ASSEMBLY AND INSTALLATION
T0240
WARNING:
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
Hardware Package (included):
Fitter Screw (A)
IMPORTANT:
The sensor has an excellent photocell function to
enable the light to turn on at dusk and off at dawn
automatically.
Glass Panel
Clip
Metal Frame
Slot
INSTRUCTIONS
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Wire Nut (B)
Set Screw
Glass Panel
Fixture
Fitter
Fig.1
Fitter Screw(A)
Metal Frame
Glass Panel
Set Screw
Bulb type B Max. 60W
(not include)
Fixture
Socket
Photocell
Fixture Wire
Wire Nut (B)
Grounding Wire
Post
160303
