- Page 1 I N S T A L L A T I O N · O P E R A T I O N · M A I N T E N A N C E G U I D E RANGEHOOD SC900WRS, SC900WTS...
-
Page 2: Table Of Contents
Index Welcome ............................3 Before Installation ..........................4 Maintenance and Service ...........................5 Maintenance and Service .........................5 LED Bulb Replacement ............................6 Electrical Cord ..............................6 For Users ................................6 Description & Installation .........................7 Rangehood Contents ............................7 Operation ................................7 Cutout Size ................................7 Installation ............................8 Mounting Instructions ............................8 For Installers ................................8 Mounting Points ..............................9 Installation Example ............................10... -
Page 3: Welcome
1. Welcome Welcome Thank you for purchasing this Scandium appliance. To achieve the optimal performance from your appliance, and to avoid the risk of accident or damage, it is essential to read this manual before installation and first time use. -
Page 4: Before Installation
2. Before Installation Important • Upon collection or delivery of the appliance, any damage or defects MUST be reported within 48 hours to the retailer or the customer service centre, or no claim will be recognised. • Before installing the electrical connections, you should: –... -
Page 5: Maintenance And Service
3. Maintenance and Service • Stainless steel is very easily damaged during installation if scratched or knocked by tools. Protect the rangehood with the cardboard box or a plastic bag during installation. • CAUTION: Accessible parts may become hot when used with cooking appliances. •... -
Page 6: Led Bulb Replacement
3. Maintenance and Service mild detergent. Do not scrub. NOTE: some discolouration of the frame may occur when washing in the dishwasher. CAUTION: Never use abrasive or oil based liquid cleaners. • If the grease filters are very dirty, the motor will extract only a small quantity of air, which reduces its efficiency. -
Page 7: Description & Installation
4. Description & Installation Rangehood Contents Mounting Bracket Extension Flue Piece Main Flue For use with Isodrive motor system Male Plug (Main Power 240V, 10 amp connection) Single Outlet 200mm Reducer (For use with HiFlow VX120 motor) Filter Lamp Note: Filter and light quantity may vary from model to model. -
Page 8: Installation
Rangehood distance of less than minimum height above the cooking surface, Distance Scandium declines responsibility for damages suffered by the rangehood due to excess heat or damage to objects, people and Cooktop others caused directly or indirectly by a malfunction, breakage or fire. -
Page 9: Mounting Points
5. Installation Mounting Points The diagrams below are a guide for all mounting points. For SC900WRS Model R3.5 R3.5 Main Mounting Points For SC900WTS Model R3.5 R6.85 Page 9... -
Page 10: Installation Example
5. Installation Installation Example Step 1 Secure rangehood to the wall using only primary mounting points. Check the level of the rangehood and adjust accordingly if necessary. Once level, continue to secure the rangehood via the secondary mounting points. Step 2 Feed through aluminium flexi duct from the outlet block to the kitchen ceiling. -
Page 11: Overview
5. Installation Overview Hi Flow VX120 Motor Roof Seal Kit (Dektite)* Support Straps* Attach Flexi Duct to Bell-Mouth Adaptor using duct tape and cable tie. DO NOT rip the ducting. Motor Power Lead (Male Plug) Rangehood to Motor Lead (Female Plug) Main Power Lead (Male Plug) Flexi Ducting must be pulled taut. -
Page 12: Condensation Information
• Installation distance from cooktop to the rangehood • Speed of food & liquid heating • Angle of ducting – Scandium ‘S’ bend preferred • Filter size - larger canopy preferred • Quality of pots or cookware you are using – high quality recommended How to reduce the possibility of condensation forming: •... -
Page 13: Troubleshooting
Faulty Installation It is not the responsibility of Scandium to rectify any incorrect installations. A service call out fee will be charged for any Scandium technician that attends a call, whereby it’s established that the fault is due to an incorrect installation or non-manufacturing fault. -
Page 14: Specifications
8. Specifications Dimensions For SC900WRS Model For SC900WTS Model Technical Specifications Model SC900WRS, SC900WTS Feeding Voltage 220-240V 50Hz (10 amp GPO) Lamp Power (Incandescent) 2 x 25W Page 14... -
Page 15: Service & Disclaimer
All information supplied is to be used for general reference purposes only and is on the understanding that Scandium will not be liable for any loss, liability or damage of whatever kind arising as a result of any reliance upon such information. All pictures used in the guide are for illustrative purposes only. - Page 16 Australia 8/3-4 Anzed Court, Mulgrave 3170 Victoria. Phone 1300 881 693 Email info@scandiumappliances.com.au Web www.scandiumappliances.com.au New Zealand 5 Tolich Place, Henderson, Auckland 0610. Phone 0800 200 510 Email info.parex@emerson.com Web www.parex.co.nz Distributed by Axis Group International Pty Ltd. ACN 124 141 322 V1270717...
