- Page 1 Whyte 5 WIRE TAPS & SPLITTERS INSTRUCTION MANUAL MODELS: WT51-10 WT51-20 WT52-10 WT52-20 WT53-10 WT53-20 WS52-05 www.whytetechnologies.com...
-
Page 2: General Description
CONTENTS GENERAL DESCRIPTION Whyte Series 5 Taps & Splitters are a range of 5 wire passive devices that distribute IF and Terrestrial Signals. The range includes 1 way, 2 way and General Description 3 way Taps with either 10dB or 20dB tap-offs and a 2 way Splitter with 2 x 4dB tap-offs. - Page 3 EXAMPLE 5 WIRE EXAMPLE 5 WIRE SAFETY 4-WAY SPLITTER 5-WAY SPLITTER Whyte Series 5 Taps and Splitt ers are intended for indoor use only. Do WT52-10 WT52-10 not install the Taps and Splitt ers in damp, humid, hot or dusty areas. WS52-05...
-
Page 4: Example Application
Input: 110 - 240VAC 50/60Hz Output: 18V 2.5A TERR WT52-20 5 Wire 2 Way Whyte DC IN 18V Tap - 20dB TERR: Freq Range 47~790 MHz Trunk Loss 2dB Tap Loss 20dB SAT: Freq Range 950~2150 MHz Trunk Loss 3dB Tap Loss 20dB... - Page 5 Whyte Whyte Technologies Unit 12-13, Watermill Business Centre Edison Road Enfield, En3 7XF Phone: 0330 999 1980 E-mail: info@whytetechnologies.com Support: technical@whytetechnologies.com @WhyteTech Whyte Technologies @WhyteTechnologies @WhyteTechnologies www.whytetechnologies.com...
