D-Torch with Quartz Outer Tube for ELAN
BEFORE YOU START
Congratulations on the purchase of your D-Torch.
For your reference, the D-Torch is made up of three components; these can be ordered separately, refer Table 1
D-torch is supplied with a pair of gloves; always wear clean gloves when handling ICP Torches and their components.
Item No.
Part Number
1
31-808-2847
2
31-808-2848
3
31-808-2818
4
SAFEGLOVE-MED
Scope
1.
Precautions for personal safety and Torch preservation
2.
How To Remove Outer Tube from Torch
3.
How To Re-Attach Outer Tube to Torch
Special tools, requirements, etc
Safety glasses
Safety gloves (Item 4 supplied)
Basic competence in making connections to ICP
1.
Precautions for personal safety and Torch preservation
Always wear safety gloves and glasses when removing (or replacing) ICP Torches
The Torch is made from high grade engineered materials – Handle with extreme care
Do not allow the Torch to be placed on hard surfaces or allow it to come into contact with hard objects
Note! It is recommend you review and understand this procedure before handling the Torch assembly
Glass Expansion
©
Base and Inner Tube
Quartz Outer Tube
Retainer
Safety Gloves
Item 1
Version 1.3
30-807-0540
Description
Item 2
Item 3
INS-0050
Qty
1
1
1
1 Pair
Item 4
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Glass Expansion D-Torch
Summary of Contents for Glass Expansion D-Torch
- Page 1 Congratulations on the purchase of your D-Torch. For your reference, the D-Torch is made up of three components; these can be ordered separately, refer Table 1 D-torch is supplied with a pair of gloves; always wear clean gloves when handling ICP Torches and their components.
- Page 2 D-Torch with Quartz Outer Tube for ELAN 30-807-0540 How to remove Outer Tube The Torch outer tube is accurately located in place with the retainer. The outer tube can be removed at any time by completing the following steps. Note! A tapered ferrule is permanently fixed to the to the outer tube – Do not attempt to remove the ferrule from the tube.
