- Page 1 INSTALLATION MANUAL RITZSCREEN® V540 V599 - V599R V599 L - V599 XL...
- Page 2 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Content 1. Screen cover with fabric and motor 4. Control 2. Side guides a. electrical: switch and plug a. back profile b. remote control: remote control and plug insert provided with neoprene (Ritz guide) c.
- Page 3 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Specifications Ritzscreens® Ritzscreen® V540 Measurements in mm section guide (G) right section bottom bar (O) Maximum ordering size V540 = 3000 mm section cover (K), bottom bar (O) and guide (G) Attention! The Ritzscreen® V540 is delivered with guides provided with predrilled mounting holes in the back profile. Only use flat counter-sunk screws.
- Page 4 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Specifications Ritzscreens® Ritzscreen® V599 L Measurements in mm section guide (G) right section bottom bar (O) maximum ordering height V599 L = 5000 mm Attention! The Ritzscreen® V599 L is delivered with guides provided with predrilled mounting holes in the back profile. Only use flat counter-sunk screws. Ritzscreen® V599 XL section guide (G) right section bottom bar (O) maximum ordering height V599 XL = 6000 mm section cover (K), bottom bar (O) and guide (G)
- Page 5 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Important before mounting General warning Mounting the Verano® product yourself is at your own risk. Only use this instruction as a tool and for the mounting of this specific Verano® product. If you cannot mount the product yourself, you can always opt for professional mounting. The mounting team of Verano® is pleased to help you. Be careful for damages Don’t use a knife or any other sharp object when opening the packing. This may cause damage to the content of the package. Put the content of the package on a soft surface. Be careful when drilling, falling drill cuttings can cause damages.
- Page 6 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Instruction placing the screen (outside) The guides consist of three parts: a. back profile b. insert provided with neoprene (Ritz guide) c. front profile These three parts are pushed together in the package. Separate the parts before mounting. 1.1 Marking the mounting holes in the back profile (only for V599 –...
- Page 7 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL 1.2 Drilling the mounting holes in the back profile The screw holes need to be duplicated. The profile is provided with a drill line as an aid tool for the drilling. View figure 1.2. 1. Drill a hole of 6 mm through both layers in the back profile of the guide. 2. After that, drill the hole with a 10 mm drill so that the screwdriver fits through. Outside Mount op de dag > 100 mm 6 mm 10 mm Inside Mount in de dag <...
- Page 8 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL 1.4 Mounting the V540/V599 L guide The Ritzscreen® V540 and V599 L is supplied with guides with predrilled mounting holes in the back profile. This occurs in a fixed pattern. At screens with a total height up to 1800 mm, the guides are provided with two holes: 1 hole 100 mm from the top and 1 hole 100 mm from the bottom. At screens with a total height of more than 1800 mm, the guides are provided with three holes: 1 hole 100 mm from the top, 1 hole 100 mm from the bottom and 1 hole in the middle. Outside Mount op de dag in de dag Inside Mount 1. Place the back profile of the guides against the façade or the window frame as described in paragraph 1.1. Make sure that the guides are perpendicular and equal to the wall. The marking of the drill holes on the wall or the window frame can be made on the base of the holes...
- Page 9 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL 1.5 Hole for control 1. Accurate mark the inside transit hole for the control cord. This hole needs to be at exactly the same height as the point where the control cord comes out of the screen! 2. Drill the hole for the wall transit with a 10 mm drill. 3. Check before drilling if there are no pipes or other lines in the wall! 4. Always use a shelf on the inside of the house, so that the stucco can not be damaged. 1.6 Placing the screen cover on the guides 1. Lift the cover with two people. 2. Perform the electrical cord through the drilled hole to the inside. 3. Slide the cap supports, that extend under the screen cover, in the back profile of the side guides. Be extra careful while tdoing this. The cap supports are very vulnerable.
- Page 10 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL 1.7 Sliding the zipper into the guide 1. Place the insert (Ritz guide) (b), with the V-profile up, a little oblique in the back profile (a). 2. Slide the edge of the zipper from the top in the V-profile of the Ritz guide (b). Make sure that it fits well in the gap! Push the Ritz guide (b) then all the way up into the back profile. 3. Mount the front profile (c) on the back profile (a) with the included screws. 4. The mounting of the screen is now almost finished. fig. 1.8 Mounting the guide 1.8 Finish outside mounting Lute the upside and the sides of the cover in order to prevent water from running through the cable to the inside. The use of transparent lute is advised. Subject to misprints, errors and technical modifications.
- Page 11 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL Instruction placing the electrical control (inside) 1. Determine the position of the switch inside the house and mark two holes on the wall. 2. Drill the holes with a 6 mm drill. Ø6 230 V 3. Open the switch, using a flat screwdriver. 4.
- Page 12 INSTALLATION MANUAL RITZSCREEN® V540 - V599 - V599R - V599L - V599 XL 5. Connect the 4-wired cord of the motor and the 3-wired cord and plug following the scheme below. Check an installer when needed. Motor left (seen from the outside) Motor right (seen from the outside) 6. Mount the switch. At a situation with a wireless remote control, the 3-wired cord can directly be connected to the socket. 7. Insert the plug into the socket and turn the power on. Optional Optioneel The screen is now ready to be...
