Hanse 300 Yachtzentrum Greifswald List of Contents Page General Introduction Admission, Certification Design Category Identification Builder's Plate Declaration of Conformity Applied Standards Warning Notices Description of the Boat Principal Dimensions Light Weight. Maximum Number of Persons and Loading Capacity Motorization...
EC Directive (see Declaration of Conformity), is authorized to do this verification. 1.3 Design Category The sailing yacht Hanse 300 is classified as design Category B. The Directive describes Design Category B as follows: Design Category B: Offshore Designed for offshore voyages where conditions up to, and including, wind force 8 (Beaufort- Scale) and significant wave heights up to, and including, 4 m may be experienced.
Hanse 300 Yachtzentrum Greifswald 1.5 Builder’s Plate The builder's plate of the yacht is on the front wall of the cockpit. Explanations – Boat design category B: Offshore – Max. = 5 = 375 kg: Maximum number of persons recommended by manufacturer if boat is underway in the relevant sea according to its design category.
Hanse 300 Yachtzentrum Greifswald .6 Declaration of Conformity EC- Declaration of Conformity in compliance with EC Directive 94/25/EC relating to Recreational Craft, Annex XV We hereby declare that the boat, thereafter described in more detail complies with the essential safety and health requirements as laid down in the EC Recreational Craft Directive regarding its concept and construction as well as the model placed on the market by us.
Hanse 300 Yachtzentrum Greifswald 1.7. Applied Standards Applied harmonised standards and/or draft standards relating to the paragraphs of Directive 94/25/EC. (Please note: Sections of the standards containing requirements for the Manual were not applied or applied only in part.) EC Directive Standards 1.
2.3 Motorization For further information see operating instructions for the engine and contract specification. The maximum rated engine power of the HANSE 300 is 15 hp / 11 kW. NOTE! Please take note of the operational instructions for the engine system and the remarks regarding its operation, maintenance and care.
Hanse 300 Yachtzentrum Greifswald 2.6 Attachment Points for Lifting Gear, Support Points for Transport (Graphic representation does not correspond to the make of the boat) Lifting by Crane The belts should be placed in compliance with the stability of the hull and the distribution of weight so that the watercraft is in an as much as possible horizontal position.
Hanse 300 Yachtzentrum Greifswald 3.1 Watertight Integrity The watercraft has a self-draining cockpit so that breaking sea and rain are drained to the outside. It may be necessary to close the hatches and entrances in case of danger of flooding.
Hanse 300 Yachtzentrum Greifswald Instruct your crew in the handling of fire extinguishers! The fire extinguishers are at the marked positions! The yacht is furnished with two fire extinguishers, at least fire class 10A/68B. ATTENTION! Observe the inspection periods for fire extinguishers and make sure that they are always ready for use.
Hanse 300 Yachtzentrum Greifswald Drinking water is to be filled in the inlet on deck marked accordingly (Wasser or Water). ATTENTION! When drinking water is stored over a longer period of time pathogens may develop. Please use appropriate licensed agents against germination! Exchange the water at regular intervals and flush the tank! 3.6 Sea Water...
Hanse 300 Yachtzentrum Greifswald only position lights at night, lights at the chart table only when it is used, navigation instruments may be in stand-by position. The general lights should also be switched on only when directly required. You should turn off the refrigerating box, radio, autopilot or other users that require a lot of energy.
Hanse 300 Yachtzentrum Greifswald Check, whether the cooker valve is closed! Open the cylinder valve! Open the valve in front of the cooker! Open one of the burner valves, keep it pressed (ignition lock) and light the gas! Keep the valve pressed down until the flame is stable! When switching off you should observe the following order, in particular for a longer interruption: Close the valve on the gas cylinder, the flame dies out.
Hanse 300 Yachtzentrum Greifswald Openings in the hull are potential dangers for ingress of water. They require your special attention. They are manually operated, therefore their condition needs regular checking. All underwater through-hull fittings may be closed with a sea valve. You should always close them if you leave the boat unattended for a longer period of time.
Hanse 300 Yachtzentrum Greifswald 3.17 Manuals and Operating Instructions Manuals, operating instructions etc. may be supplied in compliance with the contract specifications. WARNING! Please read them carefully and take note of the guidelines and notes contained therein! 4. Environmental Information Sailing is a quiet sport.
Hanse 300 Yachtzentrum Greifswald Waste Water The toilet produces most of the waste water on board. You should collect it in the tank and dispose of it on shore. It makes sense, when in port, to use always the facilities available in the ports.
Page 18
Hanse 300 Yachtzentrum Greifswald not replace your own personal seamanlike diligence as owner or skipper. We, the shipyard, have handed over a safe and reliable sailing yacht which will withstand stress when used, according to the acknowledged rules of engineering and in compliance with the European Recreational Craft Directive.
Hanse 300 Yachtzentrum Greifswald 8. Proof of Identity (To be filled by dealer and/or contracting partner) 1. First launch: ................2. Date (supply to owner): ................3. Type of boat: ................4. Hull identification and/or construction no.: ................5. Contract no.: ................
Hanse 300 Yachtzentrum Greifswald 9. Acknowledgement of Receipt Please return with signature to: Dealer address: Acknowledgement of Receipt Name: ................Address: ................................Hanse 300 DE-YZG01263B505 Owner of This watercraft is covered by the warranty which has been handed over with the craft.
