ASSEMBLY AND INSTALLATION
T0215
WARNING:
NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements.
2. READ AND SAVE THESE INSTRUCTIONS.
Hardware Package (included):
Mounting Screw (B)
Cross Bar (A)
Mounting Screw (B)
Lock Nut
Green Grounding Screw (C)
Cross Bar (A)
Headless Screw (D)
Wire Nut (F)
Outlet Box
House Grounding Wire
Fixture Grounding Wire
INSTRUCTIONS
TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF
POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE.
Green Grounding
Screw (C)
(E)
End Cap
Metal Plate
Bottom Bolt Nut
Stem
Fixture
Fig.1
Lock Nut (E)
Headless Screw(D)
Back Plate
Fixture Wire
Rubber Pad (H)
Bolt Nut (G)
Bolt Nut (G)
Wire Nut (F)
Bend Bar
Glass Shade
Metal Frame
Bulb type A Max. 60W
(not include)
Socket
Fixture
Bottom Bolt Nut
Metal Plate
End Cap
151118
Rubber Pad (H)
Advertisement
Table of Contents
Related Manuals for Vaxcel T0215
Summary of Contents for Vaxcel T0215
- Page 1 ASSEMBLY AND INSTALLATION INSTRUCTIONS T0215 WARNING: TO AVOID RISK OF ELECTRICAL SHOCK, BE SURE TO SHUT OFF POWER BEFORE INSTALLING OR SERVICING THIS FIXTURE. NOTES: 1. Before installing, consult local electrical codes for wiring and grounding requirements. 2. READ AND SAVE THESE INSTRUCTIONS.
- Page 2 Installation Steps Turn off the power at fuse or circuit box. 1. Remove the EVA plugged between glass shade and bend bars. Thread two headless screws through the cross bar, and then secure them with four lock nuts (two on each side of the cross bar).
