  • Page 1 Installation and Programming manual EN 50131-1 EN 50131-6 EN 50130-4 EN 50130-5 SmartLevel Power supply stations Installation and programming manual...
  • Page 2 24 months. As INIM Electronics s.r.l. does not install this product directly, and due to the possibility that it may be used with other equipment not approved by Us;...
  • Page 3: Table Of Contents

    Installation and programming manual Table of contents About this manual ..... 5 Terminology ....... Graphic conventions .
  • Page 4 Power supply stations...
  • Page 5: About This Manual

    Installation and programming manual ABOUT THIS MANUAL MANUAL CODE DCMIINIESPS12 REVISION 2.60 Terminology DEVICE If not otherwise specified, refers to the SmartLevel power-supply station, described in Chapter 2 - Device description. CONTROL PANEL Refers to the SmartLiving intrusion control panel of the security system. LEFT, RIGHT, Directions as seen by the operator when directly in front of the mounted device.
  • Page 6: Chapter 1 General Information

    Web: www.inim.biz The persons authorized by the manufacturer to repair or replace the parts of this system, hold authorization to work on INIM Electronics brand devices only. Description of the product and various models The SmartLevel power-supply station is a switching power-supply module capable of generating 12V nominal current to the system loads and the lead battery.
  • Page 7: The System Parts

    Installation and programming manual The system parts SMARTLEVEL This is the board which, starting from the nominal voltage stabilized at 12V MOTHER BOARD supplies the voltage to the power outputs it is equipped with, which have grade 2 or lower security rating. The board communicates over the I-BUS line with the LIVPWR100 board in order to monitor its operating status and the status of the power supply module.
  • Page 8: Chapter 2 Device Description

    Power supply stations Chapter 2 DEVICE DESCRIPTION Inside the box The package contains the SmartLevel power supply station with its components: • metal enclosure with the following devices, already mounted and connected: •• SmartLevel mother board (IN088) •• Switching power supply ••...
  • Page 9: Description And Technical Specifications

    Installation and programming manual •• T8, output that will signal faults on the power-supply module of the SmartLevel power-supply station •• T9, output that will signal the loss of communìcation between the LIVPWR100 board and the power-supply unit or between the SmartLevel motherboard and the LIVPWR100 board •...
  • Page 10 Power supply stations SPS12060XG3 Table 2: Description of parts Metal enclosure Mother board LIVPWR100 board Switching power supply Connection terminal board to mains 230V~ Mains cable entry Ground connection screws Frontplate earth wire Wires between switching-power supply and station Thermal probe Anchor-screw locations for the metal backbox Dislodgement tamper...
  • Page 11 Installation and programming manual Motherboard Table 3: Mother board (IN088) Terminals Control panel to PC serial cable connector Blue and yellow activity LEDs Dislodgement microswitch connector* Open-enclosure microswitch connectors* Open-panel tamper microswitch Power supply cable connector Table 4: Mother board - terminal board icon/identifier description 6-7-8-9...
  • Page 12: Chapter 3 Installation

    Power supply stations Chapter 3 INSTALLATION Wall-mounting Using the backbox, mark the anchor screw (table 2, K) and the tamper screw (table 2, L) locations on the wall. Be sure not to drill in the vicinity of electrical wiring or plumbing/gas pipes, etc. Insert the screw anchors (recommended size 6mm).
  • Page 13: Connecting The Backup Battery

    Installation and programming manual Ensure that terminal “ ” of the power supply module [F] and the front- plate [G] are connected to earth. SPS12060XG3 SPS12060XG3 AC Input 230V ~ 50/60 Hz Connecting the backup battery Note The connection of the backup battery [A] must be done after completion of the primary power source connection (paragraph 3-2 Connecting the Mains power supply) and after powering up the station.
  • Page 14 Power supply stations SPS12060XG3 SPS12060XG3 THERMAL PROBE The thermal probe optimizes the battery charge process. This device regulates the charging process in accordance with the battery temperature. The thermal probe protects against battery overheating and consequent permanent damage to the battery. It is supplied and inserted in the connector on the power supply unit ([D], table 6, C).
  • Page 15: Chapter 4 Using The Device

    Installation and programming manual Chapter 4 USING THE DEVICE Powering devices Connect the devices to be powered to the ancillary power outputs AUXx of the power supply station. If the SmartLevel station is used to power the devices of an installation with grade 2 or lower security rating, the AUXx outputs on the motherboard must be used (table 4 "Mother board - terminal board").
  • Page 16: Relay Output

    Power supply stations SmartLiving I-BUS SmartLevel control isolator power- panel IB100 supply station The jumpers on the isolator board [A] must be cut. Relay Output The output relay (terminals NC, NO and COM) provides a contact capable of switching a 30V 1A maximum load. The relay is normally active during standby status and maintains the COM contact closed to NC.
  • Page 17: Connection To Intrusion Control Systems

    Installation and programming manual Removal of the jumper from the earth fault signalling connector (table 6, E) deactivates the earth fault check. The T7 output signals a fault relating to the AUXx power output with grade 3 security rating caused by the intervention of the protection circuit it is equipped with.
  • Page 18 Power supply stations Using the device...
  • Page 19 Installation and programming manual WEEE Information on electrical and electronic device disposal (applicable in countries with recycling systems) The barred bin symbol found on the equipment or its box indicates that the product must be discarded separate from other waste at the end of its working life.
  • Page 20 Power supply stations ISO 9001 Quality Management certified by BSI with certificate number FM530352 Centobuchi, via Dei Lavoratori 10 63076 Monteprandone (AP) ITALY Tel. +39 0735 705007 _ Fax +39 0735 704912 info@inim.biz _ www.inim.biz...
