- Page 1 I N S T A L L A T I O N · O P E R A T I O N · M A I N T E N A N C E G U I D E UNDERMOUNT RANGEHOOD SCRH60...
-
Page 2: Table Of Contents
Index Welcome ............................3 Before Installation ..........................4 Maintenance and Service ...........................5 Maintenance and Service .........................5 Optional Charcoal Filter (only for recirculation) ....................6 Electrical Cord ..............................6 For Users ................................7 Replacing the Light Bulb ............................7 Description .............................8 Main Rangehood ..............................8 Operation ............................9 Switch Control ..............................9 Installation ............................10 Mounting Instructions ............................10 For Installers ................................11... -
Page 3: Welcome
1. Welcome Welcome Thank you for purchasing this Scandium appliance. To achieve the optimal performance from your appliance, and to avoid the risk of accident or damage, it is essential to read this manual before installation and first time use. -
Page 4: Before Installation
2. Before Installation Important • Upon collection or delivery of the appliance, any damage or defects MUST be reported within 48 hours to the retailer or the customer service centre, or no claim will be recognised. • Before installing the electrical connections, you should: –... -
Page 5: Maintenance And Service
3. Maintenance and Service is fulfilled. Even a partial obstruction will restrict the efficiency of the rangehood. • Stainless steel is very easily damaged during installation if scratched or knocked by tools. Protect the rangehood with the cardboard box or a plastic bag during installation. •... -
Page 6: Optional Charcoal Filter (Only For Recirculation)
3. Maintenance and Service • Remove the grease filters and wash them either by hand using hot soapy water or in the dishwasher using mild detergent. DO NOT scrub. NOTE: some discolouration of the frame may occur when washing in the dishwasher. CAUTION Never use abrasive or oil based liquid cleaners. -
Page 7: For Users
3. Maintenance and Service For Users • This product is designed for domestic use only and should NOT be used outside or for commercial applications. • After use, always ensure controls are left in the “OFF” position. When frying with a gas flame, take particular care not to allow the oil or grease in the pan to catch fire. -
Page 8: Description
4. Description Main Rangehood Male Plug (Main Power 240V) Ducting Outlet 120mm Filters Halogen lights NOTE: Filter and light quantity may vary from model to model. Page 8... -
Page 9: Operation
5. Operation Switch Control This rangehood is fitted with a limit switch. Retracting telescopic arm will cut off power to the motor. The limit switch does not cut power to the lighting. This rangehood is operated by means of switch controls located in the front part of the rear panel, behind the slide out panel. -
Page 10: Installation
Rangehood distance less than the minimum height specified above the cooking Distance surface, Scandium declines responsibility for any damages suffered by the rangehood due to excess heat or damage to objects, people and Cooktop others caused directly or indirectly by a malfunction, breakage or fire. -
Page 11: For Installers
6. Installation For Installers • In addition to size, the height of the rangehood above the cooktop is important to obtain the best performance. OPTIMAL ADEQUATE NOT RECOMMENDED Rangehood bigger than the Rangehood equal to the Rangehood smaller than the cooking area. -
Page 12: Installation Guide
6. Installation Installation Guide WARNING Please remove filters before installations. Failure to do so may damage the filters. Back draft and Step 1 ducting adapter To install the back draft and ducting adaptor, place it on top of the outlet and gently press the sides to clip it onto the outlet. - Page 13 6. Installation Step 4 Fix rangehood into cabinetry using mounting points. Secure the side of the rangehood by Secure the top of the rangehood by using the screws provided. using the screws provided. Page 13...
- Page 14 6. Installation Step 5 Attach the ducting to adaptor and feed through the cabinetry. Keep ducting length to a minimum, no longer than 3m. DO NOT reduce ducting diameter. DO NOT kink ducting and avoid sharp bends. Page 14...
-
Page 15: Ducting Installation
6. Installation Ducting Installation Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Figure 6 Page 15... -
Page 16: Roof Cowls / Roof Seal
6. Installation Roof Cowls / Roof Seal WARNING Electrical connection MUST be accessible. Roof Cowls* Flexible Ducting must be pulled taut. DO NOT crush or kink the ducting. Connect flexible ducting to the outlet on rangehood using duct tape or cable ties. Please DO NOT rip the ducting. -
Page 17: Ducting
6. Installation Ducting Please DO NOT crush or kink ducting, as it will reduce air flow and may cause noise to occur through the system. Ducting needs to be kept taut at all times. Page 17... -
Page 18: Condensation Information
• Installation distance from cooktop to the rangehood • Speed of food & liquid heating • Angle of ducting – Scandium ‘S’ bend preferred • Filter size - larger canopy preferred • Quality of pots or cookware you are using – high quality recommended How to reduce the possibility of condensation forming: •... -
Page 19: Troubleshooting
It is not the responsibility of Scandium to rectify any incorrect installations. A service call out fee will be charged for any Scandium technician that attends a call, whereby it is established that the fault is due to an incorrect installation or non-manufacturing fault. Should the appliance be installed in such a way that the service agent is unable to gain access to the appliance, the person/s who own the premises or the property where the appliance resides —... -
Page 20: Specifications
9. Specifications Technical Specifications Model SCRH60 Feeding Voltage 240V 50Hz Lamp Power — Halogen (W) 2 x 20W (supplied) Weight 6.7kg Measurements in mm. Page 20... -
Page 21: Disclaimer
All information supplied is to be used for general reference purposes only and is on the understanding that Scandium will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only. - Page 22 Notes Page 22...
- Page 23 Notes Page 23...
- Page 24 Australia 8/3-4 Anzed Court, Mulgrave VIC 3170. Phone 1300 829 066 Email info@scandiumappliances.com.au Web www.scandiumappliances.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. V1090817 ACN 124 141 322...
