Summary of Contents for Precaster LDM60
- Page 1 NEW BENCHMARK OF MEASURING LDM60 LASER DISTANCE METER OPERATION MANUAL...
-
Page 2: Service Support
Service Support Please contact your local dealer or contact us through service email : [ reps@precaster.com.tw ] for further assistance. Safety Information a. This is a Class 2 laser tool, laser radiation is emitted from this product and is manufactured to comply IEC 60825-1: 2007, EN 60825-1:2007, EN 61326-1:2013 and CRF21, parts 1040.10 and... -
Page 3: Error Code
Out of working temperature Measure in an environment within specified working temperature Err07 Ambient light is too strong Measure in a darker place (shadow target) Specification Model LDM60 Measuring Range 0.05m~60m Resolution 0.001m Accuracy ±1.5mm Measuring Speed 0.5 seconds Laser Type 650nm, Class II, <1mW... - Page 4 LDM60 OPERATION MANUAL www.precaster.com.tw Overview A. LCD B. Single measure / Tap and hold continuous measure C. Addition D. Subtraction / Tap and hold to change unit E. Clear / Power F. Distance Measurement (Area -> Volume -> Stake out -> Single measure) / Tap and hold to set up (volume ->...
-
Page 5: Switch On And Off
NEW BENCHMARK OF MEASURING Battery Installation & Power Status i. This unit is powered by 2 x AAA Batteries. ii. Remove battery lid and observing correct polarity before install batteries. iii. When the icon appears , it mean fully charged battery. iv. -
Page 6: Unit Setting
LDM60 OPERATION MANUAL Measurement Addition & Subtraction 1. After measure, click , the data of measurement can be set to be added or subtracted. 2. In this case, the second measurement (Add/Sub) can be performed. The machine will automatically calculate the pen distance and the distance of the previous pen and display the result and the process on the screen. - Page 7 NEW BENCHMARK OF MEASURING · Stake-out distance 1. Click three times, to enable Stake-out distance. 2. Click , set up the length of stake-out, tap and hold can add the number quickly. 3. Click , you can switch Integer and decimal places. 4.
- Page 8 LDM60 OPERATION MANUAL www.precaster.com.tw · Third mode is Indirectly Height III ,you can get the altitude height 1. Click three times, enter the third mode of Indirectly Height III. 2. Follow the instructions on the main screen to measure the length of hypotenuse 1, the length of hypotenuse 2 and base to get the result of altitude height.
