Item
Model
40845
HDE7136
40846
HDE7148
40847
HDE7160
40855
HDE8136
36" Curved Countertop Heated Display
40883
HDE8336 36" Curved
40856
HDE8148
48" Curved Countertop Heated Display
40884
HDE8348 48" Curved Self-Serve Countertop Heated Display
40857
HDE8160
60" Curved Countertop Heated Display
40885
HDE8360 60" Curved
40865
HDE8236
40890
HDE8436 36" Cubed
40866
HDE8248
40891
HDE8448 48" Cubed
40867
HDE8260
40892
HDE8460 60" Cubed
Thank you for purchasing this Vollrath equipment. Before operating the equipment, read and familiarize yourself with the following operating
and safety instructions. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. Save the original box and packaging. Use this
packaging to ship the equipment if repairs are needed.
Description
36" Curved Drop-In Heated Display
48" Curved Drop-In Heated Display
60" Curved Drop-In Heated Display
Countertop Heated Display
Self-Serve
Countertop Heated Display
Self-Serve
36" Cubed Countertop Heated Display
Countertop Heated Display
Self-Serve
48" Cubed Countertop Heated Display
Countertop Heated Display
Self-Serve
60" Cubed Countertop Heated Display
Countertop Heated Display
Self-Serve
Operator's Manual
HEATED DISPLAY CABINET
Voltage
Amps
120V
5.6 Amps
120V
5.9 Amps
120V
6.3 Amps
120V
5.6 Amps
120V
5.6 Amps
120V
5.9 Amps
120V
5.9 Amps
120V
6.3 Amps
120V
6.3 Amps
120V
6.1 Amps
120V
6.1 Amps
120V
6.6 Amps
120V
6.6 Amps
120V
7.1 Amps
120V
7.1 Amps
ENGLISH
Watts
Plug
670 Watts
5-15P
710 Watts
5-15P
750 Watts
5-15P
670 Watts
5-15P
670 Watts
5-15P
710 Watts
5-15P
710 Watts
5-15P
750 Watts
5-15P
750 Watts
5-15P
730 Watts
5-15P
730 Watts
5-15P
790 Watts
5-15P
790 Watts
5-15P
850 Watts
5-15P
850 Watts
5-15P
Item No. 2350050-1 en Rev 06/14
