QSFP-DD Test Adapter User Manual
QSFP-DD
Test Adapter
User Manual
P a g e
| 1
©2019 Wilder Technologies, LLC
Document No. 910-0057-000 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QSFP-DD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Wilder Technologies QSFP-DD

  • Page 1 QSFP-DD Test Adapter User Manual QSFP-DD Test Adapter User Manual P a g e ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 2: Table Of Contents

    QSFP-DD Mated HCBs/MCB Performance Plots ..............30 QSFP-DD MCB (Receptacle) Test Adapter Reference Information ..........60 Wilder Technologies, LLC – Limited Warranty ................. 61 Wilder Technologies, LLC – Terms & Conditions of Sale ............62 Compliance with Environmental Legislation ................63 WEEE Compliance Statement .................... 63 Compliance To RoHS 2 Substance Restrictions ..............
  • Page 3: Introduction

    Model Numbers (QSFPDD-TPAK-HCB-LGCY-P, QSFPDD-TPAK-HCB-DD-P, QSFPDD-TPAK-HCB-RX-P, QSFPDD-TPAK-HCB-TX-P and QSFPDD-TPAHK-MCB-R). The two test adapter types, shown in Figures 1 and 2, test QSFP-DD interface cables, hosts, and modules to the requirements of the QSFP-DD MSA and IEEE 802.3cd Standards. The QSFP-DD HCB (Plug) and QSFP-DD MCB (Receptacle) test adapter assemblies allow easy access, via 2.92mm (K-Style) connections, to measure or inject data signals.
  • Page 4 High-Speed QSFP-DD Receptacle Figure 2. The QSFP-DD MCB (Receptacle) Test Adapter (Note: The coaxial cables are configuration dependent and may be terminated with different connectors than what is shown.) NOTE: The metal shell of both the plug (QSFP-DD HCB) and receptacle (QSFP-DD MCB) connectors tie high-speed ground to chassis ground.
  • Page 5: Product Inspection

    Locate the shipping list and verify that all items ordered were received. • In the unlikely event that the product is defective or incomplete, the “Limited Warranty” section discusses how to contact Wilder Technologies for technical assistance and/or how to package the product for return. P a g e ©2019 Wilder Technologies, LLC...
  • Page 6: The Qsfp-Dd Test Adapter Care And Handling Precautions

    If the QSFP-DD TPA must be turned or twisted to make connection to the DUT, avoid using the QSFP-DD TPA housing alone to make this occur. Try to distribute the torque forces along the length of the test setup and cabling.
  • Page 7 • CAUTION 7: ESD Sensitivity The QSFP-DD test adapters are passive components and are not in themselves sensitive to electrostatic discharge. However, when an active DUT is installed, that device becomes susceptible to ESD. Observe proper ESD precautions, further discussed later in this document.
  • Page 8: General Test Adapter, Cable, And Connector

    Observing simple precautions can ensure accurate and reliable measurements. Handling and Storage Before each use of the QSFP-DD TPA, ensure that all connectors are clean. Handle all cables carefully and store the QSFP-DD TPA in the foam-lined instrument case when not in use, if possible.
  • Page 9: Electrostatic Discharge Information

    Electrostatic Discharge Information Protection against electrostatic discharge (ESD) is essential while connecting, inspecting, or cleaning the QSFP-DD TPA test adapter and connectors attached to a static-sensitive circuit (such as those found in test sets). Electrostatic discharge can damage or destroy electronic components. Be sure to perform all work on electronic assemblies at a static-safe work station, using two types of ESD protection: •...
  • Page 10: User Model

    QSFP-DD Test Adapter User Manual User Model The QSFP-DD TPAs are capable of performing to the requirements of both IEEE and SFF specifications, limited only by the specifications, environmental, care and handling of this document. In the case where the laboratory source or load is not used in the test, it must be replaced with RF terminations on each unused signal.
  • Page 11 QSFP-DD Test Adapter User Manual The second example shows a QSFPDD-TPAK-HCB (Plug) is used to test a host: In the case where the laboratory source or load is not used in the test, it must be replaced with RF terminations on each unused signal. (NOTE: DC Blocks and RF terminators are optionally offered by Wilder Technologies.)
  • Page 12 QSFP-DD Test Adapter User Manual The third example shows two QSFPDD-TPAHK-MCB-R’s used for testing a QSFP-DD cable: P a g e | 12 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 13: Calibration Through De-Embedding

    QSFP- DD Receivers or looks at the response of the QSFP-DD Transmitters. The QSFP-DD TPA’s have Touchstone S4P files for de-embedding the electrical length and losses within the TPA up to the QSFP-DD connector interface pads. (Contact Wilder Technologies, support@wilder-tech.com, to obtain a copy of the S4P files.) The Touchstone S4P...
  • Page 14: Mechanical And Environmental Specifications

    QSFP-DD Test Adapter User Manual Mechanical and Environmental Specifications NOTE: All specifications in this manual are subject to change. Table 1. General Specifications ITEM DESCRIPTION Usage Environment Controlled indoor environment 263.00 mm +/- 2 mm (10.35 inches +/- .08 inches)
  • Page 15 QSFP-DD Test Adapter User Manual Table 2. QSFPDD-TPAK-HCB (Plug) 12-Position Cable Connector (Low-Speed). (NOTE: Connections are common to Legacy, DD, Rx and Tx configurations) LABEL PIN NO. COLOR ID FOR HCB DESCRIPTION Pin 1 Black Signal (RF Ground) and Supply (Power) Common...
  • Page 16 QSFP-DD Test Adapter User Manual Table 3. QSFPDD-TPAK-HCB-LGCY-P (Legacy Plug) Pin Assignments Connector Color ID for Data Color Identification Pin Description Destination (HCB) Pin Number Line Polarity (HCB) Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx2n Tx2-...
  • Page 17 QSFP-DD Test Adapter User Manual P2 Pin 3 Black Insulation VccT Present/Connected Present/Connected Vcc1 Present/Connected Present/Connected P2 Pin 8 Black Insulation Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx3p Tx3+ White/Green Tx3n Tx3- Black White/Green Coax Shield and...
  • Page 18 QSFP-DD Test Adapter User Manual Table 4. QSFPDD-TPAK-HCB-DD-P (DD Plug) Pin Assignments Connector Color ID for Data Color Identification Pin Description Destination (HCB) Pin Number Line Polarity (HCB) P2 Pin 7 Black Insulation P2 Pin 6 Black Insulation VccR Present/Connected...
  • Page 19 QSFP-DD Test Adapter User Manual Rx5p Rx5+ Orange Rx5n Rx5- Black Orange Coax Shield and Ground Black Insulation P2 Pin 1, 12 Coax Shield and Ground Black Insulation P2 Pin 1, 12 Rx6n Rx6- Black Brown Rx6p Rx6+ Brown Coax Shield and...
  • Page 20 QSFP-DD Test Adapter User Manual Table 5. QSFPDD-TPAK-HCB-RX-P (Rx Plug) Pin Assignments Connector Color ID for Data Color Identification Pin Description Destination (HCB) Pin Number Line Polarity (HCB) P2 Pin 7 Black Insulation P2 Pin 6 Black Insulation VccR Present/Connected...
  • Page 21 QSFP-DD Test Adapter User Manual VccRx1 Present/Connected Present/Connected Present/Connected Present/Connected Present/Connected Present/Connected Coax Shield and Ground Black Insulation P2 Pin 1, 12 Rx7p Rx7+ Violet Rx7n Rx7- Black Violet Coax Shield and Ground Black Insulation P2 Pin 1, 12 Rx5p...
  • Page 22 QSFP-DD Test Adapter User Manual Table 6. QSFPDD-TPAK-HCB-TX-P (Tx Plug) Pin Assignments Connector Color ID for Data Color Identification Pin Description Destination (HCB) Pin Number Line Polarity (HCB) Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx2n Tx2-...
  • Page 23 QSFP-DD Test Adapter User Manual Tx6n Tx6- Black White/Brown Tx6p Tx6+ White/Brown Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx8n Tx8- Black White/White Tx8p Tx8+ White/White Coax Shield and Ground Black Insulation P2 Pin 1, 12 Reserved...
  • Page 24 The QSFPDD-TPAHK-MCB-R test adapter (Legacy, DD, Rx and Tx) provides thirty-two 2.92mm (K-Style) connectors (four lanes of primary differential signals) to access all QSFP-DD high-speed signals (Legacy, DD, Rx and Tx). Labels clearly mark each cable or connector. The following figure refers to the pin-description tables for the QSFPDD-TPAHK-MCB-R (Receptacle) test adapter.
  • Page 25 QSFP-DD Test Adapter User Manual Table 7. QSFPDD-TPAHK-MCB-R 12-Position Fixture-Mounted Connector (Low-Speed) LABEL PIN NO. DESCRIPTION Pin 1 Signal (RF Ground) and Supply (Power) Common Pin 2 Module Present Pin 3 Interrupt Pin 4 SDA, I C Data for DDC...
  • Page 26 QSFP-DD Test Adapter User Manual Table 8. QSFPDD-TPAHK-MCB-R (Receptacle) Pin Assignments Connector Color ID for Data Color Identification Pin Description Destination (HCB) Pin Number Line Polarity (HCB) Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx2n Tx2- Black...
  • Page 27 QSFP-DD Test Adapter User Manual P2 Pin 3 Black Insulation VccT Present/Connected Present/Connected Vcc1 Present/Connected Present/Connected P2 Pin 8 Black Insulation Coax Shield and Ground Black Insulation P2 Pin 1, 12 Tx3p Tx3+ White/Green Tx3n Tx3- Black White/Green Coax Shield and...
  • Page 28 QSFP-DD Test Adapter User Manual Rx5p Rx5+ Orange Rx5n Rx5- Black Orange Coax Shield and Ground Black Insulation P2 Pin 1, 12 Coax Shield and Ground Black Insulation P2 Pin 1, 12 Rx6n Rx6- Black Brown Rx6p Rx6+ Brown Coax Shield and...
  • Page 29: Electrical Specifications

    QSFP-DD Test Adapter User Manual Electrical Specifications NOTE: All specifications in this manual are subject to change. Table 9. Electrical Specifications (Optional External DC Block) as Supplied by Wilder Technologies SPECIFICATION NOTES Insertion Loss (dB), at 100 kHz - 12.4 GHz 0.50...
  • Page 30: Qsfp-Dd Mated Hcbs/Mcb Performance Plots

    QSFP-DD Test Adapter User Manual QSFP-DD Mated HCBs/MCB Performance Plots NOTE: All specifications in this manual are subject to change. Table 11. Fixtures Measured SUPPORT WILDER PART COAX CABLE DESCRIPTION FEATURE NUMBER CONFIGURATION QSFPDD-TPAHK-MCB-R (Receptacle) Power Sinking 600-1161-600 2.92mm 6” Female (K-Style)
  • Page 31 QSFP-DD Test Adapter User Manual Figure 5. QSFP-DD HCB (TX) Insertion Loss The insertion loss reflects the typical coaxial fixture loss profile where at the low frequencies the loss is at or slightly below the maximum loss limit then slopes to near the minimum loss limit at higher frequencies.
  • Page 32 QSFP-DD Test Adapter User Manual Figure 6. QSFP-DD HCB (TX) Return Loss Meets IEEE 802.3cd Specification P a g e | 32 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 33 QSFP-DD Test Adapter User Manual Figure 7. QSFP-DD HCB (TX) Mated Common Mode Conversion Insertion Loss Meets IEEE 802.3cd Specification P a g e | 33 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 34 QSFP-DD Test Adapter User Manual Figure 8. QSFP-DD HCB (TX) Mated Common Mode Return Loss Meets IEEE 802.3cd Specification P a g e | 34 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 35 QSFP-DD Test Adapter User Manual Figure 9. QSFP-DD HCB (TX) Mated Common-Mode Conversion Return Loss Meets IEEE 802.3cd Specification P a g e | 35 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 36 QSFP-DD Test Adapter User Manual Figure 10. QSFP-DD HCB (TX) Mated ILD (Worst Case) FOM (Figure of Merit) < .13 dB IEEE 802.3cd 136B.1.1.1 IEEE 802.3bj 92.11.3.1 Tx1 FOM ILD = 0.051 dB Tx2 FOM ILD = 0.029 dB Tx3 FOM ILD = 0.059 dB Tx4 FOM ILD = 0.039 dB...
  • Page 37 QSFP-DD Test Adapter User Manual Figure 11. QSFP-DD HCB (TX) Mated MDFEXT dB ICN FEXT = 4.2 mV IEEE 802.3cd 136B.1.1.6 Tx1 ICN = 2.33 mV Tx2 ICN = 3.62 mV Tx3 ICN = 2.34 mV Tx4 ICN = 3.28 mV Tx5 ICN = 3.61 mV...
  • Page 38 QSFP-DD Test Adapter User Manual Figure 12. QSFP-DD HCB (RX) Insertion Loss The insertion loss reflects the typical coaxial fixture loss profile where at the low frequencies the loss is at or slightly below the maximum loss limit then slopes to near the minimum loss limit at higher frequencies.
  • Page 39 QSFP-DD Test Adapter User Manual Figure 13. QSFP-DD HCB (RX) Return Loss Meets IEEE 802.3cd Specification P a g e | 39 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 40 QSFP-DD Test Adapter User Manual Figure 14. QSFP-DD HCB (RX) Mated Common Mode Conversion Insertion Loss Meets IEEE 802.3cd Specification P a g e | 40 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 41 QSFP-DD Test Adapter User Manual Figure 15. QSFP-DD HCB (RX) Mated Common Mode Return Loss Meets IEEE 802.3cd Specification P a g e | 41 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 42 QSFP-DD Test Adapter User Manual Figure 16. QSFP-DD HCB (RX) Mated Common-Mode Conversion Return Loss Meets IEEE 802.3cd Specification P a g e | 42 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 43 QSFP-DD Test Adapter User Manual Figure 17. QSFP-DD HCB (TX) Mated MDFEXT dB FOM (Figure of Merit) < .13 dB IEEE 802.3cd 136B.1.1.1 IEEE 802.3bj 92.11.3.1 Tx1 FOM ILD = 0.039 dB Tx2 FOM ILD = 0.059 dB Tx3 FOM ILD = 0.036 dB Tx4 FOM ILD = 0.054 dB...
  • Page 44 QSFP-DD Test Adapter User Manual Figure 18. QSFP-DD HCB (RX) Mated MDFEXT dB ICN FEXT = 4.2 mV IEEE 802.3cd 136B.1.1.6 Rx1 ICN = 3.30 mV Rx2 ICN = 2.42 mV Rx3 ICN = 3.17 mV Rx4 ICN = 2.36 mV Rx5 ICN = 3.42 mV...
  • Page 45 The QSFP-DD Legacy channels are showing more resonances at the higher frequencies. The board impedance is low by 5% to 6% on some of the Legacy channels.
  • Page 46 QSFP-DD Test Adapter User Manual Figure 20. QSFP-DD HCB (LGCY) Return Loss Meets IEEE 802.3cd Specification P a g e | 46 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 47 QSFP-DD Test Adapter User Manual Figure 21. QSFP-DD HCB (LGCY) Mated Common Mode Conversion Insertion Loss Meets IEEE 802.3cd Specification P a g e | 47 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 48 QSFP-DD Test Adapter User Manual Figure 22. QSFP-DD HCB (LGCY) Mated Common Mode Return Loss Meets IEEE 802.3cd Specification P a g e | 48 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 49 QSFP-DD Test Adapter User Manual Figure 23. QSFP-DD HCB (LGCY) Mated Common-Mode Conversion Return Loss Meets IEEE 802.3cd Specification P a g e | 49 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 50 QSFP-DD Test Adapter User Manual Figure 24. QSFP-DD HCB (LGCY) Mated ILD (Worst Case) FOM (Figure of Merit) < .13 dB IEEE 802.3cd 136B.1.1.1 IEEE 802.3bj 92.11.3.1 Tx1 FOM ILD = 0.066 dB Tx2 FOM ILD = 0.036 dB Tx3 FOM ILD = 0.061 dB Tx4 FOM ILD = 0.033 dB...
  • Page 51 QSFP-DD Test Adapter User Manual Figure 25. QSFP-DD HCB (LGCY) Mated MDNEXT dB ICN NEXT = 1.6 mV IEEE 802.3cd 136B.1.1.6 Rx1 ICN = 0.60 mV Rx2 ICN = 0.64 mV Rx3 ICN = 1.22 mV Rx4 ICN = 1.22 mV...
  • Page 52 The QSFP-DD Legacy channels are showing more resonances at the higher frequencies. The board impedance is low by 5% to 6% on some of the Legacy channels.
  • Page 53 QSFP-DD Test Adapter User Manual Figure 27. QSFP-DD HCB (DD) Return Loss Meets IEEE 802.3cd Specification P a g e | 53 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 54 QSFP-DD Test Adapter User Manual Figure 28. QSFP-DD HCB (DD) Mated Common Mode Conversion Insertion Loss Meets IEEE 802.3cd Specification P a g e | 54 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 55 QSFP-DD Test Adapter User Manual Figure 29. QSFP-DD HCB (DD) Mated Common Mode Return Loss Meets IEEE 802.3cd Specification P a g e | 55 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 56 QSFP-DD Test Adapter User Manual Figure 30. QSFP-DD HCB (DD) Mated Common-Mode Conversion Return Loss Meets IEEE 802.3cd Specification P a g e | 56 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 57 QSFP-DD Test Adapter User Manual Figure 31. QSFP-DD HCB (DD) Mated ILD (Worst Case) FOM (Figure of Merit) < .13 dB IEEE 802.3cd 136B.1.1.1 IEEE 802.3bj 92.11.3.1 Tx1 FOM ILD = 0.053 dB Tx2 FOM ILD = 0.030 dB Tx3 FOM ILD = 0.050 dB Tx4 FOM ILD = 0.038 dB...
  • Page 58 QSFP-DD Test Adapter User Manual Figure 32. QSFP-DD HCB (DD) Mated MDNEXT dB ICN NEXT = 1.6 mV IEEE 802.3cd 136B.1.1.6 Rx5 ICN = 0.83 mV Rx6 ICN = 0.83 mV Rx7 ICN = 1.35 mV Rx8 ICN = 1.45 mV...
  • Page 59 QSFP-DD Test Adapter User Manual QSFP-DD Mated Total ICN Total ICN NEXT = 4.4 mV (IEEE 802.3cd 136B.1.1.6) P a g e | 59 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 60: Qsfp-Dd Mcb (Receptacle) Test Adapter Reference Information

    QSFP-DD Test Adapter User Manual QSFP-DD MCB (Receptacle) Test Adapter Reference Information This section contains a schematic diagram of the QSFPDD-TPAHK-MCB-R Power Connections. Figure 33. QSFPDD-TPAHK-MCB-R Power Connections P a g e | 60 ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A...
  • Page 61: Wilder Technologies, Llc - Limited Warranty

    Wilder Technologies, LLC. If, during the warranty period, the Test Adapter is not in good working order, Wilder Technologies, LLC will, at its option, repair or replace it at no additional charge, except as is set forth below. In some cases, the replacement Test Adapter may not be new and may have been previously installed.
  • Page 62: Wilder Technologies, Llc - Terms & Conditions Of Sale

    Technologies, LLC is Wilder Technologies, LLC's responsibility. Loss or damage that occurs during shipping by a carrier selected by you is your responsibility. You must notify Wilder Technologies, LLC within 7 days of the date of your invoice or acknowledgement if you believe any part of your purchase is missing, wrong or damaged. Unless you provide Wilder Technologies, LLC with a valid and correct tax exemption certificate applicable to your purchase of Product and the Product ship-to location, you are responsible for sales and other taxes associated with the order.
  • Page 63: Compliance With Environmental Legislation

    European Union Directive 2002/96/EC on waste electrical and electronic equipment ("WEEE Directive"). As a service to our customers, Wilder Technologies is also available for managing the proper recycling and/or disposal of all Wilder Technologies products that have reached the end of their useful life.
  • Page 64: Glossary Of Terms

    50 Gbps 8X Pluggable Transceiver (High-Density Quad Small Form Factor QSFP-DD Pluggable) QSFP-DD Host The QSFP-DD Host is the fixed end of the connection supporting IEEE 802.3. The QSFP-DD Module is the moveable end of the connection supporting QSFP-DD Module IEEE 802.3.
  • Page 65: Index

    QSFP-DD HCB (TX) Mated Common-Mode Directivity Errors, 13 Conversion Return Loss, 35 Drift Errors, 13 QSFP-DD HCB (TX) Mated ILD (Worst Case), 36 DUT, 13 QSFP-DD HCB (TX) Mated MDFEXT dB, 37, 43 Electrical Specifications, 29 QSFP-DD HCB (TX) Return Loss, 32...
  • Page 66 QSFP-DD Test Adapter User Manual Secure Storage, 5 QSFPDD-TPAK-HCB-LGCY-P (Legacy Plug) Pin SFF Specification, 3 Assignments, 16 Source Impedance Mismatching Errors, 13 QSFPDD-TPAK-HCB-RX-P (Rx Plug) Pin Support, 13, 62, 63 Assignments, 20 Supporting Instrument Cables or Accessories, 7 QSFPDD-TPAK-HCB-TX-P (Tx Plug) Pin Assignments,...
  • Page 67 Visit our website at www.wilder-tech.com Wilder Technologies, LLC 6101A East 18 Street Vancouver, WA 98661 Phone: 360-859-3041 Fax: 360-859-3105 www.wilder-tech.com ©2019 Wilder Technologies, LLC Document No. 910-0057-000 Rev. A Created: 9/17/2019 Released: 11/11/2019...
