- Page 1 EZ HEAD Set Up Instructions: Page One: Check List Frame Joystick Controller Power Supply Extension Cable Head Mounting Camera Mounting Hardware Hardware...
- Page 2 4: Make sure that both the pan 1: Thread the shaft portion of 2. Set the frame to the 3. Secure the mount with and tilt motors are dis-engaged. the mounting hardware to the tripod or Jib. the knob and washer. base plate of the frame.
- Page 3 10: A perfect balance should allow you to position the camera at any angle and stay in place when released. Do this with both motors dis-engaged. Continue to 11: Once the vertical balance is adjust the vertical and horizontal balance until perfect. good, point the camera 9: Balance the camera downward then tighten the...
- Page 4 TURNTABLE MODE The versatile EZ Head can convert into turntable mode with the flip of a switch, giving you alternative uses for your investment. The illustration above shows how to attach your own turntable base to the pan base of the head. Simply use the switch on the side of the joystick box to change controls from the joystick to the...
