Summary of Contents for Seura SC-1
- Page 1 WARRANTY REGISTRATION REGISTER FOR EXTRA BENEFITS Activate within 30 days of purchase: seura.com/activate OUTDOOR TV CEILING MOUNT INSTALLATION GUIDE Model Numbers: SC-1 LC-1 8 " 8 "...
- Page 2 Compatible with Séura Outdoor TVs: Shade Series: SHD1-55, SHD1-65, SHD1-75, SHD2-43, SHD2-55, SHD2-65, SHD2-75 Ultra Bright: STM3-55-U, STM3-65-U, STM3-86-U Safety Prior to the installation of this product, read all • When mounting to metal structures or concrete instructions. Keep this manual for future reference. ceilings, an alternative anchor (not included) should used.
-
Page 3: Installation Tools
Installation Tools The following tools may be required depending upon your particular Parts and Tools Required (not included) The following tools may be required depending on your particular installation. They are not included. ¼˝ Drill Bit for ˝ Electronic Stud Finder Wood Stud Pencil Level... -
Page 4: Parts Included
Insert and fasten two screws without washers until approximately 1/2" remains. Pencil Level Tape Measure OUTDOOR TV CEILING MOUNT INSTALLATION GUIDE Model Numbers: SC-1 LC-1 Manual Mounting Template Socket Wrench Phillips Tip Protective Eyewear ½˝ Socket M10 Socket* (located on inside bottom of box) "... - Page 5 P5080T Installation Tools Parts Included, Packaged as TW-5 The following tools may be required depending upon your particular installation. They are not inc ¼˝ Drill Bit for ˝ Concrete Drill Bit* Electronic Stud Finder Wood Stud P5080T lation Tools Installation Tools owing tools may be required depending upon your particular installation.
- Page 6 Features Ceiling Mounting Plate A template with the mounting hole pattern is included to aid installation. Tilt Locking Bolts Allows for tilt angle of the TV adjustment. Top Leveling Screws Allows for Directional leveling Mounting Arrows adjustments of the TV after The arrow lets you mounting.
- Page 7 Cable Pass Through Run power and content cables through the back of the pole or into the ceiling. Height Adjustment Use both included screws to set the desired height. Swivel Adjustment Loosening both knobs allows adjustment of the swivel. Always retighten as TV may swivel in the wind.
- Page 8 Step 1: Assemble and Prepare Mount 1. Assemble ceiling mount Ensure the plastic ring is on the Ceiling Bracket Extension. Slide the Mounting Plate Rails onto the Ceiling Bracket Extension. Note: The Mounting Plate Rails is a symmetrical part, so orientation does not matter.
- Page 9 14" 14" 14" 14" 14" 14" 16 " 16 " 16 " 16 " 16 " 16 " 14" 14" 16 " 16 " 14" 14" 16 " 16 " 16 " 16 " 2 " X 1" 2 " X 1" 16 "...
-
Page 10: Installation
IMPORTANT: HANDLE THE TV IN A VERTICAL POSITION TO AVOID DAMAGE TO THE SCREEN. IF PLACING THE TV SCREEN-SIDE DOWN OR LEANING AGAINST A WALL DURING INSTALLATION, COVER THE SCREEN WITH A PROTECTIVE CLOTH OR BLANKET. Installation IMPORTANT: THIS PRODUCT MUST BE MOUNTED TO A PROPERLY RATED CEILING STRUCTURE. The structure must be able to support five times the weight of the television and the mount combined. - Page 11 2. Drill pilot holes Wood Joist/Truss Mounting: Pre-drill the four marked holes on the wall 3-inches deep with a 7/32” drill bit. Concrete: Pre-drill the four marked holes on the wall 3-inches deep with a 7/16” masonry drill bit. Insert a plastic anchor into each of these holes.
- Page 12 3. Attach ceiling mounting plate Align the mounting plate with the pre-drilled holes. Ensure that the cable pass through holes on the mount are positioned appropriately. Wood Joist/Truss Mounting: Concrete: Align the bracket with the screw keyed slots Align the bracket with the pre-drilled holes. and turn to hold in place.
- Page 13 Step 3: Attach Tilt Mount TV Brackets to TV IMPORTANT: Check your TV manual before attaching brackets to TV. Some models require attaching soundbar brackets in tandem with attaching TV brackets. Using a Philips #2 Screwdriver (or 6 mm Allen Wrench for 86” Ultra Bright TV), remove the four VESA mount screws from the back of the TV.
-
Page 14: Step 5: Adjust The Tv
Step 5: Adjust the TV Caution: It is possible to dislodge your TV while you level it. Use extreme caution until you tighten the leveling and locking screws. Top Leveling Screw Allows for leveling adjustments of the TV Séura recommends checking knobs, screws, after mounting. - Page 15 Tilt adjustment: t Angle Adjusting the TV Tilt Angle 1. Place one hand on the center-top edge edge of the flat of the TV. 2. Place the other hand on the center- r-bottom edge of bottom edge of the TV. 3.
- Page 16 Séura website at F. Alterations, modifications, including use of unauthorized https://www.seura.com/warranty/. This warranty is valid only mount, or changes to a Product without Séura’s prior written with respect to Product sales in the U.S. and Canada.
- Page 17 be reasonably required by Séura to verify the Product’s warranty Toll-Free Technical Support: Please call 1-800-957-3872 to eligibility. Séura shall have no liability with respect to Products speak with a Séura Technical Support Representative. Séura whose serial number has been removed, defaced, replaced, or Representatives are available Monday-Friday, 8:00am-4:30pm otherwise tampered with in any manner.
-
Page 18: Specifications
Specifications SHORT ARM CEILING LONG ARM CEILING MOUNT MOUNT Model: SC-1 Model: LC-1 DISPLAY COMPATIBILITY 42" - 86" Séura Outdoor TVs Collapsed: 26.25” w x 6.6 d x 34” h Collapsed: 26.25” w x 6.6 d x 48.5” h CEILING MOUNT DIMENSIONS Extended: 26.25”... - Page 19 5" 5 4 " 6 2 " SHORT ARM LONG ARM CEILING MOUNT CEILING MOUNT 2 " Model: SC-1 Model: LC-1 16 " FULLY COLLAPSED 22-15/16" FULLY EXTENDED 16 " 25mm 1" 16 " FULLY COLLAPSED 51-7/16" FULLY EXTENDED 16 "...
- Page 20 For technical support, please contact Séura at 1-800-957-3872 during regular business hours: M-F 8:00 am - 4:30 pm, Central Time. 1230 Ontario Road Green Bay, Wisconsin 54311 1-800-957-3872 contacts@seura.com www.seura.com Publish date: September 15, 2020 Information is subject to change without notice.
