Marley Stir It Up Quick Start Directions

1
Place the turntable on a stable, level
surface. Avoid direct sunlight, heat and
locations subject to vibrations and
excessive dust, cold or moisture.
5
Important: Do NOT twist belt. Belt must
remain untwisted when attaching platter
to turntable.
9
Connect included AC power supply
into Stir It Up and plug into outlet. Use
correct power converter.
13
Release the tone arm clamp
STIR IT UP TURNTABLE — QUICK START DIRECTIONS
2
Wrap rubber belt along outer edge of
inner circle lip on underside of metal
platter.
6
Place silicone rubber slip-mat on the
aluminum platter.
External
Device
10
Connect turntable output to external
amplifier or speaker using the included
auxiliary cable. Switch PRE-AMP "ON" or
"OFF" to match the external device.
NOTE: See details on other side for
correct PRE-AMP settings.
14
Lift and move the tone arm to the record
and the platter will start rotating.
3
Stretch rubber belt away from inner cir-
cle, grabbing belt through one large hole
from opposite side (topside) of platter.
7
Remove the needle cover from the
stylus.
11
Place a record on the turntable, over the
central spindle.
15
Use the tone arm lift lever gently lower
and raise the needle to the record.
4
Flip platter, continue stretching the belt
through hole. Connect belt to turntable
by sliding belt over brass spindle while
inserting platter down onto the unit.
8
Assemble the balance weight by pushing
onto back of tonearm, and set it to a
proper position by twisting clockwise or
counter-clockwise to find perfect amount
of pressure.
NOTE: If pressure is too much, the sound
will become distorted; if the pressure is
too little, track skipping will occur.
45
45
33
33
0
0
12
Set the Speed Selector to 33 or 45 rpm
according to record speed. Power is on
when speed is set. Platter will rotate
when tone arm moves (see #14).
16
When the record is finished the platter
will automatically stop. To stop manual-
ly, lift the tone arm from the record and
return it to the rest.
NOTE: Whole system, will power down
after 30mins. To turn it back on, flip
speed switch back off and on again.
