SubDrive Utility Fan
Replacement and Install Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SubDrive Utility Fan and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Franklin Electric SubDrive Utility Fan

Summary of Contents for Franklin Electric SubDrive Utility Fan

  • Page 1 SubDrive Utility Fan Replacement and Install Guide...
  • Page 2 • Verify that the fan runs for 3–5 seconds during the power-up initialization. If the fan does not perform as stated above, note the error and consult your local Franklin Electric representative or call the Franklin Electric Technical Service Hotline at 1-800-348-2420.
  • Page 3 SUBDRIVE UTILITY FAN REPLACEMENT AND INSTALL GUIDE WARNING REMOVE ALL INCOMING ELECTRICAL POWER TO THE DRIVE. THIS IS A NON-POWERED ELECTRIC PROCEDURE. FAN REPLACEMENT STEP 1: Verify the fan replacement kit. Drive Model Size Fan Kit No. Fan Cover 5870202003 60 mm (2.36")
  • Page 4 SUBDRIVE UTILITY FAN REPLACEMENT AND INSTALL GUIDE STEP 3: Remove the rivets from the bottom of the enclosure. STEP 4: STEP 5: Disconnect the three (3) fan leads from the fan terminal block. Remove the fan from the enclosure.
  • Page 5 SUBDRIVE UTILITY FAN REPLACEMENT AND INSTALL GUIDE STEP 6: STEP 7: Locate the airflow indication arrow on the side of the fan. Install the replacement fan into the enclosure. Position the fan so that the air is directed into the enclosure.
  • Page 6 Fan installation is complete. Replace the drive cover and tighten lid screws to 10 in-lbs (1.1 Nm). Apply power and verify that the fan turns on and is working properly. If you experience any difficulty in performing these steps, consult your local Franklin Electric representative or call the Franklin Electric Technical Service Hotline at 1-800-348-2420.
  • Page 7 SUBDRIVE UTILITY FAN REPLACEMENT AND INSTALL GUIDE...
  • Page 8 TOLL-FREE HELP FROM A FRIEND Franklin Electric Technical Service Hotline 800-348-2420 Form 226115916 9255 Coverdale Road, Fort Wayne, IN 46809 Rev. 0 Tel: 260.824.2900 Fax: 260.824.2909 06/17 www.franklinwater.com...
