- Page 1 Zuid Hollandlaan 7 2596 AL Den Haag The Netherlands Phone: +31 0 85 0441855 (NL) E-mail: info@evvelongrange.com Web : www.evvelongrange.com MK-1900HD Series...
- Page 2 EVVE LONG RANGE ADDITIONAL INFORMATION & RELATED DOCUMENTS FCC COMPLIANCE SUPPORT SERVICES RETURNS SHIPMENT SAFETY INSTRUCTIONS 1. INTRODUCTION: EQUIPMENT SUPPLIED 2. INSTALLATION: BUILDING THE CAMERA...
- Page 3 Evve Long Range website at: www.evvelongrange.com/downloads 17xxHD - High Definition Demonstration Camera Positioning System Copyright 2019 by Evve Long Range B.V (ELR). ELR has intellectual property rights to technology embodied in the product described in this manual. Evve Long Range and Evve International BV are trademarkt of BOTHA BV.
- Page 4 This equipment has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy, and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
- Page 5 IMPORTANT! If the camera needs to be shipped, please use the original packaging material which was designed to protect the product during transportation. If the original packaging is lost or damaged, please order a replacement at ELR. 17xxHD - High Definition Demonstration Camera Positioning System WARNING: Power supplies used with these cameras operate on 115 Vac or 230 Vac.
- Page 6 SAFETY INSTRUCTIONS The Evve Long Range products are part of the next generation of Long Range camera systems, ranging from high-definition (HD) to standard-definition (SD) camera positioning systems. The systems are IP (Internet Protocol) based with a full function built-in operating system. Operator functions features are controlled from the On Screen Display (OSD).
- Page 7 POWER BOX & CONNECTION CABLES PT UNIT & CONNECTION BOX CAMERA HOUSING WITH SUNSHIELD 12 BOLTS (M12 STAINLESS STEEL) & ALLEN KEY SET Installation Manual 1900HD Series...
- Page 8 This chapter covers the general installation and cable requirements of the MK1900HD series. - High Definition Demonstration Camera Positioning System NOTE: Before starting installation: Choose a flat surface or bracket. Have the bolts available. Do NOT power the systems until all devices are connected. ...
- Page 9 1. Place the camera base in the correct position to mount the bolts. 2. Check if the bolts are securely fastened. 3. Mount the powerbox at the correct position. 4. IMPORTANT: Check the position of the connector and align the camera housing with the drive shaft following the markers on the camera housing and on the drive shaft.
- Page 10 BUILDING THE CAMERA 5. Slide the camera housing on the drive shaft. 6. Secure the bolts on the drive shaft. 7. Connect the power and data cable from the power box to the camera. 8. Turn on the power. INFORMATION: Standard IP-address 192.168.178.150:8080 Analog: 192.168.178.151:80 Log in: admin | Password: 1234...
- Page 11 - High Definition Demonstration Camera Positioning System Zuid Hollandlaan 7 2596 AL Den Haag The Netherlands Phone: +31 0 85 0441855 (NL) E-mail: info@evvelongrange.com Web: www.evvelongrange.com Installation Manual 1900HD Series...
