GOWESTY F45VW-T4 Quick Start Manual

These instructions and the images herein are proprietary. Any unauthorized reproduction is prohibited.
Awning Bracket for Eurovan – Fits Fiamma and ARB Awnings
Please use your best judgment when installing your awning. These instructions are to be
used as a guideline, but remember the old adage: "Measure twice, drill once!" GoWesty
will not be liable for any damage to your vehicle during the installation of this will not be liable for any damage to your vehicle during the installation of this kit.
will not be liable for any damage to your vehicle during the installation of this will not be liable for any damage to your vehicle during the installation of this
you are uncertain of your ability to safely perform the procedures in these instructions,
please have your awning professionally installed.
(6) 6mm rivet nuts
(6) 6mm x 20mm hex bolts
(4) 6mm x 16mm hex bolts
(4) 6mm x 25mm hex bolts
(2) 5mm machine screws
(2) Rubber gaskets
Fitting the Fitting the Front Bracket Fitting the Fitting the Front Bracket Front Bracket to the Body Front Bracket
1) Hold the bracket up and mark the large, bottom hole for drilling. Hole should be centered 1¼" above lip on
front pillar. Drill a 25/64" hole.
2) Attach rivet nut using rivet nut tool. Application of a silicone sealant in the bolt hole and around each
threading piece is recommended.
3) Bolt on gasket and bracket.
4) Drill pilot holes through bracket. Remove bracket and drill holes out to 25/64".
5)
Apply silicone sealant and attach rivet nuts with rivet nut tool. Bolt on gasket and bracket to test the fit using
the 6mm x 20mm bolts (you will have to remove the brackets if installing an ARB awning).
Fitting the Rear Fitting the Rear Fitting the Rear Bracket to the Body Fitting the Rear Bracket to the Body Bracket to the Body Bracket to the Body
6) Follow steps 2-5 with the rear bracket. The lower hole should be positioned as high as possible without being
affected by the bodyline (positioning the bracket too low could interfere with the slider door).
7) From center of front bracket to center of rear bracket is measured as follows:
a. EVC Winnebago: 96" (10' Fiamma awning), 83" (8' Fiamma and ARB a EVC Winnebago: 96" (10' Fiamma awning), 83" (8' Fiamma and ARB awning)
EVC Winnebago: 96" (10' Fiamma awning), 83" (8' Fiamma and ARB a EVC Winnebago: 96" (10' Fiamma awning), 83" (8' Fiamma and ARB a
b. Eurovan MV/Hard Top: 83" (all a Eurovan MV/Hard Top: 83" (all awnings)
Eurovan MV/Hard Top: 83" (all a Eurovan MV/Hard Top: 83" (all a
