- Page 1 RPT 6 Head: Set Up Instructions: Page One: Check List Frame with Joystick Controller Power Supply mounting knob Y Cable Camera Mounting Extension Cable Hardware...
-
Page 2: Important Note
IMPORTANT NOTE: Balancing the camera correctly is very important for the head to perform properly. You must balance the camera both horizontally and vertically to get zero gravity balance. Horizontal balance is the balance between the front 1: Remove the 4 star knob and back of the camera. - Page 3 11: Use the Y cable to get power to the motors. The longer lead is for tilt and the 12. When using the RPT 6 Head with shorter lead is for pan. Plug the motors into...
- Page 4 NOTE: You may have other cables to consider such as a monitor feed or zoom and focus control cables. When you incorporate cables that connect to the camera, always feed the cables thru the hollow P&T pivot points of the head to avoid tangling.
- Page 5 Ramping at 9 O’clock or less Speed at 3 O’clock +/- See the picture above for what EZ FX considers to be ideal settings. Your user preferences may vary more or less. RAMPING: This dial, adjust the time it takes the voltage to the motor to reach full voltage.
