HDMI EXTENDER ovER Ip
RFq
q: TV display "Waiting for connection" on the right corner?
A: Please check if the power supply of TX (Sender) and switcher (if
used) is connected, and make sure connecting cable is firmly.
q: TV display "Please check the TX input signal" ?
A : 1) please check if there is a HDMI signal input of TX.
2) Try to connect the signal source directly to display device to
see if there is signal output from source device or change the
signal source, HDMI wire and try again.
q: Display not fluent, not stable?
A: 1) Please check the cable length between the TX to switch, the
switch to the RX and the connection between each level is within
the required range.
2) Click the "reset" button on the TX/RX front panel, reset and
reconnect.
SPECIFICATION
Items
HDMI signal
Transport protocol
Network cable
Transmission distance
IR Signal
Working temperature
Power Supply
Power consumption
Dimensions
Weight
Color
Maintenance: Clean only with a dry cloth. Do not use cleaning
solvents or abrasives.
Warranty: No guarantee or liability can be accepted for any changes
and modifications of the
product or damage caused due to incorrect use of this product.
This product is marked with this symbol. It means that
used electrical and electronic products should not be
mixed with general household waste.
There is a separate collections system for these
products in compliance with EU Directive WEEE.
With the CE sign, Techly® ensures that the product is
conformed to the basic European standards and directives.
Specifications
Compatible with HDCP
480i@60Hz, 480p@60Hz, 576i@50Hz,
576p@50Hz, 720p@50/60Hz,
1080i@50/60Hz, 1080p@50/60Hz
UTP/STP Cat5E/6
Up to 120m transmission distance
for 1080p 60Hz Full HD over single
CAT6
Supports 20-60KHz IR devices
0°C – 60°C
DC5V/1A
TX: 3.5W; RX: 3W
96.8 (W) x 94 (D) x 23.7 (H) mm * 2pcs
TX: 145g RX: 142g
Black
EN
