- Page 1 CDV08 & CDV09 Analog video distribution amplifier(s) Final Version ____________________________________________...
- Page 2 TECHNICAL MANUAL CDV08/09 Analog video distribution amplifier Software Revision: 0200 Hardware Version: 0300 Handelsweg 5 NL-5071 NT Udenhout The Netherlands Phone: +31 13 511 6666 Fax: +31 13 511 4151 E-mail: Info@axon.tv Web: www.axon.tv...
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: Axon warrants their products according to the warranty policy as described in the general terms. That means that Axon Digital Design BV can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
Table of Contents Chapter 1 Introduction to Synapse An introduction to Synapse Local Control Panel Remote Control Capabilities Chapter 2 Unpacking and Placement Unpacking Locating the card Chapter 3 A quick start When powering-up Default settings Changing parameters and settings Front Panel Control Example of changing parameter using Front Panel control... -
Page 5: Introduction To Synapse
High density, intuitive operation and high quality processing are Synapse key features of this system. Synapse offers a full range of converters and processing modules. Please visit the AXON Digital Design Website at www.axon.tv to obtain the latest information on our new products and updates. -
Page 6: Unpacking And Placement
2 Unpacking and Placement Unpacking The Axon Synapse card must be unpacked in an anti-static environment. Care must be taken to NOT to touch component on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. Ensuring that these precautions are followed will prevent premature failure from components mounted on the board. -
Page 7: A Quick Start
3 A Quick Start When Powering-up On powering up the Synapse frame, the card set will receive basic data and default initialisation settings. All LEDs will light during this process. After initialisation, several LEDs will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs. -
Page 8: Example Of Changing Parameter Using
Example of With the display as shown below changing parameters using RRC18 [Select Card] front panel control >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. SFS10 [Select Menu] >Settings Pressing the ►... -
Page 9: Synapse Setup Software
Synapse SetUp Software can be used to change the settings of Synapse SetUp Synapse modules from a PC, either locally or remotely. The Software software enables communication based on TCP/IP between the setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items. -
Page 10: The Cdv08/09 Cards
AC or DC coupling, in addition, the CDV08 has scalable Cable EQ, all items are user selectable. Miscellaneous The CDV08/09 cards fit into the Axon SFR18 rack. LEDs at the front of the board indicate the presence of power and input signal. -
Page 11: Settings Menu
5 Settings Menu Introduction The settings menu displays the current state of each setting within the CDV08/09 and enables the item to be changed or adjusted. Settings can be changed using the front panel of the Synapse frame (SFR18 or SFR04) or Synapse SetUp software. Please refer to chapter 3 for information on the Synapse front panel control and Synapse SetUp software Input... -
Page 12: Status Menu
6 Status Menu Introduction The status menu indicates the current status of each item listed below Input This status item indicates whether an analogue video signal is present at the input. The status can be Present if a video signal is detected or NA if a video signal is not detected. -
Page 13: Events
7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message What is the Goal? The goal of events is to inform the environment about a changing condition on the card. - Page 14 The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. The first implementation is the tag controlled switch in the GPI16.
-
Page 15: Led Indication
8 LED Indication POWER LED The power LED indicates the presence of power on the CDV08/09. INPUT LED This LED indicated the presence of a valid analog video signal on the input. -
Page 16: Block Schematic
9 Block Schematic... -
Page 17: Connector Panel
10 Connector Panel The CDV08/09 can be used with the following backplanes: BPL01, BPL07. BPL07 BPL01 VIDEO IN CDV08/09 CDV08/09... -
Page 18: Specifications
11 Specifications Analog Video Input Input level 1Vpk-pk inc, 300mV sync 75Ohm terminated Automatic Gain Control range -10dB to +6dB Colour control range -3dB to +3dB Return Loss 31dB to 5MHz 31dB to 10MHz CMR common mode >68dB, 5MHz (Floating) suppression >40dB, 10MHz Analog Video...
