Tie Down Engineering Roof Zone Penetrator 2+2 Instruction Sheet page 6

DO NOT use the Penetrator 2+2 Roofing Cart without the ballast slide extended and all ballast weights applied.
Once the location for the operation of the Penetrator 2+2 has been determined, the ballast slide must be
adjusted to the proper operational length.
DO NOT USE THE PENETRATOR 2+2 WITHOUT
THE BALLAST SLIDE ARM EXTENDED AND
THE BALLAST WEIGHTS APPLIED.
Setting the Ballast Slide and Weights
Ballast Slide
Ballast Slide
Pull Pin
Pull the ballest slide out until it stops.
DO NOT REMOVE THE BALLAST PULL PIN
Ballast Slide
Pull Pin
Step 1
Step 2
Carefully place the ballast weights one at a time.
Be carefully when placing the ballast, each weight
has the potential of being a pinch point.
ATTENTION!
Ballast Slide Must
Be Fully Extended!
ALL 6 Ballast Must Be
Applied on the Ballast Slide!
6
Ballast Slide
Pull Pin
