MAINTENANCE INSTRUCTION
Cleaning and greasing of the wedge and wedge blades
Recommanded is monthly or after every 10 working hours to keep your Holmatro Foudry Wedge in
optimal condition.
Required materials:
article number
description
(Holmatro)
150.581.093
Anti friction coating spray
100.581.082
Molykote BR-2 Plus Grease
150.583.142
Glue Permabond A130
180.000.029
2x T-grip
-
Allen key 5 mm
START position.
|
www.holmatro.com
|
HFW
example
1
Warning!
Make sure the pump is switched 'OFF'.
1
10h
2
916.001.339_001
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Holmatro Foudry Wedge HFW Series
Summary of Contents for Holmatro Foudry Wedge HFW Series
- Page 1 +31 (0)162 75150 industry@holmatro.com www.holmatro.com MAINTENANCE INSTRUCTION Cleaning and greasing of the wedge and wedge blades Recommanded is monthly or after every 10 working hours to keep your Holmatro Foudry Wedge in optimal condition. Required materials: article number description example (Holmatro) 150.581.093...
- Page 2 +31 (0)162 75150 industry@holmatro.com www.holmatro.com MAINTENANCE INSTRUCTION Fasten the tumbler with help of the T-grips. Remove the wedge blades. Remove the top and bottom covers. Start the pump. Set the pump switch to it’s Press the button, until the wedge is ‘MAINTENANCE’...
- Page 3 +31 (0)162 75150 industry@holmatro.com www.holmatro.com MAINTENANCE INSTRUCTION Clean the sliding surfaces of the wedge and Clean the plunger area. wedge blades Then apply a good amount of Apply the anti-friction coating to the Molykote BR-2 grease to the the sliding surfaces and let it set 3 min sliding surfaces by using a brush.
- Page 4 Place both wedge blades (new) back into the wedge. key 5 mm. Loosen the tumbler with help of the T-grips. Start the pump, set the switch to it’s ‘OPERATION’ Now your Holmatro Foundry Wedge is ready for position. use. 916.001.339_000...
