: Information
