Y-SERIES HYDRAULIC REAR TINE TILLER
CONGRATULATIONS!
You are now the proud owner of the BARRETO Model 916/918 Y-Series tiller. Please take a
moment of your time to look over the following information. Familiarize yourself with the tiller, its
characteristics, and method of operation. Pay particular attention to the safety and operating
instructions.
If you have any questions or need any replacement parts in the future, please contact us at your
convenience. Our toll-free phone number, fax and email are listed below and parts may be ordered
through any of these methods.
THANK YOU for your patronage and confidence in BARRETO equipment.
Barreto Manufacturing, Inc.
Innovative Equipment Engineered to Last
66498 Hwy 203, La Grande, OR 97850
(800) 525-7348 (541) 963-7348
FAX (541) 963-6755
E-Mail:
info@barretomfg.com
Web Site:
http://www.barretomfg.com
Machine Identification Record
Barreto Customer number
Machine model number
Machine serial number
Engine manufacturer
Engine model number
Engine serial number
916 - 918 Y Series Owner's/Operator's Manual
MODEL E916/918
OWNER'S/OPERATOR'S MANUAL
________________________
________________________
________________________
________________________
________________________
________________________
THE
8/30/18
Page 1 of 18
Advertisement
Table of Contents
Related Manuals for Barreto Y Series
Summary of Contents for Barreto Y Series
- Page 1 OWNER’S/OPERATOR’S MANUAL CONGRATULATIONS! You are now the proud owner of the BARRETO Model 916/918 Y-Series tiller. Please take a moment of your time to look over the following information. Familiarize yourself with the tiller, its characteristics, and method of operation. Pay particular attention to the safety and operating instructions.
-
Page 2: Table Of Contents
HONDA GX270 SCHEMATIC HYDRAULIC SCHEMATIC SPECIFICATIONS TROUBLESHOOTING LUBRICATING INSTRUCTIONS OPERATING INSTRUCTIONS SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS OVERVIEW LOCATING UNDERGROUND UTILITIES WORKSITE ASSESSMENT CONTACT WITH UNDERGROUND UTILITIES INDEX _________________________________________________________________ 18 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 2 of 18... -
Page 3: Tiller Assembly Instructions
1. Remove the tiller from shipping crate. Please inspect immediately for any damage and notify the shipping company and Barreto Manufacturing, Inc. right away if any is found. 2. Fasten the handle bar to the tiller using the 1/2" x 3" bolt supplied. -
Page 4: Barreto Warranty
Engines, engine accessories, batteries and tires are warranted by the original manufacturers and are not covered by the Barreto Equipment Warranty. Wear parts such as tiller tines, sprockets, bearings, trencher chain parts including teeth, stump grinder cutting teeth & holders, etc. -
Page 5: Hour Meter
Your DGI® hour meter is pre-set at the DGI® factory to go into Flash Alert mode at 25-hour intervals. Although the engine manufacturer does not require changing engine oil this often, due to heavy-duty use and extreme conditions inherent to tiller use, Barreto Manufacturing strongly recommends frequent oil changes. -
Page 6: Honda Gx270 Schematic
ELECTRICAL SCHEMATIC - HONDA GX270 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 6 of 18... -
Page 7: Hydraulic Schematic
HYDRAULIC SCHEMATIC 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 7 of 18... -
Page 8: Specifications
HOUR METER Standard HYDRAULIC SYSTEM Reservoir Capacity 7.2 U.S. gallons (27.25 liters) OPERATIONS Ground Speed, Low Speed 50 FPM (15.24 m/min) Ground Speed, High Speed 200 FPM (60.96 m/min) 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 8 of 18... - Page 9 3. Tilling depth too great for Shut OFF engine and lower depth bar to raise soil conditions. the tines, decreasing tilling depth. 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 9 of 18...
-
Page 10: Troubleshooting
Barreto Manufacturing, Inc. * Recommended oil is CHEVRON 1000 or equivalent hydraulic oil with anti-foaming and anti-wear additives. Hydraulic oil should have an ISO/AW rating of 68. 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 10 of 18... -
Page 11: Lubricating Instructions
Move the WHEEL DRIVE lever to the right until the desired wheel speed is reached. Under most conditions, at least two passes must be made. For deeper tillage, move the depth bar up one hole at a time. 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 11 of 18... -
Page 12: Safety Instructions
12. Hydraulic oil is under extreme pressure and can get under skin and burn or poison. Check for leaks with cardboard. 13. Muffler and engine get hot enough to cause serious burns. Do not touch until cool. 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 12 of 18... -
Page 13: Safety Instructions Overview
NOTE 1 - The sum of a measured noise emission value and its associated uncertainty represents an upper boundary of the range of values which is likely to occur in measurements. Values listed above are rounded to the nearest decibel according to ISO 4871 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 13 of 18... - Page 14 WARNING: Muffler and engine get hot enough to cause serious burns. For the safety of yourself and others, allow enough time for the engine, muffler, and the hydraulic fluid to cool 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 14 of 18...
-
Page 15: Locating Underground Utilities
WARNING: If tiller should fall it would crush anybody under it. We recommend having a fire extinguisher suitable for petrol fires in the operating area. Attachments can change the center of mass and machine operations. Use only Barreto attachments. DETERMINE LOCATION OF UNDERGROUND UTILITIES OSHA CFR 29 1926.651 requires that the estimated location of underground utilities be determined before... -
Page 16: Worksite Assessment
This is intended for your safety and must be maintained in good functional condition. Contact your dealer or the factory if anything on the tiller does not function properly 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18... -
Page 17: Contact With Underground Utilities
Fiber optic cables: If you think that you may have severed a fiber optic cable, do not touch or even look at the ends of it. WARNING: Fiber optic cables convey laser light that can injure your eyesight. Call 911 for help. 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 17 of 18... -
Page 18: Index
UNDERGROUND UTILITIES, 15, 16, 17 HYDRAULIC OIL FILTER, 3 WARRANTY, 3, 4 HYDRAULIC PUMP, 4, 9, 10 WHEEL DRIVE, 11, 16 HYDRAULIC SCHEMATIC, 7 WORK SITE, 16, 17 916 - 918 Y Series Owner’s/Operator’s Manual 8/30/18 Page 18 of 18...
