Sealey CS20V Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
Always wear appropriate eye protection, ear protection, substantial footwear, gloves, long trousers whilst operating.
9
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and contain long hair.
9
Inspect and ensure equipment is in good working order before use.
9
Maintain and clean tool and battery pack, regularly. Check air holes are clear.
9
Must be serviced by an authorised agent. Use genuine parts only. Non authorised parts will invalidate the warranty.
9
WARNING! Remove battery before: performing maintenance, carrying out adjustments, inspecting the machine after striking an object,
‰
before clearing a blockage, before leaving the tool unattended, before moving to the next job location.
WARNING! Risk assess the work area. Keep bystanders away from the work area.
9
DO NOT operate with anyone or pets nearby. Check intended work area for wildlife.
8
DO NOT use in bad weather conditions, especially when there is a risk of lightning. DO NOT expose to rain. Only use in good light.
8
DO NOT use if tool vibrates abnormally, switch off, remove battery and then inspect.
8
DO NOT touch hazardous moving parts. Allow to come to a complete stop first.
8
DO NOT operate whilst tired, ill under the influence of alcohol or other intoxicating drugs.
8
DO NOT overreach and keep balance at all times.
8
DO NOT use if damaged. DO NOT operate with defective guards or shields or without safety
8
DO NOT use for a task it was not designed to perform.
8
Store with the battery removed and separate from the machine, in a dry, childproof location.
9
WARNING! Never allow children, persons with reduced physical sensory or mental capabilities or lack of experience and knowledge
‰
or people unfamiliar with these instructions to use the machine, local regulations may restrict the age of the operator.
2. INTRODUCTION
Lightweight cordless strimmer makes gardening easy, clean and effective. Fully adjustable in height and cutting angles. Head can be adjusted
vertically between 0°-50° (4 settings available). Head can also be rotated between 0°-90° both ways for applications such as lawn edge cutting.
Works in conjunction with our one battery fits all program. Body only. (Includes 10 x plastic blades). Powered by a 2Ah or 4Ah battery and mains
charger (not included).
3. SPECIFICATION
Model No: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . CS20V
Cutting Mechanism: . . . . . . . . . . . . . . . . . . . . . . . Plastic Blade
Cutting Width:. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .260mm
No Load Speed: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8000rpm
Voltage: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20V Li-ion
Nett Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.5kg
Vibration: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5.8m/s²
Uncertainty: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2.3m/s²
Noise Power: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88dB(A)
Noise Pressure: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78dB(A)
CP20VBP2: . . . . . . . . . . . . . (Sold Seperately) 2ah Battery
CP20VBP4: . . . . . . . . . . . . . (Sold Seperately) 4ah Battery
CP20VMC: . . . . . . . . . . . . (Sold Seperately) Mains Charger
© Jack Sealey Limited
STRIMMER CORDLESS 20V - BODY ONLY
MODEL NO:
Wear protective Wear safety
gloves footwear
Original Language Version
CS20V
Wear protective Wear ear
clothing protection
Keep in dry area
protect from rain
devices.C
CS20V | Issue 1 10/12/18
