VI. TESTING
In order to test the system and its functions, Navigate to the 3100 Manual Control page and
begin a device Self-Test. This will simulate the sensor going into Low, Mid then High alarm.
As the sensor goes through these alarms the 3500 screen should show the sensor going
into alarm and respond accordingly (turn fan on/siren/lights/etc....) depending on the user's
system settings and what the response to those alarms.
To keep an alarm on longer than the Self-Test runs or to leave an alarm on indefinitely, this
can be done through the SEC 3500 OI. Navigate to the Relay Assignment page and set the
desired relay to On. This will keep the alarm active until this is changed back.
