Programmable electronic digital thermostat

Advertisement

Quick Links

Operator: Save these instructions for future use!
FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY
BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE
PERSONAL INJURY AND/OR PROPERTY DAMAGE.
Your new White-Rodgres 7-Day Digital Thermostat uses the
technology of a solid-state microcomputer to provide precise
time/temperature control. This thermostat offers you the fl exibility
to design heating and cooling programs that fi t your needs.
Features:
• Separate program for each day of the week with four separate
time/temperature periods per day
• Simultaneous heat and cool program storage
• Preprogrammed temperature control
• Backlit display
• LCD continuously displays setpoint, and alternately displays
time and room temperature
This thermostat is intended for use with a low voltage system;
do not use this thermostat with a line voltage system. If in doubt
about whether your wiring is millivolt, line, or low voltage, have it
inspected by a qualifi ed heating and air conditioning contractor
or electrician.
Do not exceed the specifi cation ratings.
All wiring must conform to local and national electrical codes
and ordinances.
This control is a precision instrument, and should be handled
carefully. Rough handling or distorting components could cause
the control to malfunction.
CAUTION
!
To prevent electrical shock and/or equipment damage,
disconnect electric power to system at main fuse or
circuit breaker box until installation is complete.
ELECTRICAL DATA
Electrical Rating:
8 to 30 VAC 50/60 Hz. or D.C.
0.05 to 1.0 Amps (Load per terminal)
1.5 Amps Maximum Total Load (All terminals combined)
THERMAL DATA
Setpoint Temperature Range:
45°F to 90°F (7°C to 32°C)
Operating Ambient Temperature Range:
32°F to 105°F
Operating Humidity Range:
0 to 90% RH (non-condensing)
Shipping Temperature Range:
-4°F to 149°F
Programmable Electronic Digital Thermostat
INSTALLATION AND
OPERATION INSTRUCTIONS
• Temperature override until next program period
• Manual program override (HOLD temperature)
• Temporary HOLD
• °F/°C convertibility
• Temperature range 45° to 90°F
• RC, RH, C, W, Y, G, O and B terminals
• Optional C terminal (Dual Power option)
• B and O terminals for single stage heat pumps (no auxiliary
heat) or damper operation
• Program storage in case of power loss
• 2 "AA" alkaline batteries included
WARNING
!
Do not use on circuits exceeding specifi ed voltage.
Higher voltage will damage control and could cause
shock or fi re hazard.
Do not short out terminals on gas valve or primary
control to test. Short or incorrect wiring will damage
thermostat and could cause personal injury and/or
property damage.
Thermostat installation and all components of the
system shall conform to Class II circuits per the NEC
code.
APPLICATIONS
For use with:
• Standard heat/cool or heat only systems
• Electric heat systems
• Gas or oil fi red systems
• Gas systems with intermittent ignition devices (I.I.D.)
and/or vent dampers
• Hydronic (hot water or steam) systems
• Single-stage heat pump systems (no auxiliary heat)
• Millivolt systems
DO NOT USE WITH:
• Multi-stage systems
• Systems exceeding 30 VAC and 1.5 amps
• 3-wire zoned hydronic heating systems
875
DESCRIPTION
PRECAUTIONS

SPECIFICATIONS

PART NO. 37-6910A
0806

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 875 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for White Rodgers 875

  • Page 1: Specifications

    Operator: Save these instructions for future use! FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL INJURY AND/OR PROPERTY DAMAGE. Your new White-Rodgres 7-Day Digital Thermostat uses the technology of a solid-state microcomputer to provide precise time/temperature control.
  • Page 2: Check Thermostat Operation

    INSTALLATION REMOVE OLD THERMOSTAT 1. Shut off electricity at the main fuse box until installation is complete. Ensure that electrical power is disconnected. 2. Remove the front cover of the old thermostat. With wires still attached, remove wall plate from the wall. If the old thermostat has a wall mounting plate, remove the thermostat and the wall mounting plate as an assembly.
  • Page 3: Wiring Diagram

    C ‡ Heating Relay System NOTE For 2-wire Heat only, attach to RH and W Figure 2. Typical wiring diagram for heat only, 3-wire, single transformer systems JUMPER C ‡ Cooling System Relay Figure 3. Typical wiring diagram for cool only, 3-wire, single transformer systems NOTE RED jumper wire (provided with thermostat) must be connected between thermostat RH and RC terminals...
  • Page 4: Operation

    OPERATION Before you begin programming your thermostat, you should be familiar with its features and with the display and the location and operation of the thermostat buttons. Your thermostat consists of two parts: the thermostat cover and the base. To remove the cover, pull it straight out from the base.
  • Page 5: Operating Features

    Step Press Button(s) Displayed (Factory Default) Press PRGM and RUN HOLD* HOLD* HOLD* HOLD* HOLD* HOLD* HOLD* * Press HOLD to advance to next item or TIME to move backwards to previous item 4) Select Energy Management Recovery OFF or ON – (not available on all Thermostats) Energy Management Recovery (EMR) causes the thermostat to start heating or cooling early to make the building temperature reach the...
  • Page 6: Enter Heating Program

    Planning Your Program Look at the factory preprogrammed times and temperatures shown in the sample schedule. If this program will suit your needs, simply press the RUN button to begin running the fac- tory preset program. If you want to change the preprogrammed times and tempera- tures, follow these steps.
  • Page 7: Reset

    NOTE If you are programming your thermostat for the fi rst time and you want programming for all days of the week to be the same as Monday’s program, press RUN or HOLD at this point, and proceed to Enter Cooling Program. (This simplifi ed COPY DAY feature only works the fi...
  • Page 8 TROUBLESHOOTING Symptom Possible Cause No Cool 1. SYSTEM Switch not set to COOL 2. Loose connection to thermostat or system. 3. Cooling System requires service or thermostat Heat, Cool or Fan Runs Constantly. 1. FAN Switch set to Fan ON. 2.
