  • Page 1 Instruction Manual Care Bed Libra Last updated: 31-05-2019 275739_v1...
  • Page 2 Instruction Manual for Libra Care Bed Libra care bed In this instruction manual, numbers which appear in round brackets () and bold type refer to the care bed’s operating devices as shown in this and the following images. Position Designation...
  • Page 3 “Vario Safe system” split safety side (telescopic on both sides) “Easy-floor-access” double castors (head and foot end) (individual axle braking) Libra beds can also be supplied without safety sides. Refer to Chapter 4.5.5 for more information about this Page 3...

  • Page 4: Table Of Contents

    Instruction Manual for Libra Care Bed Contents FOREWORD ........................6 GENERAL INFORMATION ....................7 2.1 efinition of the Groups of Persons Involved ............ 8 2.2 Safety Information ..................9 2.2.1 Explanation of the Safety Symbols Used ..........9 2.2.2 Safety Information for the Operator ............. 10 2.2.3...
  • Page 5 Instruction Manual for Libra Care Bed 4.5.2 Special Safety Information for Safety Sides ......... 56 4.5.3 Combined Safety Sides * ..............58 4.5.4 Split Safety Sides * ................63 4.5.5 Variant - Without Safety Side * ............. 74 4.5.6 Comfort Mattress Base - 90 cm width * ..........75 4.5.7...

  • Page 6: Foreword

    It is a practical reference book and should be kept close to hand at all times. Even after purchasing a bed, Stiegelmeyer is still on hand to help at any time. Our Assist business division can provide you with customised solutions in all matters relating to inspection and maintenance, repair and process optimisation.

  • Page 7: General Information

    Instruction Manual for Libra Care Bed 2 General Information The Libra care bed is simply referred to as the 'bed' or 'care bed' in this instruction manual. In addition to the standard functions of the bed, this instruction manual also describes optional functions and special bed equipment which might not apply for the model that you have selected.

  • Page 8: Efinition Of The Groups Of Persons Involved

    In this instruction manual, the following groups of persons are defined as: Operator The operator (e.g. nursing homes operators) are all natural and legal persons with property rights to the Libra care bed. The operator is responsible for the safe operation of this medical device. Users Users (nursing staff, carers and attendants, ...) are persons who, based on their...

  • Page 9: Safety Information

    Instruction Manual for Libra Care Bed 2.2 S AFETY NFORMATION At the time of leaving the factory, this bed represents state-of-the-art technology. Only use the bed if it is in perfect working order. The most important objective of the safety information is to prevent personal injuries.

  • Page 10: Safety Information For The Operator

    Check that your staff are complying with the safety information! Allergic reactions when using upholstered components Please note: The headboards, footboards and side-panels of the Libra bed can be supplied in the upholstered version according to customer specifications. If the resident is especially sensitive and tends to allergic...

  • Page 11: Safety Information For The User

    Instruction Manual for Libra Care Bed 2.2.3 Safety Information for the User Route the mains cable in such a way that it cannot be pulled, driven over or damaged by moving parts when the bed is operated. At regular intervals, carry out a visual inspection of the mains cable to check for mechanical damage (scuffing, exposed wires, kinks, pressure points, etc.).
  • Page 12 Instruction Manual for Libra Care Bed Ensure that the operator instructs you in the safe operation of this bed. Each time before using the bed, check that it is in perfect working order to prevent unnecessary hazards for the resident and delays to work procedures (see also Chapter 3.1).

  • Page 13: Product Description

    Instruction Manual for Libra Care Bed 2.3 P RODUCT ESCRIPTION 2.3.1 Purpose This bed is designed for positioning and transporting patients, as an aid to diagnosing, monitoring, treating, and alleviating illnesses or compensating for injuries or disabilities. For detailed instructions for use, see Chapter 9.7.

  • Page 14: Side Effects

    Instruction Manual for Libra Care Bed This bed may only be used under the operating conditions described in this instruction manual. Any other use shall be regarded as contrary to the intended purpose! 2.3.2 Contraindications This bed is only suitable for residents who do not fall below the...

  • Page 15: Optional Electrical Features

    Instruction Manual for Libra Care Bed 2.3.5 Optional Electrical Features Electrical setting of Trendelenburg position: An external operating device (handset) allows medical staff to place the resident in an emergency position whenever necessary LED reading light: Energy-saving, no hazardous heating as with conventional lamps, resistant to jolts and vibrations;...

  • Page 16: Materials Used

    Instruction Manual for Libra Care Bed 2.3.7 Materials Used For the most part, the bed was manufactured from steel profiles whose surfaces were finished with a polyester powder coating or a metal coating of zinc or chromium. The head and footboards and safety sides are made of wood or wood-based material with sealed surfaces.

  • Page 17: Putting Into Service

    Instruction Manual for Libra Care Bed 3 Putting into Service No electrical measurements are necessary prior to putting this bed into service for the first time, since the bed has been tested by the manufacturer for electrical safety and functionality and left our factory in perfect condition.

  • Page 18: Checklist: Inspection By The User

    Instruction Manual for Libra Care Bed 3.1 C HECKLIST NSPECTION BY THE Inspection Description of Defect What to Check... Check for... Visual Inspection of the Electrical Components Handset Damage? Handset cable Damage, cables routed away from moving parts? Power pack...

  • Page 19: Location Requirements

    Instruction Manual for Libra Care Bed 3.2 L OCATION EQUIREMENTS There must be sufficient room available to accommodate the bed’s entire range of adjustments. Furniture, window sills, must not be in the way. Before using the bed on parquet flooring, check whether the castors could leave marks on the parquet varnish.
  • Page 20 Instruction Manual for Libra Care Bed If any other additional equipment is attached to the bed, (e.g. compressors for positioning systems, etc.), ensure that this is securely fastened and is functioning properly. Pay special attention here to the safe routing of all loose connector cables, tubing, etc.

  • Page 21: Operation

    The bed is not suitable for being moved often and over long distances outside the room in corridors, across thresholds or on very uneven floors (except for Libra with Movo chassis, as it is equipped with larger castors). Adjust the bed to the lowest mattress base position before moving the bed over a long stretch outside the room.

  • Page 22: Individual Axle Braking (Standard)

    Instruction Manual for Libra Care Bed 4.1.1 Individual Axle Braking (Standard) Operate the castors, one set after the other, on either side at the head or foot end of the bed. This allows the castor sets at each end of the bed to be operated with one lever.

  • Page 23: Mechanical Adjustment Options

    Instruction Manual for Libra Care Bed 4.2 M ECHANICAL DJUSTMENT PTIONS 4.2.1 Lower Leg Rest (LR) The lower leg rest can be raised and lowered manually when the thigh rest is raised It is possible to adjust the bed to an orthopaedic (stepped bed) position or so that the lower leg rest is sloping downwards.

  • Page 24: Manual Cpr Release Of The Backrest

    Instruction Manual for Libra Care Bed Lower lower leg rest using the handset If the thigh rest is lowered using the handset, the lower leg rest is automatically lowered as well. Raise lower leg rest using the handset If the thigh rest is raised using the handset, the lower leg rest is automatically moved as well and locks into place in several intermediate positions.
  • Page 25 Instruction Manual for Libra Care Bed The motor is now disconnected from the backrest. Lay the motor down on the bed frame by hand. After the second person has left the danger zone, the first person (with the help of the second person) lowers the backrest carefully.

  • Page 26: Cpr Backrest Release Using Quick Release (Optional)

    Instruction Manual for Libra Care Bed 4.2.3 CPR Backrest Release Using Quick Release (Optional) In the event of a power cut or drive system failure, the raised backrest can also be comfortably lowered by just one person, without the need to dismantle the drive, using a quick release mechanism.

  • Page 27: Electrical Adjustment Options

    Instruction Manual for Libra Care Bed 4.3 E LECTRICAL ADJUSTMENT OPTIONS 4.3.1 Special Safety Information on the Electrical Drive System When making any adjustment procedures, always ensure that there are no limbs belonging to residents, users, other persons, and especially playing children, that could be trapped underneath the rests or the bed frame.
  • Page 28 Instruction Manual for Libra Care Bed Before moving the bed, always make sure that you have unplugged the power pack from the mains socket. The power pack must not fall off or touch the floor ( 4.4.1). Failure to observe this may result in permanent damage to the power pack.

  • Page 29: Handset (Standard)

    Instruction Manual for Libra Care Bed 4.3.2 Handset (Standard) The electrical bed functions can be activated by the resident or the user by using the handset. For safety reasons, the handset is equipped with a locking function. Depending on the clinical condition of the patient, the user can lock handset adjustments when deemed necessary by the supervising doctor ( Chapter 4.3.5).
  • Page 30 Instruction Manual for Libra Care Bed 4.3.2.1 Adjustment Functions of the Standard Handset Adjusting the backrest The backrest can be raised to approx. 70°. - Please also refer to Chapter 4.2.2 , “CPR release of the backrest”! Adjusting the thigh rest The thigh rest can be raised to approximately 40 °.

  • Page 31: Trendelenburg Handset (Optional)

    Instruction Manual for Libra Care Bed 4.3.3 Trendelenburg Handset (Optional) The Trendelenburg handset is optional and is used when using the bed for long-term medical care. 4.3.3.1 Adjustment Functions Function LED (yellow) Pressing this button will move the mattress base into the reverse- Trendelenburg position.

  • Page 32: Handset Including Trendelenburg Position (Optional)

    Instruction Manual for Libra Care Bed 4.3.4 Handset including Trendelenburg Position (Optional) Function LED (green) This handset offers the same functions as the standard handset but with the following difference: Locking icon (yellow) The sleep position button is replaced by the Trendelenburg button 1 .

  • Page 33: Handset Locking Functions

    Instruction Manual for Libra Care Bed 4.3.5 Handset Locking Functions Only users are authorised to use the locking function! If the clinical condition of the resident is so critical that any adjustment using the handset places him/her at risk, then carers must lock this adjustment function immediately.

  • Page 34: Lowering Mattress Base Elements Using The 9-Volt Batteries

    Instruction Manual for Libra Care Bed 4.3.6 Lowering Mattress Base Elements Using the 9-Volt Batteries In the event of a power outage, the backrest can be lowered using 2 x 9 volt batteries. The batteries are not included in the delivery.

  • Page 35: Attachments And Optional Features

    Instruction Manual for Libra Care Bed 4.4 A TTACHMENTS AND PTIONAL EATURES Optional bed features are indicated by an asterisk (*). 4.4.1 Cable Holder A steel cable holder is welded to the bed frame under the headboard. Before moving the bed, always hang the power pack and cable into the cable holder.

  • Page 36: Led Reading Light

    Instruction Manual for Libra Care Bed 4.4.2 LED Reading Light * The Libra bed can optionally be fitted with a reading light. The reading lamp can be supplied in two versions: Variant: Sola Variant: Stella The reading lamp is supplied with power via a separate plug-in power pack and has...

  • Page 37: Under Bed Light

    Instruction Manual for Libra Care Bed 4.4.3 Under Bed Light * The energy-saving, long-lasting LED under bed light provides safe orientation during the night and can reduce the risk of falls. The light is sufficiently restrained, however, to not disturb the resident of the adjacent bed.

  • Page 38: Patient Lifting Pole

    Instruction Manual for Libra Care Bed 4.4.4 Patient Lifting Pole * The two corners of the mattress base frame at the head end E of the bed are each fitted with a round sleeve with a recess at the top. These sleeves are the location sleeves for the patient lifting pole.

  • Page 39: Grab Handle * (Triangular Grab Handle)

    Instruction Manual for Libra Care Bed 4.4.5 Grab Handle * (Triangular Grab Handle) A grab handle can be attached to the patient lifting pole (accessory, see Chapter 8). The resident can use this grab handle to sit up and readjust his/her position.

  • Page 40: Bed Extension (Adaptable)

    Instruction Manual for Libra Care Bed 4.4.6 Bed Extension (Adaptable) * The bed can be fitted with an adaptable bed extension at the foot end which extends the mattress base by approx. 10 cm (if used with full-length and combined safety sides) or by approx.
  • Page 41 Instruction Manual for Libra Care Bed Screw the bed extension in place as shown 1 (2x screws from below) Assembling the footboard (see Chapter 4.4.8) Assemble the longer side panel or the longer safety side ( see Chapter 4.4.9 or Chapter 4.5.4.
  • Page 42 Instruction Manual for Libra Care Bed 4.4.6.3 Attaching the Bed Extension (with (2)/(6) Safety Sides) (2): Full-length safety sides (6): Combined safety side Before extending, observe the following points: The bed must not be occupied! The bed must be immobilised with the brake.

  • Page 43: Linen Holder

    Instruction Manual for Libra Care Bed 4.4.7 Linen Holder * The bed can be fitted with an optional linen holder 1 , which can be pulled out from under the footboard whenever necessary. To prevent the bedding from falling, the linen holder has a gallery rail 2 which can be folded up.

  • Page 44: Removing/Assembling The Headboard/Footboard

    Instruction Manual for Libra Care Bed 4.4.8 Removing/Assembling the Headboard/Footboard The headboard and footboard can be quickly removed/assembled without tools to provide easier access to the resident. Use the locking lever attached to the cross tubing to operate/release the headboard/footboard for assembly/removal.
  • Page 45 Instruction Manual for Libra Care Bed 4.4.8.1 Assembly Standing behind the 2 Insert the locking hooks 1 of the headboard/footboard, firmly grip the adaptors into the slits of the cross tube uppermost corners of the 2 as far as they will go and make...
  • Page 46 Instruction Manual for Libra Care Bed 4.4.8.2 Removal Use a finger to pull the orange safety lock 1 to the centre of the bed and keep holding it in this position. Page 46...
  • Page 47 Instruction Manual for Libra Care Bed Swivel the locking lever 1 (left and right side) downwards Page 47...
  • Page 48 Instruction Manual for Libra Care Bed Standing behind the headboard/footboard, firmly grip the uppermost corners of the headboard/footboard with both hands 4 Pull the headboard/footboard up and out of the slits in the cross tube as evenly as possible Page 48...

  • Page 49: Fitting/Removing The Side Panels

    Instruction Manual for Libra Care Bed 4.4.9 Fitting/Removing the Side Panels The bed can optionally be fitted with side panels. A total of four side panels are needed: 2x long (110 cm) and 2x short (90 cm). 1x short and 1x long side panel are mounted on each side of the bed.
  • Page 50 Instruction Manual for Libra Care Bed 2 Attach the side panel at the head end to the long tube (head end) as shown. Place the locking hooks of the adaptors 1 into the slits in the long tube as far as they will .
  • Page 51 Instruction Manual for Libra Care Bed Swivel the locking lever 2 (left and right side) upwards and press until it audibly clicks into place. 5 Check that the side panel is firmly in place by jiggling the top edge of the panel to and fro.
  • Page 52 Instruction Manual for Libra Care Bed Removal Use the locking lever to release the side panels. Use a finger to pull the orange safety lock of the locking lever 1 outwards and keep holding it in this position. Swivel the locking lever 2 (left and right side) downwards...
  • Page 53 Instruction Manual for Libra Care Bed Grasp the lower edge of the side panel with both hands. Pull the side panel up and out of the slits in the long tube as evenly as possible Page 53...

  • Page 54: Safety Sides

    Instruction Manual for Libra Care Bed 4.5 S AFETY IDES The bed has safety sides to protect the resident from falling out of bed. The bed is supplied as standard with full-length safety sides (2) on both sides of the bed. At the customer's request, the bed can be fitted with the following variants of safety sides.

  • Page 55: Full-Length Safety Sides (Standard)

    Instruction Manual for Libra Care Bed 4.5.1 Full-length Safety Sides (Standard) Raising At the head and footboard, pull the upper bar of the safety side upwards as far as it will go, first at one end and then at the other. The lower bar follows.

  • Page 56: Special Safety Information For Safety Sides

    Instruction Manual for Libra Care Bed 4.5.2 Special Safety Information for Safety Sides Safety sides protect the resident from unintentionally falling out of bed. They are not intended as a device to prevent the occupant from intentionally leaving the bed.
  • Page 57 Instruction Manual for Libra Care Bed Risk of injury if the mattress holders are not used and only a side panel is fitted on one side In this case, a mattress can be displaced too far away from a raised safety side and towards the side panel at the other side of the bed.

  • Page 58: Combined Safety Sides

    Instruction Manual for Libra Care Bed 4.5.3 Combined Safety Sides * Position as delivered Raising the safety sides Raising the safety sides at the head end Grasp the middle of the top safety side bar and pull the safety side bar upwards as far as it will go.
  • Page 59 Instruction Manual for Libra Care Bed Lowering the safety side Before lowering the safety side, make sure that none of the resident's limbs are located within the moving range of the bars. This prevents the occupant from being crushed or sustaining other injuries.
  • Page 60 Instruction Manual for Libra Care Bed Store the central support at the foot end of the bed by sliding it into the special holder 1 underneath the mattress base, as illustrated here. Slide the central support in gently as far as it will go.
  • Page 61 Instruction Manual for Libra Care Bed Fixing the central support in place Pull the central support out of the holder 1 at the foot end of the bed. Open the cover 2 by hand and hold it firmly. Make sure that fingers, bed linen, tubes or other objects cannot become...
  • Page 62 Instruction Manual for Libra Care Bed Other uses for the central support If safety sides are not needed (foot end), the centre support can be used as a mobilisation aid. The sturdy central support helps the resident to get in and out of bed easily.

  • Page 63: Split Safety Sides

    Instruction Manual for Libra Care Bed 4.5.4 Split Safety Sides * Libra can be fitted with optional split safety sides “Vario Safe system”. Risk of injury due to incorrect installation or storage of split safety sides, headboards, footboards or side panels with the “Vario Safe”...
  • Page 64 Instruction Manual for Libra Care Bed Attach the side panel at the head end to the long tube Page 64...
  • Page 65 Instruction Manual for Libra Care Bed Insert the locking hook of the adapter into the slits of the long tube as far as it will go and make sure the safety side is inserted properly Swivel the locking lever (left and right side) upwards and press until it audibly...
  • Page 66 Instruction Manual for Libra Care Bed Check that the safety side is firmly attached by holding it at the lower edge with both hands and rocking it up and down. Repeat steps 1 to 5 with the remaining three sections of the split safety side.
  • Page 67 Instruction Manual for Libra Care Bed 4.5.4.2 Sticker - Split Safety Sides Risk of injury through incorrect installation of split safety sides! Non-observance can lead to entrapment of body parts. Please note: There is a sticker in the middle of the long side of the mattress base frame (see illustration).
  • Page 68 Instruction Manual for Libra Care Bed With bed extension The following is permitted: 2x The following is permitted: 2x size size 110 cm 110 cm split safety sides split safety side Bed extension approx. 20 cm Without bed extension The following is permitted:...
  • Page 69 Instruction Manual for Libra Care Bed 4.5.4.3 End Cap - Split Safety Side Please note: Slits are provided in the frame of the mattress base to accommodate split safety sides or side panels. Two slits are left open when the large safety side/side panel is mounted on the head end and the small one on the foot end and vice versa.
  • Page 70 Instruction Manual for Libra Care Bed 4.5.4.4 Removal Use a finger to pull the orange safety lock 1 of the locking lever outwards and keep holding it in this position Swivel the locking lever (left and right side) downwards Page 70...
  • Page 71 Instruction Manual for Libra Care Bed Grasp the lower bar of the safety side with both hands Pull the safety side up and out of the slits in the long tube as evenly as possible. Page 71...
  • Page 72 Instruction Manual for Libra Care Bed 4.5.4.5 Operation The split safety side can be easily raised or lowered and can be adjusted to various positions. Raising Grasp the top bar 1 with both hands and pull the safety side up as far as it will go.
  • Page 73 Instruction Manual for Libra Care Bed Various position options The split safety sides can be positioned as follows: Fully-lowered safety side Raising the top bar Fully-raising the safety side Angled position of the top bar Page 73...

  • Page 74: Variant - Without Safety Side

    4.5.5 Variant - Without Safety Side * Libra beds can also be supplied without safety sides if the customer prefers. Should it later be necessary to use a safety side, the bed can easily be fitted with this at a later date.

  • Page 75: Comfort Mattress Base - 90 Cm Width

    Instruction Manual for Libra Care Bed 4.5.6 Comfort Mattress Base - 90 cm width * Libra can optionally be fitted with a Comfort mattress base. The following assembly instructions refer to the 90 cm wide mattress base: Wings of the black elements face outwards 1 Turn the mounting clips 2 180°...

  • Page 76: Comfort Mattress Base - 100 Cm Width

    Instruction Manual for Libra Care Bed 4.5.7 Comfort Mattress Base - 100 cm width * The following assembly instructions refer to the 100 cm wide mattress base: Wings of the black elements face outwards 1 Turn the mounting clips 2 180° until they are 168 mm in length 3 .

  • Page 77: Cleaning And Disinfection

    Instruction Manual for Libra Care Bed 5 Cleaning and Disinfection This bed is NOT suitable for machine washing or for cleaning in a decontamination unit. The bed is only suitable for manual cleaning and disinfection. To extend the bed's service life and preserve its operability, always follow the instructions provided in this chapter.

  • Page 78: Cleaning And Disinfection Plan

    Instruction Manual for Libra Care Bed 5.2 C LEANING AND ISINFECTION Remove the bed linen and send it to the laundry service. Clean all surfaces, including the slatted bed frame and mattress base made of synthetic or metal slats, with a mild and environmentally friendly cleaning agent.

  • Page 79: Instruction Of Users And Staff

    Instruction Manual for Libra Care Bed 5.3 I NSTRUCTION OF SERS AND TAFF In order to ensure that cleaning and disinfection are conducted properly, we recommend that users and technical staff are appropriately instructed. When providing instruction, observe the following points: A clean bed must be transported in such a way that it will not become dirty or contaminated.

  • Page 80: Cleaning Of Firmly Upholstered Components

    IRMLY PHOLSTERED OMPONENTS The headboards, footboards and side-panels of the Libra bed can be supplied in the upholstered version, fabric or imitation leather upholstery, according to customer specifications. Any soiling of these components must be removed immediately. 5.4.1 Cleaning the Fabric Upholstery Soiling caused by intensive use or food residues must be removed using simple means.
  • Page 81 Instruction Manual for Libra Care Bed Cleaning method 2 Apply a generous amount of solvent-based cleaning agent to the stain with a soft cloth or sponge. Rinse the area with fresh water and dry with a soft cloth. Cleaning method 3 Apply a strong, solvent-based cleaning agent diluted with water (70% water, 30% acetone) with a soft cloth or sponge.

  • Page 82: Cleaning And Disinfection Agents

    Despite the excellent mechanical resistance, any scratches, knocks etc. which permeate the entire coating should be resealed using a suitable repair substance to prevent moisture from penetrating. For further information, consult STIEGELMEYER or a specialist of your choice. As a rule, aldehyde-based disinfectants have the advantage that they have a wide range of impact, a relatively low protein effect and are environmentally friendly.

  • Page 83: Handling Cleaning And Disinfection Agents

    Instruction Manual for Libra Care Bed The choice of cleaning agents and disinfectants available on the market may change from time to time. Stiegelmeyer therefore routinely tests the most commonly used materials for compatibility. The most up-to-date list of cleaning agents and disinfectants can be obtained from our service centre on request.

  • Page 84: Maintenance

    Instruction Manual for Libra Care Bed 6 Maintenance Legal Principles Operators of beds in Germany are obliged in accordance with German Medical Devices Operator Ordinance § 4 (Maintenance) DGUV 3 (Testing of Mobile Electrical Equipment in Commercial Use) of the...

  • Page 85: By The User

    Instruction Manual for Libra Care Bed 6.1 B Y THE If damage or a malfunction is suspected, the bed must be withdrawn from service immediately and disconnected from the mains supply until the defective parts have been repaired or replaced! Contact the operator who is responsible for you if the defective parts need to be replaced or repaired.

  • Page 86: By The Operator

    Instruction Manual for Libra Care Bed 6.2 B Y THE PERATOR The operator of this care bed is obliged according to MPBetreibV (Medical Devices Operator Ordinance) Section 4 to conduct regular inspections after each renewed assembly, after each maintenance and during regular operation...
  • Page 87 Instruction Manual for Libra Care Bed Power pack Preparation: o Unplug the power pack from the wall mains socket. o Plug the power pack into the test socket on the test device. Test procedure: o Make the following selections on the instrument: Leakage current test: direct or...
  • Page 88 Instruction Manual for Libra Care Bed Inspection Report following an Inspection of Electromedical Equipment according to DIN EN 62353 (VDE 0751-1): 2015-10 – Page 1 of 3 Customer / med. facility / practice: Address: Carried out: value) Equipment type: Care bed...
  • Page 89 Instruction Manual for Libra Care Bed Inspection Report following an Inspection of Electromedical Equipment according to DIN EN 62353 (VDE 0751-1): 2015-10 – Page 2 of 3 III. Description Function test of Defect What to Check... Check for... Performance Check of the Electrical Components...
  • Page 90 ** Data from Stiegelmeyer supplemented for the existing full-length safety side configuration *** Data from Stiegelmeyer supplemented for the existing split safety side configuration with at least the safety sides at the head end raised (if completely raised at head and foot ends, this corresponds to a one-piece safety side;...

  • Page 91: Replacement Parts

    Instruction Manual for Libra Care Bed 6.3 R EPLACEMENT ARTS In order to maintain operational safety and the right to claim under warranty, only original Stiegelmeyer replacement parts may be used! For quick and easy ordering of replacement parts we require the following information...

  • Page 92: Replacement Of Electrical Components

    Before commencing any work, unplug the power pack from the electrical socket! Any work and/or repairs to the electrical equipment may only be carried out by the Stiegelmeyer service engineers, the drive manufacturer or qualified and authorised electricians in compliance with all the relevant VDE and safety regulations!

  • Page 93: Plug Assignment Of The Control Unit

    Instruction Manual for Libra Care Bed 6.5.1 Plug Assignment of the Control Unit All plugs are connected to the control unit. To prevent the plugs from being inadvertently disconnected, they are secured with a cover. 1 = Handset 2 = Foot section lift motor (white)

  • Page 94: Control Replacement

    Instruction Manual for Libra Care Bed 6.5.3 Control Replacement Unplug the power pack from the socket. Carefully unscrew the plug cover from the control unit using a Phillips screwdriver. Mark the plug positions to avoid switching them when they are re-assembled (see Chapter 6.5)

  • Page 95: Motor Replacement

    To prevent the motor bolts from working loose and causing potentially hazardous sudden changes in the position of the bed, always ensure that you fit new safety washers (“Starlock”; available from Stiegelmeyer service department) and do not refit the old safety caps that you removed.

  • Page 96: Troubleshooting

    Instruction Manual for Libra Care Bed 7 Troubleshooting The following table is a guide for rectifying common malfunctions. Should a malfunction occur that is not included in the table, inform your operator. Problem Possible causes Solution Handset/ Power pack not plugged in/not Insert power pack;...
  • Page 97 Instruction Manual for Libra Care Bed Problem Possible causes Solution Permanent or Control faulty Inform your operator about longer signal tone any necessary repairs without operating the handset Individual drives Handset, drive unit or control Inform your operator about operate in one...

  • Page 98: Accessories

    This will prevent any overloading of the fixing points. Lists of accessories can be obtained from Stiegelmeyer and their sales partners, quoting the bed model. Here are some examples: Patient lifting pole with...

  • Page 99: Technical Data

    Instruction Manual for Libra Care Bed 9 Technical Data All indications of dimensions and weights in this manual are approximate. 9.1 D IMENSIONS AND EIGHTS 200 x 90 cm (standard) Mattress base (LxW) 200 x 100 cm (option) (option: 220 x 90 cm) with bed extension...
  • Page 100 Instruction Manual for Libra Care Bed Handset DEWERT IPROXX II Type IP X6 Protection category Input voltage 24 V DC Electric motor for mattress base height DEWERT Megamat 2 Type 6,000 N / 250 mm Force/lift 24 V DC Input voltage...

  • Page 101: Ambient Conditions

    Instruction Manual for Libra Care Bed 9.3 A MBIENT ONDITIONS The following ambient conditions must be maintained: For storage/transport Minimum Maximum Storage temperature: - 20 °C + 50 °C Relative humidity: 30 % 75 % Air pressure: 800 hPa 1060 hPa at altitude of < 2000m...

  • Page 102: Other Labelling On The Product

    Instruction Manual for Libra Care Bed 9.5 O THER ABELLING ON THE RODUCT Symbol Meaning Mark of conformity in accordance with the Medical Devices Directive 93/42, EEC Annex VII Safe working load (= max. permissible weight of patient, mattress and all accessories attached) Max.
  • Page 103 Instruction Manual for Libra Care Bed This device is compliant with the following EMC standards regarding interference emissions and immunity: Ambient limit values of the interference emissions Phenomenon Professional healthcare facilities Home healthcare environment Conducted and radiated interference CISPR 11...
  • Page 104 Instruction Manual for Libra Care Bed DC port for supply input Phenomenon EMC basic Immunity test level standard Professional healthcare Home healthcare facilities environment Short, transient electrical IEC 61000-4-4 +/- 2 kV; 100 kHz repetition frequency disturbances / bursts Surges: conductor to conductor IEC 61000-4-5 +/- 0.5 kV;...
  • Page 105 Instruction Manual for Libra Care Bed Table zz: Test specifications for the immunity of sheathings to high-frequency wireless communication equipment Test Frequency Radio Modulation Max. power Distance Immunity frequency band service test level Pulse TETRA 400 380 to 390 modulation...

  • Page 106: Classification

    Instruction Manual for Libra Care Bed 9.7 C LASSIFICATION This bed fulfils all the requirements of the 93/42/EEC Medical Device Directive. This bed is classified as a Class I active medical device with type B applied part (in accordance with the Medical Devices Act § 13).

  • Page 107: Disposal Instructions

    - The operator of this bed is legally obliged to send the electrical components directly to the manufacturer and not to dispose of them at municipal waste collection points. STIEGELMEYER and its service and sales partners will take these components back.

  • Page 108: Declaration Of Conformity

    Instruction Manual for Libra Care Bed 11 Declaration of Conformity EC Declaration of Conformity Stiegelmeyer GmbH & Co. KG Ackerstrasse 42 D-32051 Herford, Germany hereby declare under sole responsibility as the manufacturer that the product model named below: Care bed model: Libra in the version submitted complies with the regulations of the EC Directive 93/42/EEC Annex VII for Medical Devices, last amended by Directive 2007/47/EC dated 5 September 2007.
  • Page 109 Instruction Manual for Libra Care Bed Page 109...
  • Page 110 Instruction Manual for Libra Care Bed Page 110...
