Paramount ME User's Guide

Guider Jack Wiring Specifications

The Adaptor Panel's Guider port accepts a male RJ12 modular connector and provides
access to the directional switching used during autoguiding.
6 5 4 3 2 1
Figure 73: Pinout
diagram for the
camera guider port.
Figure 74: Diagram showing the pinouts for the guider cable and the camera and guider ports.
*Note: The actual wire colors may differ.
T his information may be used with SBIG ST-4, ST-5, ST-6 and SG-4 cameras.
†
P P
See the section labeled "Guide Port" in the
autoguider cable specifications.
®
Radio Shack

Cross Reference

P P
The table below shows the Radio Shack® part number of several Adaptor Panel
components.
102
Pinouts for the Male RJ12 End of Guider Cable that Plugs into the
RJ12 pin
Color*
1 WHT
2 BLK
3 RED
4 GRN
5 YLW
6 BLU
SG-4 Autoguider Operating Manual
Camera Guider Port
Description
+X
+Y
–Y
–X
Ground (common)
NC (not connected)
†
SBIG DB15 pin
P P
10
13
7
4
5,8,11,14
for SBIG
