  • Page 1 INSTALLATION MANUAL SCREENS V585 - V595...

  • Page 2: Table Of Contents

    INSTALLATION MANUAL SCREENS Index page Content package Required tools Specifications screen Specifications guiding rail Mounting (L)HTF-guiding rail 1.1 Drawing mounting holes 1.2 Drilling mounting holes in guiding rail 1.3 Mounting guiding rail Mounting (L)HTF + CLICK guiding rail 2.1 Mounting click cubes 2.2 Mounting guiding rail 2.3 Mounting (L)HTF + CLICK guiding rail without click cubes Hole control...

  • Page 3: Content Package

    INSTALLATION MANUAL SCREENS Content 1. Screen including screenfabric, operating type, bottom rail and operating box a. Manually: cord or strap b. Electrically: switch + plug c. Remote control: remote control + plug 2. Guiding rails (with spacers or clicking cubes) 3.

  • Page 4: Specifications Screen

    INSTALLATION MANUAL SCREENS Specifications screenbox Screen V585 Sizes in mm beveled straight Section box Screen V595 beveled straight Section box Subject to misprints, errors and technical modifications. 1787-190826EN...

  • Page 5: Specifications Guiding Rail

    INSTALLATION MANUAL SCREENS Specifications guiding rail Sizes in mm HTF + CLICK HTF + CLICK + LIP Section HTF guiding rail left Section HTF + CLICK guiding rail left Section HTF + CLICK + lip guiding rail left LHTF LHTF + LIP The extra lip on to the guiding rail gives the fabric extra protection against the clacking of the fabric.

  • Page 6: Mounting (L)Htf-Guiding Rail

    INSTALLATION MANUAL SCREENS 1 Mounting (L)HTF-guiding rails 1.1 Drawing mounting holes The guiding rails are not drilled yet. The number of holes and the placement of the holes depends on the surface and size of the screen. The surface can be wooden, metal or concrete. 1.

  • Page 7: Drilling Mounting Holes In Guiding Rail

    INSTALLATION MANUAL SCREENS 1.2 Drilling mounting holes in guiding rail HTF guiding rail: First drill a hole of 6mm through both layers of the guiding rail. Then drill the top hole with a 10 mm drill so that the screw fits through it. The plastic covering caps will be placed in these holes later on. LHTF guiding rail: Drill all holes with a 6mm drill.

  • Page 8: Mounting Guiding Rail

    INSTALLATION MANUAL SCREENS 1.3 Mounting guiding rail 1. Place the guiding rails against the wall or window frame. Make sure the guiding rails are perpendicular and are level with the wall or window frame. Based on the holes in the guiding rails you can now mark the drilling holes. 2.

  • Page 9: Mounting (L)Htf + Click Guiding Rail

    INSTALLATION MANUAL SCREENS Mounting (L)HTF + CLICK guiding rail 2.1 Mounting click cubes 1. Place the guiding rail vertically, at the correct width and height, against the wall or the window frame and determine the exact position of the click cubes. 2.

  • Page 10: Hole Control

    INSTALLATION MANUAL SCREENS Hole for control 1. Accurately draw a hole on the wall where the (electrical) cord/strap should go through for operation. This hole is exactly on the same heigth as where the (electrical) cord/strap comes out of the screenbox. 2.

  • Page 11: Finishing Mounting Outside

    INSTALLATION MANUAL SCREENS Finishing mounting outside 1. Close (if necessary) the mounting-holes with the covering caps. 2. Place (if necessary) the sealing caps at the bottom of the guiding rails (see figure on page 1). The sealing caps may NOT be placed if the screen rests on a windowsill or on the ground/pavement. If the sealing caps do get placed, an opening of a few millimeters will appear when closing the screen.

  • Page 12: Instruction Installing Manually Controlled (Inside)

    INSTALLATION MANUAL SCREENS Instruction installing manually controlled (inside) 1. Place the winding strap inside the house through the guiding wheel. Make sure the winding strap is not twisted. 2. Place the guiding wheel inside the hole. 3. Determine the position of the strap coiler inside the house and draw two holes on to the windowsill or wall.
  • Page 13 INSTALLATION MANUAL SCREENS 7. Guide the end of the strap through the strap coiler and place the hole over the lip, making sure it is tightly fastened. Be aware! Do NOT shorten the strap! You will need all the length of the strap when closing the screen. 8.

  • Page 14: Instruction Installing Electrically Controlled (Inside)

    INSTALLATION MANUAL SCREENS Instruction installing electrically controlled (inside) 1. Determine inside the house the position of the switch and draw two holes on the wall. 2. Drill the holes with a 6mm drill. Ø6 230 V 3. Open the switch with a flathead screwdriver.
  • Page 15 INSTALLATION MANUAL SCREENS 5. Connect the 4-wire cord from the motor and the 3-wire cord + plug to the following schedule. Consult an electrician if necessary Motor, left (seen from the outside) Motor, right (seen from the outside) 6. Mount the switch. In a situation with wireless remote control, the 3-wire cord can be connected directly to the plug box.
