- Page 1 USER GUIDE PoE & optical transmission 16-ports Gigabit PoE switch (GGM GS16P)
- Page 2 GIGAMEDIA - 16 ports Gigabit PoE Switch Statement Copyright @ 2002-2013 our company. All Rights Reserved. No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any lan- guage, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise without the prior written permission of our company.
- Page 3 GIGAMEDIA - 16 ports Gigabit PoE Switch Product overview Product introduction The full Gigabit Ethernet PoE switch can provide seamless connection for 10/100/1000M Ethernet network and equipped with PoE function, can be used as Ethernet power supply device (PSE). It can automatically identify the connected devices whether compatible with IEEE 802.3af or IEEE 802.3at standards, and then supply power for them.
- Page 4 GIGAMEDIA - 16 ports Gigabit PoE Switch Technical structure and port description 275 mm 44.5 mm 100/1000M 16G+2G SFP PORT GIGABIT SWITCH 100/1000M 10/100/1000M GIGABIT SWITCH 440 mm 100/1000M 16G+2G SFP PORT GIGABIT SWITCH 100/1000M 10/100/1000M GIGABIT SWITCH ACIN 100-240V A.
- Page 5 GIGAMEDIA - 16 ports Gigabit PoE Switch Indicator description Indicator Status Description Yellow LED ON Normal power supply Power LED: PWR Power OFF Green LED ON Connected the pd device, working normally PoE Working LED: PoE Green LED Blink Short circuit or current overload...
- Page 6 GIGAMEDIA - 16 ports Gigabit PoE Switch Installation guide Please install with the matched devices. Installation Please confirm the following things before installation: 1. If the POE port power meets the power requirement of the connecting devices. 2. If the POE standard requirement and power supply matches with the power receiving device [1/2+, 3/6-(End-span) / 4/5+, 7/8-(Mid-span)].
- Page 7 GIGAMEDIA - 16 ports Gigabit PoE Switch Connection diagram Power PoE switch Monitor Fiber media converter CAT5 cable Video line CAT5 cable PoE IP camera GIGAMEDIA - www.gigamedia.net...
- Page 8 GIGAMEDIA - 16 ports Gigabit PoE Switch Products model & description GGM GS16P: 16-Port 10/100/1000M PoE switch + 2 empty SFP slots. Transmission distance is 100 m,1-16 port support PoE, IEEE 802.3af, single port power is 15.4 W, the total power is 250 W, built-in power.
