Delta-Therm TT Series Installation Instructions

B C
A E G
F
H
I
J
K
A. Heat Shrink Sleeve .375" x 6" (1 x 15cm)
B. Cable Connector Assembly
C. Standoff Bracket
D. High Temp Fiberglass Tape (60" x 1/2")
E. Heat Shrink Sleeve .5" x 1.5" (1 x 11cm)
F. Ground Screw
G. Closed-End Crimp Connectors (2)
H. Ring Connector
I. .75" Sealing Locknut
J. Heat Shrink Sleeve .25" x 1.5" (.5 x 11cm)
K. Heat Shrink Sleeve .125" x 2.5" (.3 x 6cm)
L. Caution Labels (6) Small
TOOLS NEEDED
• Crimping Tool
• Wire Stripper/Cutter
• Utility Knife
• Flat-Blade Screwdriver
• Needle-Nose Pliers
• Adjustable Wrench
• Heat Gun (750F)
• Measuring Tape
WARNING:
This kit and the cable used with it must
be installed by a qualified electrician. All assembly,
installation, and test instructions must be followed.
Improper installation can result in property damage,
serious injury, and/or death due to electric shock and fires.
Please call Delta-Therm Corporation at 1-800-526-7887
with any installation or operating questions.
DELTA-THERM Corporation, 6711 Sands Road Suite A, Crystal Lake, IL 60014
D
L
Installation Instructions
TT Series for Pipe Tracing
CONNECTINg TO POwER
For braided Cable
Remove 6" (15cm) of any optional overjacket.
1.
Push the braid back to loosen it.
2.
Approximately 6" (15cm) from the end of the
3.
cable, spread the braid strands to create an
opening.
Detail 1.
Bend the cable at the opening, then pull the cable
4.
through the opening to free the braid.
Twist the braid into a cold lead, then trim the cold
5.
lead to remove the tapered end.
6. Insert the cable through the connector cap, the gland
washer, and the grommet, leaving 4" (10cm)
exposed from the end of the rubber grommet.
Detail 2.
continued...
(847) 526-2407 Fax (847) 526-4456
PCK-TT
