- Page 1 Electra Roman Blinds How to install, programme and operate your blind electrablinds.co.uk Ref 09/20...
-
Page 2: Table Of Contents
Contents - Page 3 The contents of your order - Page 4 Blind fitting and position - Page 5 Roman Blind Installation and removal - Page 6 Battery pack installation & power up Power up & testing - - Page 7 without a control - Page 8 Operation... -
Page 3: The Contents Of Your Order
The contents of your order Smart Home Options Controls Power supply Roman Blind If you ordered one of our If you ordered a control with smart home options with Rechargeable Li-ion Battery your blind(s), then it will be Pack your blind(s), then it will be one of the following: one of the following: 5-Channel... -
Page 4: Blind Fitting And Position
Blind fitting & position Fitting your blind inside the window recess Firstly decide whether to face fix or top fix your blind. We recommend you top fix your blind within the recess if: • you have uPVC window frame • there are obstructions like handles We recommend you face fix your blind if: •... - Page 5 Removing the blind - Start at one end of the blind and: Electra Top Tip! If securing the brackets to plaster, 1) Push the headrail in to compress the bracket spring. 2) Tilt the headrail down at the rear and unhook the headrail stone, brick, etc., drill the holes at the marked...
-
Page 6: Battery Pack Installation & Power Up
Battery pack installation Decide where you want the battery to sit and check that the battery is close enough to connect to the motor supply cable. Position and mark the square mounting clips. Fix using the screws provided and suitable fixings. Push the external battery into mounted clips. - Page 7 The following instructions are relevant if you already have a remote control/wall switch and selected 'no control needed' when ordering your Electra blind. The blind supplied has been set up with the up and down stop position preset for your convenience.
-
Page 8: Operation
Operation Operating your Roman Blind General control We have programmed your blind to automatically stop at preset upper and lower stop positions. It couldn't be simpler- just press the Up or Down button until the blind starts moving and your blind will move in the respective direction until it reaches the preset stop position, where it will stop automatically. -
Page 9: Adjusting The Upper & Lower Stop Positions
Adjusting the upper & lower stop positions 1a. Adjust upper stop position - 3. Adjust to the desired 4. Press and hold the press the up button and send the 2. Press and hold the upper/lower stop 'my' button until the blind to the current upper stop Up and Down buttons position using either... -
Page 10: Add/Delete Controls
Add/delete controls Delete a control Add a control Control already paired to the Control to add to the blind blind memory Step 1 - Take a handset or wall Step 1 - Press the program button on your handset or switch that is already wall switch that already programmed to the blind... -
Page 11: Multi Channel Programming
Multi-channel programming Assigning additional channels with a 5-channel control Example: Two blinds with independent control on channels 1 (blind 1) & 2 (blind 2) - set up the blinds for group control so that when you press channel 3, blinds 1 & 2 will operate together). Your 5-Channel Step 1 - Select Channel 1 which operates blind 1. -
Page 12: Reset And Reprogramme Procedure
Reset and reprogramme procedure Before you begin - Disconnect the power to all other powered blinds while programming. Reset STEP 1 - Disconnect the battery pack. STEP 2 - Remove the blind and the battery pack from their mounting brackets and lay out on a table. STEP 3- Reconnect the battery pack. - Page 13 Reset procedure continued STEP 4: Use the up STEP 5: Press and hold button to move the the 'my' and up button blind until it reaches until the blind starts to the upper limit position. move up. The blind will Press and hold the 'my' automatically stop at and down buttons until...
- Page 14 • Your guarantee does not cover accidental damage, damage caused by rough use or damp conditions. Cleaning Your Roman Blinds To lightly clean your blinds, simply dust with a feather duster or the brush nozzle of your vacuum cleaner. More persistent marks may be removed using a sponge with warm water and a mild detergent.
- Page 15 General Maintenance continued It is important that nothing is allowed to obstruct your Electra Roman blind when moving. Should the blind be lowered onto an obstruction, such as an ornament on a window sill, the blind will be impeded but the motor will carry on turning and the lift cords may become entangled in the headrail.
- Page 16 electrablinds.co.uk...
