Alnor HRU-CONTR-TPAD User Manual page 7

Touch screen controller
Number 08–Modbus address, to set each HRU-ERGO ID number when using the multiple controller or BMS
system,
the ID ranges from 1 to 16.
Number 21–to match the suitable program on PCB to the HRU-ERGO model, refer to below table.
Code Models
6
5 HRU-ERGO-250
4 HRU-ERGO-350
3 HRU-ERGO-500
0 HRU-ERGO-650
Number 22– this function is not available now.
Number 23– please select value 2, 10 speeds controls for HRU-ERGO.
Number 24– multifunction setting, 0 is reserved, 1 means fan running time clearance (to reset filter
alarm time), 2 means all weekly timer record clearance (to reset weekly timer).
6
ALNOR Systemy Wentylacji Sp. z o.o. Knowledge Base | www.alnor.com.pl
Code Models
1 HRU-ERGO-800
2 HRU-ERGO-1000
