INSTALLATION INSTRUCTIONS
HANGER RAIL ASSEMBLY
Mount the Add-a-Collars:
Model No: XACS-2PK
2
Add-a-Colar
Add-a-Plate
5
Mount the accessory rail:
6
Rail Frame
WEIGHT CAPACITIES
Product Name
Pair of Add-a-Collars
Hanger Rail
HD Wire Hook
Add-a-collars are
MQ9985 wedges.
included with the
3
7
Weight
200 LBS (90.7 KG)
25 LBS (11.3 KG)
10 LBS. (4.5 KG)
1
mounted to
the posts with
Wedges are
collar sets.
Product Name
Add-a-Collars
Bag of 4 Wedges
HD Wire
Hook
THIS COMPLETES INSTALLATION
OF THE HANGER RAIL ASSEMBLY
Wedge
4
Collar
Assembly
Replacement parts
Model No.
XACS-2PK
MQ9985
