Flexcut 80 Torch Positioning Procedure
The purpose of the instructions below are to explain how change the
position of the LC105/100M within the torch holder clamps, per OEM
specification.
Datum the machine.
Install the 40 amp consumable stack to the LC105/100M torch.
LC105M:
LC100M:
Jog the machine, in the X and Y axis, to a position between two slats.
Jog the Z axis down to the end of its travel.
Rev#:00
Rev Date:8/8/2018
