Osmond Ergonomics Axia Profit Instructions

1. SEAT HEIGHT
Lift the middle lever on the right or
left-hand side and take your weight
off the seat to raise the height.
Remain seated to lower the height.
Release the lever to lock the seat
height.
4. BACK HEIGHT
Twist the left and right knob on the
back mechanism in the same direction
simultaneously to adjust the back
height.
AXIA PROFIT - INSTRUCTIONS
2. SEAT TILT ADJUSTMENT AND
FREE FLOAT ACTIVATION
Lift the front lever on the right or
left-hand side to release the seat tilt
lock. Tilt the seat while seated.
Release the lever to lock the seat tilt.
Or push down the front lever to
activate the seat rock. Lift the lever
back up to lock the seat in any
5. SEAT DEPTH
Ensure the seat is tilted fully forward.
Pull out either the left or right lever at
the back corner of the seat and slide
the seat forward or backward. Release
the lever to lock the seat depth.
position.
3. FREE FLOAT TENSION
Twist the knob on the underside of
the chair while in free float mode to
adjust the tension of the rocking
motion. Clockwise increases the
tension, anticlockwise reduces the
tension.
6. ARM REST (IF FITTED) WIDTH
Loosen the screw at the base of the
arm to loosen the arm width lock.
Slide the whole arm in or out. Tighten
the screw back again to lock the arm.
Repeat for the other arm.
