2.16 Re-Access the Web GUI via CLI Commands
Yo u ca n u se t h e fo llo w in g CLI co m m a n d s t o r e ga in w e b GUI a cce s s ( e .g.
a ft e r a So ft w a r e Up lo a d ) .
# show ip int brief
Vlan Address Method Status
---- -------------------- -------- ------
# conf term
(config)# int vlan 1
(config-if-vlan)# ip addr 192.168.1.110 255.255.255.0
(config-if-vlan)# end
# show ip int brief
Vlan Address Method Status
---- -------------------- -------- ------
1 192.168.1.110/24 Manual UP
#
Yo u ca n t h e n a cce s s t h e w e b GUI v ia t h e IP a d d r e s s a n d n e t m a s k e n t e r e d
( e .g., 1 9 2 .1 6 8 .1 .1 1 0 a n d 2 5 5 .2 5 5 .2 5 5 .0 in t h e e xa m p le a b o v e ) . Se e t h e CLI
Re fe r e n ce m a n u a l fo r d e t a ils.
2.17 Switching MGMT / PORT 1 Modes
Th e LIB-3 0 4 / LIB-3 0 6 MGMT / PORT 1 is a n o r m a l d a t a p o r t , b u t b y
d e fa u lt it w ill p la ce d in a se p a r a t e p r iv a t e VLAN t h a t y o u ca n r e m o v e . Yo u
ca n e n a b le o r d is a b le o u t -o f-b a n d m a n a ge m e n t o n Po r t 1 . Po r t 1 ca n b e
o p t io n a lly co n figu r e d t o su p p o r t e it h e r o u t -o f-b a n d m a n a ge m e n t o r it ca n
b e u s e d a s a n o r m a l d a t a UNI/ NNI p o r t .
By d e fa u lt , Po r t 1 is e n a b le d a s a m a n a ge m e n t p o r t w it h a d e fa u lt IP
( 1 9 2 .1 6 8 .0 .1 / 2 4 ) a n d s u b n e t m a sk . By d e fa u lt , a ll p o r t s a r e VLAN u n a w a r e
a n d m e m b e r s o f VLAN 1 a n d Pr iv a t e VLAN 1 .
To co n figu r e Po r t 1 a s a n o r m a l fr o n t p a n e l d a t a p o r t , u s e t h e s e t t in gs
b e lo w .
No rm al fro n t p o rt:
interface GigabitEthernet 1/1
!
LIB-3 0 4 & LIB-3 0 6 In st a lla t io n Gu id e
DOC IG-3 0 X-V1 .2
27 of 37
